30" AND 36" ISLAND-MOUNT RANGE HOOD
Universal Installation Instructions and Use & Care Guide
Model:
627I
680I
668I
GVA-I
668IS2 GVC-I
610I
GVA-IS2
688I
GVAIS-3
9007
IMPORTANT: READ AND SAVE THESE INSTRUCTIONS.
FOR RESIDENTIAL USE ONLY.
Revised September 2014
Disclaimer: Item purchased may be slightly different from the manual.
For questions about features, operation/performance parts, accessories or service, call:
1-626-453-0550
1
Advertisement
Table of Contents
Related Manuals for Sears 627I
Summary of Contents for Sears 627I
- Page 1 30" AND 36" ISLAND-MOUNT RANGE HOOD Universal Installation Instructions and Use & Care Guide For questions about features, operation/performance parts, accessories or service, call: 1-626-453-0550 Model: 627I 680I 668I GVA-I 668IS2 GVC-I 610I GVA-IS2 688I GVAIS-3 9007 IMPORTANT: READ AND SAVE THESE INSTRUCTIONS.
-
Page 2: Table Of Contents
TABLE OF CONTENTS RANGE HOOD SAFETY ..............2 INSTALLATION REQUIREMENTS ...........4 Tools and Parts Requirements ...........4 Location Requirements .............4 Installation Dimensions ............5 Venting Requirements ..............6 Electrical Requirements ............7 INSTALLATION INSTRUCTIONS ..........8 Prepare Location ..............8 Install Range Hood ..............13 Connect Vent System .............13 Complete Installation ..............13 RANGE HOOD USE .................15 Range Hood Controls ..............16... - Page 3 IMPORTANT SAFETY INSTRUCTIONS WARNING: TO REDUCE THE RISK OF A RANGE TOP WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC GREASE FIRE, READ THE FOLLOWING: SHOCK, OR INJURY TO PERSONS, READ THE FOLLOWING: Never leave surface units unattended at high settings. ■...
-
Page 4: Installation Requirements
INSTALLATION REQUIREMENT TOOLS AND PARTS REQUIREMENTS Electrical drill or ratchet driver 1/2” drill bit for drilling pilot holes 1 ¼” drill bit for drilling electrical wiring access hole. Screwdrivers: Philips & Straight blade Pliers Tape measure or ruler and pencil Electrical supplies for wiring Aluminum foils tape and/or duct tape Hammer... -
Page 5: Location Requirements
LOCATION REQUIREMENTS IMPORTANT: Observe all governing codes and ordinances. Have a qualified technician install the range hood. It is the installer’s responsibility to comply with installation clearances specified on the model/serial rating plate. Canopy hood's location should be away from strong draft areas, such as windows, doors, and strong heating vents. -
Page 6: Installation Dimensions
INSTALLATION DIMENSIONS A. Countertop height B. Hood height from ceiling to bottom of the range hood filter surface: D-A-C=B C. 29” (73.66 cm) min. from cooking surface, suggested 31” (78.74 cm) max. D. Ceiling height... - Page 7 VENTILATION REQIUREMENTS Venting Method ■ Range hoods must be ventilated to the This canopy hood is factory set for through outdoors, except for non-vented the roof or wall. (recirculating) installations. ■ Do not ventilate the range hood into an attic or other enclosed areas. A 6"...
-
Page 8: Electrical Requirements
Calculating Vent System ELECTRICAL Length REQIUREMENTS Observe all governing codes and ordinances. To calculate the length of the system you need, Ensure that the electrical installation is adequate add the equivalent feet (meters) for all vent and in conformance with the National Electrical pieces used in the system. -
Page 9: Installation Instructions
INSTALLATION INSTRUCTIONS PREPARE LOCATION ■ Lay out the vent duct system before installing the range hood to determine the best routing for the vent duct. ■ It is recommended that the vent system be installed before the range hood is installed. ■... - Page 10 Complete Preparation Determine the required location for the home power supply cable and drill a ½" (1.3 cm) diameter hole for wire access. Run ½" (1.3 cm) conduit and wires or home power supply cable according to the National Electrical Code or CSA Standards and local codes and ordinances.
- Page 11 Install the inner support frame to the holes on the range hood body with M4*12 screws. 7. Remove all protective film from the duct cover. 8. Attach inner (Upper) duct cover into outer (Lower) duct cover...
- Page 12 8. Install Inner and outer duct covers on the range hood body 9. Install the outer support frame on to the ceiling with four 7.5*52 drywall anchors and M5*60 screws.
-
Page 13: Install Range Hood
INSTALL RANGE HOOD Using 2 or more people lift the range hood assembly and attach it to the mounting bracket with M4*9. Excessive Weight Hazard Use two or more people to move and install range hood. Failure to do so can result in back or other injury. Install M4*12 screws on both side and tighten to secure. -
Page 14: Complete Installation
COMPLETE INSTALLATION(FOR NON- VENTED(RECIRCULATING) INSTALLATION ONLY Step 1: Do not install exhaust pipe, remove the grease filters, and locate the blower inside the hood Step 2: Attach the carbon filters to both sides of the blower Step 3: Twist the carbon filter until it is in the locking position Step 4: Reinstall the grease filters, reconnect the power. -
Page 15: Range Hood Use
RANGE HOOD USE The range hood is designed to remove smoke, vapors, and odors. For best results, start the hood before cooking. After, the cooking process is complete, allow the range hood to run for several minutes to completely clear all the smoke and odors from the kitchen. A. -
Page 16: Range Hood Controls
RANGE HOOD CONTROLS Operating the lights The On/Off light button controls both lights. Press once for on and again for off. Operating the blower The blower speed buttons turn the blower on and control the blower speed and sound level for quiet operation. -
Page 17: Range Hood Care
RANGE HOOD CARE Cleaning IMPORTANT: Clean the hood and grease filters frequently according to the following instructions. Replace panel filters before operating hood. Exterior Surfaces To avoid damage to the exterior surface, do not use steel wool or soap-filled scouring pads. Always wipe dry to avoid water marks. - Page 18 Non-Vented (recirculating) Installation Filters: The carbon filter is not washable. It should last up to 6 months with normal use. For replacement, please visit our website www.shoprangehoods.com Replacing the LED/Halogen light Turn off the range hood and allow the LED/Halogen to cool. To avoid damage or decreasing the life of the new bulb, do not touch bulb with bare fingers.
-
Page 19: Trouble Shooting
TROUBLE SHOOTING Potential Effect of Potential Cause(s) Recommended Action(s) Failure Lamp does not turn Electronic Control a) Pressing any key the LCD lights up and does not work. Due to icons are in place? Over Voltage Yes, Proceed with the following diagnostic sequence No, Replace the control and user interface. - Page 20 - Hold and press main connectors attached in the white plastic. - Push inwards the motor/lamp connectors until the locking system on connectors is well attached. 5) Connect hood to power supply and verify. The blower is Filters are dirty 1) Verify that the grease and/or charcoal too noisy filters are clean.
- Page 21 SHOPRANGEHOODS.COM MAJOR APPLIANCE WARRANTY LIMITED WARRANTY For three year from the date of purchase, when this major appliance is operated and maintained according to instructions attached to or furnished with the product, Www.shoprangehoods.com will pay for Factory Specified Parts. This limited warranty is valid only in the United States or Canada and applies only when the major appliance is used in the country in which it was purchased.
