Page 1 UPER ® 6014H-32 UPER ERVER USER’S MANUAL 1.0a...
Page 2 Please Note: For the most up-to-date version of this manual, please see our web site at www.supermicro.com. SUPER MICRO COMPUTER reserves the right to make changes to the product described in this manual at any time and without notice.
Page 3: Preface
About This Manual This manual is written for professional system integrators and PC technicians. It pro- vides information for the installation and use of the SuperServer 6014H-32. Instal- lation and maintainance should be performed by experienced technicians only. The SuperServer 6014H-32 is a high-end 1U rackmount server based on the SC813T-500 1U rackmount server chassis and the X6DHR-3G2 serverboard, which supports single or dual Intel®...
Page 4 UPER ERVER 6014H-32 User's Manual Chapter 4: System Safety You should thoroughly familiarize yourself with this chapter for a general overview of safety precautions that should be followed when installing and servicing the SuperServer 6014H-32. Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the X6DHR-3G2 serverboard, includ- ing the locations and functions of connectors, headers and jumpers.
Page 5 Preface Notes...
Page 6: Table Of Contents
UPER ERVER 6014H-32 User's Manual Table of Contents Preface About This Manual ... iii Manual Organization ... iii Chapter 1: Introduction Overview ... 1-1 Serverboard Features ... 1-2 Server Chassis Features ... 1-4 Contacting Supermicro ... 1-6 Chapter 2: Server Installation Overview ...
Page 7 Power ... 3-3 SAS/SATA Drive Carrier LED ... 3-3 Chapter 4: System Safety Electrical Safety Precautions ... 4-1 General Safety Precautions ... 4-2 ESD Precautions ... 4-3 Operating Precautions ... 4-4 Chapter 5: Advanced Serverboard Setup Handling the Serverboard ... 5-1 Processor and Heatsink Installation ...
Page 8 UPER ERVER 6014H-32 User's Manual Extra USB Headers ... 5-15 Power LED/Speaker ... 5-15 ATX PS/2 Keyboard & Mouse Ports ... 5-15 JLAN 1/2 (Ethernet Ports) ... 5-15 Wake-On-LAN ... 5-16 Wake-On-Ring ... 5-16 SMB ... 5-16 SMB Power ... 5-16 Jumper Settings ...
Page 9 Removing/Replacing the Power Supply ... 6-9 Chapter 7: BIOS Introduction ... 7-1 Running Setup ... 7-2 Main BIOS Setup ... 7-2 Main BIOS Setup Menu ... 7-3 Advanced Setup ... 7-6 Security ... 7-16 Boot ... 7-17 Exit ... 7-18 Appendices: Appendix A: BIOS POST Codes Appendix B: Software Installation...
Page 10 UPER ERVER 6014H-32 User's Manual Notes...
Page 11: Chapter 1: Introduction
Overview The Supermicro SuperServer 6014H-32 is a high-end dual processor, 1U rackmount server featuring some of the most advanced technology currently available. The SuperServer 6014H-32 is comprised of two main subsystems: the SC813T-500 1U rackmount chassis and the X6DHR-3G2 Xeon dual processor serverboard. Please refer to our web site for information on operating systems that have been certiﬁ...
Page 12: Serverboard Features
ERVER 6014H-32 User's Manual Serverboard Features At the heart of the SuperServer 6014H-32 lies the X6DHR-3G2 a dual Xeon pro- cessor serverboard designed to provide maximum performance. Below are the main features of the X6DHR-3G2. See Figure 1-1 for a system block diagram of the chipset.
Page 13: Ati Graphics Controller
ATI Graphics Controller An ATI video controller based on the Rage XL 8 MB graphics chip is integrated onboard the X6DHR-3G2. Rage XL fully supports sideband addressing and AGP texturing. This onboard graphics package can provide a bandwidth of up to 512 MB/sec over a 32-bit graphics memory bus.
Page 14: Server Chassis Features
The SC813T-500 chassis includes a single 500W cold-swap power supply. SAS/SATA Subsystem For the 6014H-32, the SC813T-500 chassis was designed to support four SAS or four SATA hard drives, which are hot-swappable units. Note: The operating system you use must have RAID support to enable the hot- swap capability of the SAS/SATA drives.
Page 15: System Block Diagram
Figure 1-1. Intel E7520 Chipset: System Block Diagram Note: This is a general block diagram. Please see Chapter 5 for details. PCI-E_(X8) Gbit LAN ANVIK 1_PCI-X133 SLOT--6 PCI-X BUS(133MHZ) PXH#2 PCI-X BUS(100MHZ) 1_PCI-X100 SLOT--7 PCI-E_(X8) SATA 4 Ports SOCKET PRI/SEC SATA 0, 1 USB PORTS...
