Summary of Contents for Citizen Eco-Drive Historische JR4046-03E

  • Page 5 Please charge the watch fully before use by exposing it to light. When the watch does not operate according to the instruction manual, it is insufficiently charged. Charge the watch for at least 3 hours approximately 20 cm (8 in) away from a fluorescent or incandescent lamp (30 W) as a light source.

  • Page 6: Table Of Contents

    Contents 1. Features ....................4 2. Before Using the Watch ................5 3. Names of Components and Major Functions ........6 4. Switching Modes (Display Functions) ..........10 5. Checking 0-Position of Each Hand ............11 6. Accessing Times and Dates of Major Cities around the World ..15 7.
  • Page 7 15. Using Zone Setting ................39 16. About All-Reset ..................40 17. Functions Unique to Eco-Drive Watches ..........42 · Insufficient Charge Warning Function · Time Setting Warning Function · Overcharging Prevention Function · Power Save 1 · Power Save 2 18.

  • Page 8: Features

    1. Features This watch is a combination solar-powered watch that contains a solar cell in its face that drives the watch hands, race timer, chronograph, alarm, and numerous other functions by converting light energy into electrical energy. It is also equipped with convenient functions including a power save mode that reduces power consumption when light is not shining on the solar cell, UTC (Coordinated Universal Time) and a world timer indicating the time and dates of 30 major cities around the world.

  • Page 9: Before Using The Watch

    2. Before Using the Watch This watch is a solar-powered watch. Before using, allow light to shine onto the watch so that it is sufficiently charged. In this watch a rechargeable cell is used to store electrical energy. This rechargeable cell is a clean energy battery that does not contain mercury or other toxic substances.

  • Page 10: Names Of Components And Major Functions

    3. Names of Components and Major Functions Name/Mode Time Calendar Race timer Chronograph 1. Mode hand RACE 2. Hour hand Always indicates “hours” 3. Minute hand Always indicates “minutes” Indicates the remaining Indicates the race time (seconds) chronograph 4. Second hand Always indicates “seconds”...
  • Page 11 Timer Alarm-1 Alarm-2 Zone setting AL-1 AL-2 Always indicates “hours” Always indicates “minutes” Always indicates “seconds” Always indicates “24-hour time” in conjunction with hours and minutes Always stopped at 0-position (standard position) Indicates the timer’s remaining time Hours, minutes, alarm (ON/OF) City name (SET/OFF) (minutes, seconds) City name...
  • Page 12 Name/ Crown Time Calendar Race timer Chronograph Mode position Normal Mode switching position 9. Crown Race Timer Time correction Calendar Adjust to 0 set time click Calendar corr correction position correction Normal Changing between cities Start/stop Start/stop position Switching Button (A) Switching location to be corrected ------ location to be...
  • Page 13 Timer Alarm-1 Alarm-2 Zone setting Mode switching Timer set time correction Alarm time correction Changing city name Start/stop Changing between cities Changing city name ------ Switching location to be corrected ------ Return flight / reset Changing between cities Changing city name Changing city name ------ Switching alarm (ON/OF)

  • Page 14: Switching Modes (Display Functions)

    4. Switching Modes (Display Functions) In addition to the time and date modes, this watch is also equipped with a race timer, a chronograph and a timer mode and alarm-1 and 2 modes. Switch modes by turning the crown. Check the current mode using the mode hand.

  • Page 15: Checking 0-Position Of Each Hand

    5. Checking 0-Position of Each Hand Before using this watch perform the following procedure to check that the 0- position (standard position of each hand) is set correctly to ensure that the functions of the watch operate properly. <0-Position Check> 1.
  • Page 16 < 0-Position Correction (Setting to the Watch Standard Position) > ... Setting when the 0-position is out of algnment When setting the 0-position of each hand, always make sure to turn the crown to the right (clockwise) to set each hand to its 0-position in the clockwise direction. 1.
  • Page 17 Notes: 1. When the date is set for any one city, the dates of other cities, including UTC time, are corrected automatically. 2. The year can be set from 2001 to 2099. 3. The day is corrected automatically when the year, month and date are set. 4.
  • Page 18 <Normal Chronograph <0-Position (Standard Position) Display> Correction State> Crown pulled out to the first click Function hand Minute hand/hour hand/ 24-hour hand Crown returned to normal position Second hand...

