SansAmp RBI Specifications

Note: With on-going product development and improvements, specifications and/or
the cosmetic appearance of this unit may change without prior notice. Replacement
parts are available, i.e., knobs, rack handles, faceplate, etc. For more information,
please contact your authorized dealer or Tech 21.
Model Number:
Input Impedance-Input 1:
Input Impedance-Input 2:
Output Impedance-1/4":
Output Impedance-XLR:
Input Level-Input 1:
Input Level-Input 2:
Output Level-XLR:
Maximum Output Level:
Effects Loop Send:
Effects Loop Return:
Low Frequency Response:
High Frequency Response:
Maximum Power Consumption:
AC Input Power (factory set):
Cycles:
Enclosure:
Dimensions:
Weight:
NOTES: ___________________________________________________________________
___________________________________________________________________________
___________________________________________________________________________
___________________________________________________________________________
___________________________________________________________________________
___________________________________________________________________________
___________________________________________________________________________
___________________________________________________________________________
* Due to the variety of amplifier emulations available, frequency response
characteristics will vary.
RBI
1MΩ
1MΩ
1K Ohm min
600 Ohm min
1V RMS max
1V RMS or 10V max, with -20dB pad engaged
Switchable to -20dB or 0dB range
+10dB or better
1K Ohm min, -20dB
100K Ohm min, -20dB
10Hz or better*
Harmonic content, 20kHz or better*
5 Watts
100V, 117V, 230V, 240V
50/60 Hz
NOTE: Each unit is constructed for specific
voltages. AC power cannot be switched.
Aluminum and steel, fully shielded
19.0"w x 1.75"h x 5.25"d / Overall depth: 6.25"
5 lbs.