Page 16: Contacting Supermicro
UPER ERVER 6014H-32 User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V.
Page 17: Chapter 2: Server Installation
Precautions in the next section. Preparing for Setup The box the SuperServer 6014H-32 was shipped in should include two sets of rail assemblies, two rail mounting brackets and the mounting screws you will need to install the system into the rack. Follow the steps in the order given to complete the installation process in a minimum amount of time.
Page 18: Choosing A Setup Location
UPER ERVER 6014H-32 User's Manual Choosing a Setup Location - Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches). - Leave approximately 30 inches of clearance in the back of the rack to allow for sufﬁ...
Page 19: Rack Mounting Considerations
Chapter 2: Server Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tem- perature of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equip- ment in an environment compatible with the manufacturer’s maximum rated ambient temperature (Tmra).
Page 20: Installing The System Into A Rack
This section provides information on installing the SuperServer 6014H-32 into a rack unit with the rack rails provided. If the 6014H-32 has already been mounted into a rack, you can skip ahead to Sections 2-5 and 2-6. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly.
Page 21: Installing The Chassis Rails
Chapter 2: Server Installation Installing the Chassis Rails Two of the chassis rails (Chassis Rail 1) should have already been preattached - one to each side of the chassis. Attach the second set of chassis rails (Chassis Rail 2) directly to the chassis with the screws provided. Chassis Rail 2 should be positioned just behind Chassis Rail 1 (see Figure 2-2).
Page 22: Installing The Server Into The Rack
UPER ERVER 6014H-32 User's Manual Installing the Server into the Rack You should now have rails attached to both the chassis and the rack unit. The next step is to install the server into the rack. Do this by lining up the rear of the chassis rails with the front of the rack rails.
Page 23: Installing The Server Into A Telco Rack
Chapter 2: Server Installation Installing the Server into a Telco Rack To install the SuperServer 6014H-32 into a Telco type rack, use two L-shaped brackets on either side of the chassis (four total). First, determine how far the server will extend out the front of the rack. Larger chassis should be positioned to balance the weight between front and back.
Page 24: Checking The Serverboard Setup
UPER ERVER 6014H-32 User's Manual Checking the Serverboard Setup After you install the 6014H-32 in the rack, you will need to open the unit to make sure the serverboard is properly installed and all the connections have been made. 1. Accessing the inside of the 6014H-32 (see Figure 2-5) First, release the retention screws that secure the unit to the rack.
Page 25: Checking The Drive Bay Setup
Figure 2-5. Accessing the Inside of the SuperServer 6014H-32 (with optional front bezel shown) Checking the Drive Bay Setup Next, you should check to make sure the peripheral drives and the SAS/SATA drives have been properly installed and all connections have been made.
Page 26 UPER ERVER 6014H-32 User's Manual 4. Check the airﬂ ow Airﬂ ow is provided by two heavy duty 10-cm blower fans. The system compo- nent layout was carefully designed to direct the airﬂ ow to the components that generate the most heat. Note that all power and data cables have been routed in such a way that they do not block the airﬂ...
Page 27: Chapter 3: System Interface
System Interface Overview There are several LEDs on the control panel as well as others on the SAS/SATA drive carriers to keep you constantly informed of the overall status of the system as well as the activity and health of speciﬁ c components. There are also two but- tons on the chassis control panel and an on/off switch on the power supply.
Page 28: Control Panel Leds
UPER ERVER 6014H-32 User's Manual Control Panel LEDs The control panel located on the front of the SC813T-500 chassis has ﬁ ve LEDs. These LEDs provide you with critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any corrective action you may need to take.
Page 29: Hdd
HDD: Indicates IDE channel activity. On the SuperServer 6014H-32 this light indicates SAS/SATA and/or CD-ROM drive activity when ﬂ ashing. Power: Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating.
Page 30 UPER ERVER 6014H-32 User's Manual Notes...
Page 31: Chapter 4: System Safety
Electrical Safety Precautions Basic electrical safety precautions should be followed to protect yourself from harm and the SuperServer 6014H-32 from damage: Be aware of the locations of the power on/off switch on the chassis as well as the room's emergency power-off switch, disconnection switch or electrical outlet.
Page 32: General Safety Precautions
General Safety Precautions Follow these rules to ensure general safety: Keep the area around the SuperServer 6014H-32 clean and free of clutter. The SuperServer 6014H-32 weighs approximately 38 lbs (17.3 kg) when fully loaded. When lifting the system, two people at either end should lift slowly with their feet spread out to distribute the weight.
Page 33: Esd Precautions
After accessing the inside of the system, close the system back up and secure it to the rack unit with the retention screws after ensuring that all connections have been made. ESD Precautions Electrostatic discharge (ESD) is generated by two objects with different electrical charges coming into contact with each other.