  • Page 19: Accessing Times And Dates Of Major Cities Around The World

    6. Accessing Times and Dates of Major Cities around the World The time or date of major cities pre-registered in this watch can be easily accessed by pressing the buttons. <Access Procedure> 1. Turn the crown to set the mode hand to the [TME] time or [CAL] calendar mode.
  • Page 20 <Cities and UTC Time Differences Pre-registered in this Watch> Daylight Daylight Display Time Display Time on watch City name savings on watch City name savings difference difference time time × Universal time constant ±0 Tokyo ○ ○ London ±0 Sydney ○...

  • Page 21: Switching Between Analog Time And Digital Time

    7. Switching between Analog Time and Digital Time Since the time is corrected with the digital display of this watch, you can switch between the analog time and digital time. <Switching Procedure> 1. Turn the crown to set the mode hand to the time [TME] mode. 2.
  • Page 22 Press Pressing buttons (A) and (B) simultaneously Press Analog time: 10:10 AM (Tokyo: TYO) Analog time: 8:10 PM (New York: NYC) Digital time: 8:10 PM (New York: NYC) Digital time: 10:10 AM (Tokyo: TYO)

  • Page 23: Hand Evacuation Function

    8. Hand Evacuation Function (When reading the time is difficult because the analog hands cover the digit al display) The hand evacuation function allows the hour hand and the minute hand to be evacuated to the 12 o’clock position. <Hand Evacuation Method> 1.

  • Page 24: Setting The Time

    9. Setting the Time The analog time cannot be corrected by operating the crown. It can only be corrected with the digital display. 1. Turn the crown and set the mode hand to the time [TME] mode. 2. Press either button (A) or button (B) to select the city to be corrected. 3.
  • Page 25 · When the crown is turned to the right (clockwise) in the “hour” or “minute” correction states, correction is made in the positive direction. Turning the crown continuously allows “hours” or “minutes” to be corrected continuously. When turning the crown to the left (counter-clockwise), correction can be made in the negative direction.
  • Page 26 <Normal Time Display> <Time Correction State> Switching daylight savings time Crown pulled out to first click Seconds Crown returned to normal position Minutes Hours Switching 12H/24H time indication...
  • Page 27 Notes: 1. Daylight savings time can be set for each city. 2. When the time is set for any one city, the times of other cities, including UTC time, are corrected automatically. 3. When changing the time, the crown and buttons do not respond even if operated.

  • Page 28: Setting The Date

    10. Setting the Date (Date is corrected by digital display) 1. Turn the crown and set the mode hand to the calendar [CAL] mode. 2. Press either button (A) or button (B) to access the city to be corrected. 3. When the crown is pulled out to the first click (date setting position), the watch enters the date correction state.
  • Page 29 <Normal Date Display> <Date Correction State> Crown pulled out to first click Month Date Crown returned to normal position Year...
  • Page 30 Notes: 1. When the date is set for any one city, the dates of other cities, including UTC time, are corrected automatically. 2. The year can be set from 2001 to 2099. 3. The day is corrected automatically when the year, month and date are set. 4.

  • Page 31: Using The Race Timer

    11. Using the Race timer The race timer is able to set the time for 5 minute intervals for times between 60 and 10 minutes, and to 6, 5, 4, 3, and 2 minutes and 1 minute. <Setting the Race Timer> 1.
  • Page 32 <Timing Using the Race Timer> <Race Timer Initial Setting Display> 1. When pressing button (A), the race timer starts counting down from the time set while the second hand starts moving counter clockwise. 2. When pressing button (A) during the countdown, Press the race timer stops.
  • Page 33 Race timer timing Race timer stops display Time Up Auto chronograph Auto chronograph timing stops * After the remaining time is finished, the watch automatically switches to the auto chronograph.
  • Page 34 <Using Auto Chronograph Measurement> When the race timer measurement is finished, upon finishing simultaneously it changes to the auto chronograph that starts counting down automatically. The auto chronograph measures to a maximum of 23 hours, 59 minutes, 59 seconds in 1 second units. After timing is finished, the chronograph automatically returns to the race timer initial setting display.

