contact a qualified electrician and have it replaced with a properly
grounded three-pronged wall receptacle or have a grounding adapter
properly grounded and polarized. If the extension cord must be used, it
should be a 3-wire, 15 amp. or higher rated cord. Do not drape over a
countertop or table where it can be pulled on by children or tripped over
accidentally.
CAUTION: DO NOT UNDER ANY CIRCUMSTANCES CUT OR RE-
MOVE THE ROUND GROUNDING PRONG FROM THIS
PLUG.
1. Door open handle
Pull to open door.
2. Door latches
The oven will not operate unless the
door is securely close.
3. Removable turntable support
4. Removable turntable
The turntable will rotate clockwise or
counterclockwise.
5. Oven lamp
It will light when oven is operating or
door is opened.
6. Oven door with see-through window
7. Ventilation openings (Rear)
NOTE:
The directed features are disabled after three minutes
when the oven is not in use. These features are auto-
matically enabled when the door is opened and closed
or the STOP/ CLEAR pad is pressed.
OVEN DIAGRAM
6
5
10
2
1
8. Auto-Touch control panel
9. Time display: Digital display, 99 minutes 99 seconds
10. Coupling
TOUCH CONTROL PANEL
5
3-Pronged Plug
Grounding Pin
3-Pronged Receptacle
9
12
8
11
Sensor Cooking
Sensor
Popcorn
reheat
Fresh
Rice
Vegetables
Ground
Poultry
meat
Frozen Foods
Entrees
Snacks
Let's Cook
Breakfast
Lunch
Defrost
From the
Center
Pantry
Keep Warm
Timer
Plus
Clock
Stop
Power
Level
Clear
R-330EK
R-330EW
Grounded
Receptacle Box
7
4
3
11. Wave guide cover
12. Power supply cord
See note.
Custom
Help
Baked
potatoes
Fish
Seafood
Vegetables
15 Minute
Recipes
Beverage
Center
Minute
PLus
Start
See note.
Touch on