Page 34: Operating Precautions
Operating Precautions Care must be taken to assure that the chassis cover is in place when the 6014H-32 is operating to ensure proper cooling. Out of warranty damage to the 6014H-32 system can occur if this practice is not strictly followed.
Page 35: Chapter 5: Advanced Serverboard Setup
Advanced Serverboard Setup This chapter covers the steps required to install processors and heatsinks to the X6DHR-3G2 serverboard, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are described and a layout and quick reference chart are included in this chapter. Remember to close the chas- sis completely when you have ﬁ...
Page 36: Processor And Heatsink Installation
UPERSERVER 6014H-32 User’s Manual Processor and Heatsink Installation When handling the processor package, avoid placing direct pressure on the label area of the fan. Also, do not place the serverboard on a conductive surface, which can damage the BIOS battery and prevent the system from booting up.
Page 37 5. Screw in two diagonal screws until just snug (eg. screws #1 and #2 in Figure 5-2 - do not fully tighten), then do the same with the remaining two diagonal screws. Finish by fully tightening all four screws (see Figure 5-2). 6.
Page 38: Connecting Cables
UPERSERVER 6014H-32 User’s Manual Connecting Cables Now that the processors are installed, the next step is to connect the cables to the serverboard. These include the data (ribbon) cables for the peripherals and control panel and the power cables. Connecting Data Cables The ribbon cables used to transfer data from the peripheral devices have been carefully routed in preconﬁ...
Page 39: Connecting The Control Panel
Connecting the Control Panel JF1 contains header pins for various front control panel connectors. See Figure 5-3 for the pin locations of the various front control panel buttons and LED indi- cators. Please note that even and odd numbered pins are on opposite sides of each header.
Page 40: I/O Ports
Figure 5-4 below for the colors and locations of the various I/O ports. Figure 5-4. Rear Panel I/O Ports Installing Memory Note: Check the Supermicro web site for recommended memory modules. Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Also note that the memory is inter- leaved to improve performance (see step 1).
Page 41 Memory Support The X6DHR-3G2 supports up to 16 GB of registered ECC DDR2-400 SDRAM. You should not mix DIMMs of different sizes and speeds. See Figure 5-5 for installing and removing memory modules. Figure 5-5a. Installing DIMM into Slot Notch Release Note: Notches should align...
Page 42: Adding Pci Cards
Adding PCI Cards 1. PCI slots The 6014H-32 can accommodate add-on cards in both the PCI-X 133 MHz and the PCI-X 100 MHz slot with the use of two riser cards, which are included with the system: the CSE-RR1U-X riser supports a standard size card in slot #6 and the CSE-RR1U-XLP riser supports a low proﬁ...
Page 43: Serverboard Details
Serverboard Details Figure 5-6. SUPER X6DHR-3G2 Layout DIMM 1A DIMM 1B J 3 4 DIMM 2A USB 0/1 DIMM 2B DIMM 3A DIMM 3B DIMM 4A DIMM 4B GLAN Controller Slot 7: PCI-X 100 MHz Slot 6: PCI-X 133 MHz SuperIO P X H S P K R...
Page 44: X6Dhr-3G2 Quick Reference
UPERSERVER 6014H-32 User’s Manual X6DHR-3G2 Quick Reference Jumper Description 3rd Power Supply Detect JBT1 CMOS Clear JP17/JP18 Compact Flash Master/Slave Select JPG1 VGA Enable/Disable JPL1 JLAN Enable/Disable JPS1 SAS Enable/Disable Watchdog Connector Description COM1/COM2 COM1/COM2 Serial Port/Header FAN1-5 System Fan Headers IPMI IPMI 2.0 Socket...
Page 45: Connector Deﬁ Nitions
Connector Deﬁ nitions ATX Power Connection The power supply connector meets the SSI (Superset ATX) 20-pin speciﬁ - cation. Make sure that the orientation of the connector is correct. See the table on the right for pin deﬁ nitions. PWR_SEC Connection In addition to the Primary ATX power connector (above), the Secondary 12v 8-pin J15 connector (J38) must...
Page 46: Hdd Led
UPERSERVER 6014H-32 User’s Manual HDD LED The HDD (IDE Hard Disk Drive) LED connection is located on pins 13 and 14 of JF1. Attach the IDE hard drive LED cable to display disk activity. Refer to the table on the right for pin deﬁ...
Page 47: Reset Button
Reset Button The Reset Button connection is lo- cated on pins 3 and 4 of JF1. Attach it to the hardware reset switch on the computer case. Refer to the table on the right for pin deﬁ nitions. Power Button The Power Button connection is located on pins 1 and 2 of JF1.