  • Page 35: Using The Chronograph

    12. Using the Chronograph The chronograph is able to measure and display time to a maximum of 23 hours, 59 minutes, 59.99 seconds in 1/100th second units. After 24 hours have elapsed, the chronograph automatically returns to the chronograph reset display. <Chronograph Measurement>...
  • Page 36 · The ‘SPL” mark flashes in digital display-1 during split time display. In addition the second hand also stops moving. 4. Pressing button (B) while the chronograph is stopped, returns the chronograph to the chronograph reset display. · The second and function hand (used as the minute hand for the chronograph) rapidly advance to and stops at the 12 o’clock position.
  • Page 37 Chronograph reset Measurement Stops Split time *1: Returns automatically after timing for 24 hours *2: Returns automatically after 10 seconds...

  • Page 38: Using The Timer

    13. Using the Timer The timer can be set to a maximum of 99 minutes in 1 minute units. When the set time has elapsed, a tone indicating that the set time is up, sounds for about 5 seconds, after which the timer returns to the timer initial setting display. <Setting the Timer>...
  • Page 39 <Timing using the Timer> <Timer Initial Setting Display> 1. When pressing button (A) the timer starts counting down from the time set. 2. Pressing button (A) again during measurement Press stops the timer and pressing button (A) once more while the timer is stopped, restarts the timer. ·...

  • Page 40: Using The Alarm

    14. Using the Alarm The alarm setting procedure and other procedures for alarm use are the same for Alarm 1 and 2. Only the tone that sounds is different. Once a day, the alarm sounds for 15 seconds when the set time is reached. When the alarm is sounding, it can be turned off by pressing button (A), (B) or (C).
  • Page 41 correction state, correction is made in the positive direction. When the crown is turned to the left (counter-clockwise), correction is made in the negative direction. · Turning the crown continuously allows corrections to be made rapidly. 5. After corrections have been completed, return the crown to the normal position. Note: ·...
  • Page 42 <Switching Alarm ON and OF> 1. The alarm can be switched ON and OF by pulling out the crown to the first click when the alarm mode is on. 2. Pressing button (B) switches the alarm ON and OF each time it is pressed. 3.

  • Page 43: Using Zone Setting

    15. Using Zone Setting The zone setting function enables only those cities for which ‘SET’ has been selected to be easily accessed (displayed) in each mode. <Using Zone Setting> 1. Turn the crown while in the normal position and set the mode hand to the zone setting [SET] mode.

  • Page 44: About All-Reset

    16. About All-Reset When this watch indicates an abnormal display or does not function properly (no display, alarm continues to sound, etc.) as a result of being subjected to the effects of static electricity or strong impact and so forth, perform the all-reset procedure described below.
  • Page 45 · All segments of the digital display are shown when any of the buttons is released. 4. This fully lit display is canceled when the crown is returned to the normal position. · After canceling, a confirmation tone is sounded after which each of the hands perform a demonstration movement in the order of the second hand, function hand, and minute hand, to indicate that the all-reset procedure is finished.

  • Page 46: Functions Unique To Eco-Drive Watches

    17. Functions Unique to Eco-Drive Watches Normal Display When the When power watch generation stops as a becomes result of light not insufficiently shining on the watch charged Power Save 1 When the Power Save watch is When power 1 continues charged generation resumes for 3 days...
  • Page 47 If the watch Stopped continues Insufficient Charging Warning Analog displays: Hands to be Analog display: Two-second stop insufficiently interval moving charged Digital display: CHARGE mark Digital display: The entire flashes isplay goes out When the time is set while charging is still insufficient Time Setting Warning Function Analog display: Hands stopped at standard...
  • Page 48 [Insufficient Charging Warning Function] 2sec Analog Display 2sec Regardless of the display (mode) of the watch at the time, when the watch becomes insufficiently charged, the watch changes to the time display and the second hand begins to move at two-second interval movement. Although the 24 hour hand, hour hand and minute hand continue to keep the correct time, the watch stops after about 1.5 days have elapsed after the insufficient charging warning function is...
  • Page 49 <Digital Display in Each Mode> · The watch displays the normal time display regardless of the position of the crown (pulled out to the first click) in each mode except for the calendar mode. · When the watch is in the calendar mode, the normal date display is displayed regardless of the position of the crown.
  • Page 50 <When the insufficient Charging Warning Function is Canceled> When the insufficient charging warning function is canceled as a result of exposing the watch to light and a sufficient charge, the watch returns to the mode indicated by the mode hand. [Time Setting Warning Function] Analog Display The watch stops when insufficient charging continues for about 1.5 days.
  • Page 51 Digital Display The all-reset display (12 hours, 00 minutes, 00 seconds, UTC or January 1 TU) flashes in the time or calendar mode. <Canceling the Time Setting Warning Function> 1. Set the mode hand to the time mode and pull the crown out to the first click to set the time.
  • Page 52 [Overcharging Prevention Function] The overcharging prevention function is activated when the rechargeable cell is fully charged so that it is not charged further. This allows the user to charge the watch without any risk of overcharging. [Power Save 1] When power is not generated as a result of the solar cell not being exposed to light, the second hand stops when it reaches the 12 o’clock position and the watch automatically enters the power save state to inhibit power consumption of the rechargeable cell.
  • Page 53 <Canceling Power Save 1 > Power Save 1 is canceled when power generation resumes as a result of exposing the solar cell to light. · The second hand rapidly advances to the current time and begins one- second interval movement. ·...
  • Page 54 Analog Display · The 24 hour hand, hour hand, minute hand, second hand and function hand stop at the standard position (12:00). Digital Display · The digital display remains completely out in continuation from the Power Save 1 state. Notes: ·...

