TRENDnet TE100-PCIWS Specifications

TE100-PCIWS
32-bit PCI 10/100Mbps NWay Fast Ethernet Card
TRENDnet's TE100-PCIWS is a high performance 32-bit PCI
10/100Mbps NWay Fast Ethernet Adapter. It complies with
PC99 standard and supports PCI Bus Master specifi-cation
2.1 and 2.2. It senses 10Mbps or 100Mbps (20Mbps or
200Mbps in full-duplex mode) automatically and connects to
Ethernet/Fast Ethernet network with single RJ-45 connector.
Running at full duplex speed, the adapter turns a desktop PC
into a high-bandwidth multimedia work-station.
FEATURES
Complies with IEEE 802.3, IEEE 802.3µ, and IEEE
802.3x standards
Plug-and-Play (PnP) auto-configuration
32-Bit PCI bus master specification Rev 2.1/2.2
Supports Wake-on-LAN and ACPI for PCI 2.2
specification Motherboard
Full-duplex mode that doubles the data transfer rate up to
20Mbps/200Mbps
Full-duplex flow control (IEEE 802.3x)
10/100Mbps NWay auto-negotiation RJ45 port
Easy-to-view LED indicators
Built-in FIFO buffers reduces overhead of memory
transfers
Compatible with all popular operating systems
Complies with PC99 standard
5 Year Warranty
TRENDnet
TRENDware, USA
What's Next in Networking
BENEFITS
Performance:
Operates in the 32-bit bus master mode,
delivering throughputs as multi-
megabits per second with little stress on
the host's CPU.
Easy Installation:
Just plug it into your workstation, load
the driver, and it's ready to go!
Flexibility:
Half/full-duplex mode auto-detection in
both 10Base-T and 100Base-TX modes.
Cost-Effectiveness:
Complying with PC99 standard and
power saving mode (for PCI 2.2
specification), TRENDnet PCI PnP
adapter is the perfect choice for cost-
effective and high-bandwidth
workgroup.
TE100-PCIWS (11-17-2002)