Page 48: Serial Ports
UPERSERVER 6014H-32 User’s Manual Serial Ports The COM1 serial port is located beside the mouse port. COM2 is a header on the serverboard (see serverboard layout for location). See the table on the right for pin deﬁ nitions. Power Supply Fail Header...
Page 49: Power Led/Speaker
Extra Universal Serial Bus Headers Two additional USB headers (USB2/3) are located near the WWD jumper on the serverboard. These are included for connection to the ports on the front of the chassis. A USB cable (not included) is needed for the con- nection.
Page 50: Wake-On-Lan
UPERSERVER 6014H-32 User’s Manual Wake-On-LAN The Wake-On-LAN header is desig- nated WOL. See the table on the right for pin deﬁ nitions. You must enable the LAN Wake-Up setting in BIOS to use this feature. You must also have a LAN card with a Wake-on-LAN con- nector and cable.
Page 51: Jumper Settings
Jumper Settings Explanation of Jumpers To modify the operation of the serverboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function of the connector. Pin 1 is identiﬁ ed with a square solder pad on the printed circuit board.
Page 52: Jlan Enable/Disable
UPERSERVER 6014H-32 User’s Manual JLAN Enable/Disable Change the setting of jumper JPL1 to enable or disable the JLAN1 and JLAN2 Ethernet ports. See the table on the right for jumper settings. The default setting is enabled 3rd Power Supply Fail Detect...
Page 53: Watch Dog Enable/Disable
Watch Dog Enable/Disable JWD controls the Watch Dog function. Watch Dog is a system monitor that can reboot the system when a software application hangs. Pins 1-2 will cause WD to reset the system if an applica- tion hangs. Pins 2-3 will generate a non-maskable interrupt signal for the application that is hung up.
Page 54: 5-10 Onboard Indicators
UPERSERVER 6014H-32 User’s Manual 5-10 Onboard Indicators JLAN1/JLAN2 LEDs The Ethernet ports (located beside the VGA port) have two LEDs. On each Gigabit LAN port, the yellow (right) LED indicates activity while the left LED may be green, orange or off to indicate the speed of the connec- tion.
Page 55: 5-11 Sata, Floppy And Hard Drive Connections
5-11 SATA, Floppy and Hard Drive Connections Note the following when connecting the ﬂ oppy and hard disk drive cables: • The ﬂ oppy disk drive cable has seven twisted wires. • A red mark on a wire typically designates the location of pin 1. •...
Page 56: Ide Connectors
UPERSERVER 6014H-32 User’s Manual IDE Connectors See the table on the right for pin deﬁ nitions for the onboard IDE#1 and #2 connectors. SATA Connectors See the table on the right for pin deﬁ nitions for the onboard SATA connectors.
Page 57: Chapter 6: Advanced Chassis Setup
Advanced Chassis Setup This chapter covers the steps required to install components and perform mainte- nance on the SC813T-500 chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the next step. Tools Required The only tool you will need to install components and perform maintenance is a Philips screwdriver.
Page 58: Control Panel
UPER ERVER 6014H-32 User's Manual Figure 6-1. Chassis: Front and Rear Views Slim CD-ROM Drive Power Supply Module USB Ports Mouse/Keyboard COM1 Port Control Panel The control panel (located on the front of the chassis) must be connected to the JF1 connector on the serverboard to provide you with system status indications.
Page 59: System Fans
Replace the failed fan with an identical 10-cm, 12 volt fan (available from Supermicro: p/n FAN-0059). Install the new fan in its proper place in the chassis by positioning it on the two mounting posts. Secure the fan to the chassis with the screws you removed previously, then attach the fan wires to the same chassis fan header you removed it from.
Page 60: Drive Bay Installation/Removal
UPER ERVER 6014H-32 User's Manual 10-cm Blower Fans Figure 6-2. System Cooling Fans (with optional front bezel shown) Drive Bay Installation/Removal Removing the Front Bezel If your system has a front bezel (optional) attached to the chassis, you must ﬁ rst remove it to gain access to the drive bays.
Page 61: Accessing The Drive Bays
CD-ROM/Floppy Disk Drives: For installing/removing a CD-ROM or ﬂ oppy disk drive, you will need to gain access to the inside of the 6014H-32 by removing the top cover of the chassis. Proceed to the "CD-ROM and Floppy Drive Installation"...
Page 62: Sas/Sata Drive Installation
UPER ERVER 6014H-32 User's Manual SAS/SATA Drive Installation 1. Mounting a SAS/SATA drive in a drive carrier The SAS/SATA drives are mounted in drive carriers to simplify their installation and removal from the chassis. These carriers also help promote proper airﬂ ow for the SAS/SATA drive bays.
