SETUP INSTRUCTIONS
2011
250 SX‑F EU
250 SX‑F USA
Art. no. 3211676en

Advertisement

loading

Related Manuals for KTM 250 SX-F 2011

Summary of Contents for KTM 250 SX-F 2011

  • Page 1 SETUP INSTRUCTIONS 2011 250 SX‑F EU 250 SX‑F USA Art. no. 3211676en...
  • Page 3 KTM accepts no liability for delivery options, deviations from illustrations and descriptions, as well as misprints and other errors.

  • Page 4: Means Of Representation

    MEANS OF REPRESENTATION Symbols used The symbols used are explained in the following. Identifies an expected reaction (e.g. to a work step or a function). Identifies an unexpected reaction (e.g. to a work step or a function). Identifies a page reference (more information is provided on the specified page). Indicates information with more details or tips.
  • Page 5 SET‑UP Unpacking and setting up the vehicle Packaging 2 – Remove the box and the plastic packaging. Info To avoid damaging the motorcycle during the setup, leave the protective film on the vehicle until you have finished. – Remove the separate enclosure and unpack it. Check that the scope of delivery is complete on the basis of the enclosed packing list.
  • Page 6 SET‑UP Guideline Screw, bottom shock 60 Nm Loctite ® 243™ absorber (44.3 lbf ft) – Position FI warning lamp with holder . Mount and tighten the screw.  Guideline Remaining screws, chassis 10 Nm (7.4 lbf ft) – Plug connector into the wiring harness.
  • Page 7 Apply the label included in the delivery (optional). 101019-01 – Refuel. ( p. 7) – Position all controls exactly on the handlebar. Tighten all screws. – Print out the current PDI form found on KTM DEALER.NET and perform the delivery inspection.
  • Page 8 WORK Installing the front wheel Warning Danger of accidents Reduced braking efficiency due to oil or grease on the brake discs. – Always keep the brake discs free of oil and grease, and clean them with brake cleaner when necessary. – Check the wheel bearing for damage and wear.
  • Page 9 WORK Removing the seat – Remove screw  – Lift up the seat at the rear, pull it back and then remove it from above. B00317-10 Mounting the seat – Hook in the front of the seat at the collar bushing of the fuel tank, lower it at the rear and simultaneously it push forward.
  • Page 10 WORK Note Material damage Premature clogging of the fuel filter. – In some countries and regions, the available fuel quality and cleanliness may not be sufficient. This will result in problems with the fuel system. – Only refuel with clean fuel that meets the specified standards. Warning Environmental hazard Improper handling of fuel is a danger to the environment.

  • Page 11: Technical Data - Chassis Tightening Torques

    TECHNICAL DATA - CHASSIS TIGHTENING TORQUES – Spoke nipple, front wheel M4.5 5… 6 Nm (3.7… 4.4 lbf ft) – Spoke nipple, rear wheel M4.5 5… 6 Nm (3.7… 4.4 lbf ft) – Remaining nuts, chassis 15 Nm (11.1 lbf ft) –...
  • Page 12 SUBSTANCES Super unleaded (ROZ 95 / RON 95 / PON 91) According to – DIN EN 228 (ROZ 95 / RON 95 / PON 91)

  • Page 13: Auxiliary Substances

    AUXILIARY SUBSTANCES Long-life grease Guideline – ® KTM recommends Motorex products. Supplier ® Motorex – Bike Grease 2000...
  • Page 14 *3211676en* 3211676en KTM-Sportmotorcycle AG 5230 Mattighofen/Austria http://www.ktm.com...
