OWNER'S MANUAL
MOTORCYCLE
YZF660N/YZF690N (YZF-R7)
Read this manual carefully
before operating this vehicle.
BEB-28199-20
For your safety - pre-operation checks
1
2
3
4
5
6
7
8
9
10
11