Page 63 2. Installing/removing hot-swap SAS/SATA drives The SAS/SATA drive carriers are all easily accessible at the front of the chassis. These hard drives are hot-pluggable, meaning they can be removed and installed without powering down the system. To remove a carrier, push the release button located beside the drive LEDs.
Page 64: Cd-Rom And Floppy Drive Installation
The top cover of the chassis must be opened to gain full access to the CD-ROM and ﬂ oppy drive bays. The 6014H-32 accomodates only slim-line CD-ROM drives. Side mounting brackets are needed to mount a slim-line CD-ROM drive in the 6014H-32 server.
Page 65: Power Supply
If the power supply unit fails, the system will shut down and you will need to replace the unit. Replacement units can be ordered directly from Supermicro (see contact information in the Preface). As there is only one power supply unit in the 6014H-32, power must be completely removed from the server before removing and replacing the power supply unit for whatever reason.
Page 66 UPER ERVER 6014H-32 User's Manual Figure 6-6. Removing/Replacing the Power Supply 6-10...
Page 67: Chapter 7: Bios
Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual. Please refer to Supermicro's web site: <http://www.supermicro.com> for any changes to BIOS that may not be reﬂ...
Page 68: Running Setup
UPER ERVER 6014H-32 User's Manual Running Setup *Default settings are in bold text unless otherwise noted. The BIOS setup options described in this section are selected by choosing the appropriate text from the main BIOS Setup screen. All displayed text is described in this section, although the screen display is often all you need to understand how to set the options (see on next page).
Page 69: Main Bios Setup Menu
Chapter 7: BIOS Main BIOS Setup Menu Main Setup Features System Time To set the system date and time, key in the correct information in the appropriate ﬁ elds. Then press the <Enter> key to save the data. System Date Using the arrow keys, highlight the month, day and year ﬁ...
Page 70 UPER ERVER 6014H-32 User's Manual Legacy Diskette A This setting allows the user to set the type of ﬂ oppy disk drive installed as diskette A. The options are Disabled, 360Kb 5.25 in, 1.2MB 5.25 in, 720Kb 3.5 in, 1.44/1.25MB, 3.5 in and 2.88MB 3.5 in.
Page 71 to select a pre-determined HDD type. Select CD-ROM if a CD-ROM drive is installed. Select ATAPI if a removable disk drive is installed. Multi-Sector Transfers Select the number of transfer sectors. The options are Disabled, 2, 4, 6, 8 and 16 Sectors.
Page 72: Advanced Setup
UPER ERVER 6014H-32 User's Manual Advanced Setup Choose Advanced from the Phoenix BIOS Setup Utility main menu with the arrow keys. You should see the following display. The items with a triangle beside them have sub menus that can be accessed by highlighting the item and pressing <Enter>.
Page 73 ACPI Mode Use the setting to determine if you want to employ ACPI (Advanced Conﬁ guration and Power Interface) power management on your system. The options are Yes and No. Power Button Behavior If set to Instant-Off, the system will power off immediately as soon as the user hits the power button.
Page 74 UPER ERVER 6014H-32 User's Manual Cache Base 0-512K If enabled, this feature will allow the data stored in the base memory area: block 0-512K to be cached (written) into a buffer, a storage area in the Static DRM (SDROM) or written into L1, L2, L3 cache inside the CPU to speed up CPU operations .
Page 75 PCI Conﬁ guration Access the submenu to make changes to the following settings for PCI devices. Onboard GLAN (Gigabit- LAN) OPROM Conﬁ gure Enabling this option provides the capability to boot from GLAN. The options are Disabled and Enabled. Default Primary Video Adapter This option allows the user to decide which video adapt is the default primary video adapter for the system.
Page 76 UPER ERVER 6014H-32 User's Manual Enable Master This setting allows you to enable the selected device as the PCI bus master. The options are Enabled and Disabled. Latency Timer This setting allows you to set the clock rate for Bus Master.A high-priority, high- throughout device may beneﬁ...
Page 77 Chapter 7: BIOS ECC Error Type This setting lets you select which type of interrupt to be activated as a result of an ECC error. The options are None, NMI (Non-Maskable Interrupt), SMI (System Management Interrupt) and SCI (System Control Interrupt.) SERR Signal Condition This setting speciﬁ...
Page 78 UPER ERVER 6014H-32 User's Manual No Execute Mode Memory Protection (*Available when supported by the CPU.) Enable this feature to enable the functionality of Execute Disable Bit and allow the processor to classify areas in the memory where an application code can execute and where it cannot, and thus preventing a worm or a virus from inserting and creating a ﬂ...
