Curtis Kubota L47 TLB Cab Installation & Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
While this cab kit was designed to fit on the vehicle(s) listed above, manufacturing tolerances and vehicle
assembly may affect cab fitment. It is the responsibility of the cab installer to check all vehicle pedals and levers
for full functionality and, as required, adjust the cab fitment to prevent any interference of the cab components
with the travel of pedals or levers.
Available Options:
1. Rear Closeout Panel for Operation When Backhoe is Removed (P/N: 1KTLBL47RP)
2. Optional Rear Hydraulics Closeout panel for tractors with optional rear remote hydraulics installed (P/N: 1KTLBL47HYD)
3. Front or rear Round LED Work Lights (fits both L47 and M62) (P/N: 1KTLBLEDWL) (shown above)
Approximate Installation Time *
Experienced Dealer Technician – 6-8 Hours
Average Dealer Technician – 8-10 Hours
Do-It-Yourself – 10-14 Hours
(*=Not including accessories)
The contents of this envelope are the property of the owner. Leave with the owner when installation is complete.
Kubota L47 TLB Cab
P/N: 1KTLBL47
Shown with Optional Front and Rear Round LED Work Lights
Approximate Product Specifications
Fits Under the Factory Roof
Weight: 584 lbs.
Cab Width: 60-1/2" (3-1/2" wider than right fender)
1 of 37
Rev. G, 04-13-2022
p/n: IM-1KTLBL47