Page 79 I/O Device Conﬁ guration Access the submenu to make changes to the following settings. KBC Clock Input This setting allows you to set the clock frequency for the Keyboard Clock. The options are 6MHz, 8MHz, 12 MHz and 16MHz. On-board COM 1 This setting allows you to assign control of serial port A.
Page 80 UPER ERVER 6014H-32 User's Manual DMI Event Logging Access the submenu to make changes to the following settings. Event Log Validity This is a display, not a setting, informing you of the event log validity. Event Log Capacity This is a display, not a setting, informing you of the event log capacity.
Page 81 Console Connection Select the console connection: either Direct or Via Modem. Continue CR after POST This option allows the user to decide whether to continue with console redirection after the POST routine. The options are On and Off. Hardware Monitor Logic CPU Temperature Threshold This option allows the user to set a CPU temperature threshold that will activate the alarm system when the CPU temperature reaches this pre-set temperature...
Page 82: Security
UPER ERVER 6014H-32 User's Manual Security Choose Security from the Phoenix BIOS Setup Utility main menu with the arrow keys. You should see the following display. Security setting options are displayed by highlighting the setting using the arrow keys and pressing <Enter>. All Security BIOS settings are described in this section.
Page 83: Boot
Chapter 7: BIOS Set User Password When the item "Set User Password" is highlighted, hit the <Enter> key. When prompted, type the user's password in the dialogue box to set or to change the user's password, which allows access to the system at boot-up. Fixed Disk Boot Sector This setting may offer some protection against viruses when set to Write Protect, which protects the boot sector on the hard drive from having a virus written to it.
Page 84: Exit
UPER ERVER 6014H-32 User's Manual +Removable Devices Highlight and press <Enter> to expand the ﬁ eld. See details on how to change the order and specs of devices in the Item Speciﬁ c Help window. CD-ROM Drive See details on how to change the order and specs of the CD-ROM drive in the Item Speciﬁ...
Page 85 Chapter 7: BIOS Exit Saving Changes Highlight this item and hit <Enter> to save any changes you made and to exit the BIOS Setup utility. Exit Discarding Changes Highlight this item and hit <Enter> to exit the BIOS Setup utility without saving any changes you may have made.
Page 86 UPER ERVER 6014H-32 User's Manual Notes 7-20...
Page 87: Appendix A: Bios Post Codes
Appendix A BIOS POST Codes This section lists the POST (Power On Self Test) codes for the PhoenixBIOS. POST codes are divided into two categories: recoverable and terminal. Recoverable POST Errors When a recoverable type of error occurs during POST, the BIOS will display an POST code that describes the problem.
Page 88 UPERSERVER 6014H-32 User’s Manual POST Code Description 8254 timer initialization 8237 DMA controller initialization Reset Programmable Interrupt Controller 1-3-1-1 Test DRAM refresh 1-3-1-3 Test 8742 Keyboard Controller Set ES segment register to 4 GB Auto size DRAM Initialize POST Memory Manager...
Page 89 POST Code Description Test RAM between 512 and 640 kB Test extended memory Test extended memory address lines Jump to UserPatch1 Conﬁ gure advanced cache registers Initialize Multi Processor APIC Enable external and CPU caches Setup System Management Mode (SMM) area Display external L2 cache size Load custom defaults (optional) Display shadow-area message...
Page 90 UPERSERVER 6014H-32 User’s Manual POST Code Description Check for SMART Drive (optional) Shadow option ROMs Set up Power Management Initialize security engine (optional) Enable hardware interrupts Determine number of ATA and SCSI drives Set time of day Check key lock...
Page 91 POST Code Description Re-map I/O and memory for PCMCIA Initialize digitizer and display message Unknown interrupt The following are for boot block in Flash ROM POST Code Description Initialize the chipset Initialize the bridge Initialize the CPU Initialize system timer Initialize system I/O Check force recovery boot Checksum BIOS ROM...
Page 92 UPERSERVER 6014H-32 User’s Manual Notes...
Page 93: Appendix B: Software Installation
Appendix B: Software Installation Appendix B Software Installation B-1 Introduction to the Adaptec SATA RAID Controller Serial ATA (SATA) Serial ATA(SATA) is a physical storage interface. It uses a single cable with a minimum of four wires to create a point-to-point connection between devices. It is a serial link which supports SATA Transfer rates from 150MBps.
Page 94 UPERSERVER 6014H-32 User’s Manual Combined Mode In this mode, system BIOS assigns the traditional IRQ 14 and IRQ 15 for the use of HDD. Up to 4 ATA devices are supported by this mode. Within the Combined Mode, the following three modes are supported: *Non-Combined Mode: Parallel ATA only:with the maximum of 4 devices sup- ported;...
Page 95 Appendix B: Software Installation Conﬁ guring BIOS settings for the SATA RAID Functions (Enhanced Mode) 1. Press the <Del> key during system bootup to enter the BIOS Setup Utility. (If it is the ﬁ rst time to power on the system, we recommend that you load the Opti- mized Default Settings.
Page 96 I/O throughput and providing data accessibility regardless of a single disk failure. By incorporating the Adaptec Embedded Serial ATA into the motherboard design, Supermicro's X6DH3-G2 offers the user with the beneﬁ ts of SATARAID without the high costs associated with hardware RAID applications.
Page 97 Appendix B: Software Installation Managing Arrays Select this option to view array properties, and delete arrays. The following sec- tions describe the operations Of "Managing Arrays". To select this option, use the arrow keys and the <enter> key to select "Managing Arrays"...
Page 98 UPERSERVER 6014H-32 User’s Manual Viewing Array Properties To view the properties of an existing array: 1. At the BIOS prompt, press Ctrl+A. 2. From the ARC menu, select Array Conﬁ guration Utility (ACU). 3. From the ACU menu, select Manage Arrays (as shown on the previous screen.) 4.
Page 99 Appendix B: Software Installation Creating Arrays Before creating arrays, make sure the disks for the array are connected and installed in your system. Note that disks with no usable space, or disks that are un- initialized are shown in gray and cannot be used. See Initializing Disk Drives.
Page 100 UPERSERVER 6014H-32 User’s Manual Assigning Array Properties Once you've create a new array, you are ready to assign the properties to the array. Caution: Once the array is created and its properties are assigned, you cannot change the array properties using the ACU. You will need to use the Adaptec Stor- age Manager - Browser Edition.
Page 101 3. For RAID 0, select the desired stripe size. (*Note: Available stripe sizes are 16, 32, and 64 KB-default. It is recommended that you do not change the default setting.) 4. The item: "Create RAID via" allows you to select between the different creating methods for RAID 0 and RAID 1.
Page 102 UPERSERVER 6014H-32 User’s Manual Notes: 1. Before adding a new drive to an array, back up any data contained on the new drive. Otherwise, all data will be lost. 2. If you stop the Build or Clear process on a RAID 1 from ACU, you can restart it by pressing Ctrl+R.
Page 103 Appendix B: Software Installation Adding a Bootable Array To make an array bootable: 1. From the Main menu, select Manage Arrays. 2. From the List of Arrays, select the array you want to make bootable, and press Ctrl+B. 3. Enter Y to create a bootable array when the following message is displayed: "This will make all other existing bootable array non-bootable.
Page 104 UPERSERVER 6014H-32 User’s Manual Initializing Disk Drives If an installed disk does not appear in the disk selection list for creating a new ar- ray, or if it appears grayed out, you may have to initialize it before you can use it as part of an array.
Page 105 Appendix B: Software Installation 4. Use the up and down arrow keys to select the disk you wish to initialize and press Insert (as shown in the screen below). B-13...
Page 106 UPERSERVER 6014H-32 User’s Manual 5. Repeat Step 4 so that both drives to be initialized are selected (as shown below). 6. Press Enter. 7. Read the warning message as shown below. 8. Make sure that you have selected the correct disk drives to initialize. If correct, type Y to continue.
Page 107 Appendix B: Software Installation Rebuilding Arrays Note 1: Rebuilding applies to Fault Tolerant array (RAID 1) only. If an array Build process (or initialization) is interrupted or critical with one member missing, you must perform a Rebuild to get the array to Optimal status. For a criti- cal array Rebuild operation, the optimal drive is the source drive.
Page 108 * The SAS Cable (CBL-097) can only be used with backplanes that support both SAS and SATA. * If Supermicro's chassis is used, the backplane must be Rev.2.0 or above, which came with gold trims. * If you want to use this motherboard with Supermicro's SAS Mobile Racks, such as CSE-M28E1, make sure to use Cable CBL-0116.
Page 109: Managing Arrays
Appendix B: Software Installation Managing Arrays Select this option to view array properties, and delete arrays. The following sec- tions describe the operations Of "Managing Arrays". To select this option, use the arrow keys and the <enter> key to select "Managing Arrays"...
Page 110 UPERSERVER 6014H-32 User’s Manual Deleting Arrays Warning: Back up the data on an array before you delete it to prevent the loss of data. Deleted arrays cannot be restored. To delete an existing array: 1. Turn on your computer and press Ctrl+A when prompted to access the ARC utility.
Page 111 Assigning Array Properties Once you've create a new array, you are ready to assign the properties to the array. Caution: Once the array is created and its properties are assigned, you cannot change the array properties using the ACU. You will need to use the Adaptec Stor- age Manager - Browser Edition.
Page 112 UPERSERVER 6014H-32 User’s Manual 3. A RAID 1 created using the Quick Init option may return some data mis-com- pares if you later run a consistency check. This is normal and is not a cause for concern. 4. The ACU allows you to use drives of different sizes in a RAID . However, during a build operation, only the smaller drive can be selected as the source or ﬁ...
Page 113 Appendix B: Software Installation Initializing Disk Drives If an installed disk does not appear in the disk selection list for creating a new array, or if it appears grayed out, you may have to initialize it before you can use it as part of an array.
Page 114 UPERSERVER 6014H-32 User’s Manual Using the SerialSelect Utility to Conﬁ gure SAS Settings The SerialSelect Utility enables you to conﬁ gure SAS disk drive settings. To access the SAS utilities: 1. Turn on your computer and press Ctrl+A when prompted to access the ARC util- ity.
Page 115 Appendix B: Software Installation To set the controller conﬁ guration: 3. Select "Controller Conﬁ guration" and press <Enter> to access the submen as shown below: 4. Use the arrow keys to select an item. Then, press <Enter> and the arrow keys to conﬁ...
Page 116 UPERSERVER 6014H-32 User’s Manual To Set the Physical Conﬁ guration: 1. Turn on the computer and press Ctrl+A when prompted to access the ARC util- ity. 2. Use the arrow keys to select "SerialSelect Utility" and press <Enter> to access the Physical Conﬁ...
Page 117: Using The Disk Utilities
Appendix B: Software Installation 4. Use the arrow keys to select an item. Then, press <Enter> and the arrow keys to conﬁ gure the item selected. 5. To load default settings, press <F6>. 6. Press <Esc> to return to the previous menu and to exit the utility. Using the Disk Utilities The Disk Utilities enable you to format or verify the media of your Serial ATA hard disks.
Page 118 UPERSERVER 6014H-32 User’s Manual 2. Verify Disk Media—Scans the media of a disk drive for defects. To Exit Adaptec RAID Conﬁ guration Utility 1. Once you have completed RAID array conﬁ gurations, press ESC to exit. The following screen will appear.
Page 119 Appendix B: Software Installation B-2 Installing the 6300ESB/SAS Driver and the OS a. Insert Supermicro's bootable CD that came with the package into the CD Drive during the system reboot, and the screen:"Super Micro Driver Diskette Maker" will appear. b. From the list displayed on the screen, choose the item: "Intel 6300 ESB/ICH5R Driver by 3rd Party (Adaptec)"...
Page 120 UPERSERVER 6014H-32 User’s Manual B-3 Installing Other Software Programs and Drivers A. Installing Drivers other than Adaptec Embedded Serial ATA RAID Controller Driver After you've installed Windows Operating System, a screen as shown below will appear. You are ready to install software programs and drivers that have not yet been installed.
Page 121 Appendix B: Software Installation Supero Doctor III The Supero Doctor III program is a Web base management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called SD III Client. The Supero Doctor III program included on the CDROM that came with your motherboard allows you to monitor the environment and operations of your system.
Page 122 Supero Doctor III Interface Display Screen-II (Remote Control) Notes: 1. SD III Software Revision 1.0 can be downloaded from our Web site at: ftp://ftp.supermicro.com/utility/Supero_Doctor_III/. You can also download SDIII User's Guide at: http://www.supermicro.com/PRODUCT/Manuals/SDIII/UserGuide. pdf. For Linux, we will still recommend Supero Doctor II. 2. For detailed infor- mation on Adaptec's SCSI SATA RAID Utility, please refer to the CDs that came with your motherboard.
Page 123: Appendix C: System Speciﬁ Cations
Appendix C: System Speciﬁ cations Appendix C System Speciﬁ cations Processors Single or dual Intel® Xeon™ 604-pin processors to 3.60 GHz at a front side (system) bus speed of 800 MHz. Note: Please refer to our web site for a complete listing of supported processors. Chipset Intel E7520 chipset BIOS...
Page 124 UPER ERVER 6014H-32 User's Manual Expansion Slots (provided with included riser cards) One (1) 64-bit 133 MHz standard size PCI-X slot and one (1) 64-bit 66 MHz low proﬁ le PCI-X slot (with CSE-RR1U-X and CSE-RR1U-XLP riser cards) An additional two riser cards are available as an option to support add-on cards in the SXB-E1 and SXB-E2 x8 (PCI-Express) slots (CSE-RR1U-EL and CSE-RR1U-ELP).
Page 125 Appendix C: System Speciﬁ cations Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55022 Class A, EN 61000-3-2/-3-3, CISPR 22 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: EN 60950/IEC 60950-Compliant, UL Listed (USA), CUL Listed (Canada), TUV Certiﬁ...
Page 126 UPER ERVER 6014H-32 User's Manual Notes...