  • Page 55: General Reference For Charging Times

    18. General Reference for Charging Times Below are the approximate times required for charging when exposing the watch dial to light continuously. This table is for general reference only and does not represent exact charging times. Charging time (approx.) Illuminance To start working To become fully Environment...
  • Page 56 To become fully charged when the cell is discharged: Time required for recharging the watch from the stopped state to the fully charged state. To work for one day: Time required for recharging the watch to run for 1 day at one-second interval movement.

  • Page 57: Notes Regarding Handling Of This Watch

    19. Notes Regarding Handling of this Watch <Try to keep the watch charged at all times.> • Please note that if you routinely wear long sleeves, the watch can easily become insufficiently charged as a result of it being concealed and unable to be exposed to light.

  • Page 58: Precautions

    20. Precautions CAUTION: Water-resistance performance There are several types of water-resistant watches, as shown in the following table. The unit "bar" is roughly equal to 1 atmosphere. * WATER RESIST(ANT) xx bar may also be indicated as W.R. xx bar. Indication Minor exposure to water Specification...
  • Page 59 For correct use within the design limits of the watch, confirm the level of water- resistance of your watch, as indicated on the dial and case, and consult the table. Examples of use Moderate exposure to Operation of the Marine sports Scuba diving water (washing, kitchen crown or button with...
  • Page 60 • Water-resistance for daily use (to 3 atmospheres): This type of watch is water- resistant to minor exposure to water. For example, you may wear the watch while washing your face; however, it is not designed for use underwater. • Upgraded water-resistance for daily use (to 5 atmospheres): This type of watch is water-resistant to moderate exposure to water.
  • Page 61 • If moisture has entered the watch, or if the inside of the crystal is fogged up and does not become clear within a day, immediately take the watch to your dealer or Citizen Service Center for repair. Leaving the watch in such a state will allow corrosion to form inside.
  • Page 62 metal band. If your watch is not water-resistant, take it to your dealer. NOTE: Avoid using solvents (thinner, benzine, etc.), as they may mar the finish. CAUTION: Operating environment • Use the watch within the operating-temperature range specified in the instruction manual.
  • Page 63 has occurred, move the watch away from the magnet and reset the time. • Do NOT place the watch close to household appliances that generate static electricity. Timekeeping may become inaccurate if the watch is exposed to strong static electricity, such as is emitted from a TV screen. •...

  • Page 64: Specifications

    21. Specifications 1. Model No.: C660 2. Type: Combination solar-powered watch 3. Accuracy: Within ±15 seconds per month (when worn at normal temperatures of +5°C to +35°C (41°F to 95°F) 4. Operating Temperature Range: Watch operating temperature range: 0°C to +55°C (32°F to 131°F) 5.
  • Page 65 * Alarm 1: Hours, minutes, city name, ON/OF * Alarm 2: Hours, minutes, city name, ON/OF * Zone setting: Display setting (SET) and cancelation (OFF) for each city 6. Additional Functions * Solar power function * Switching between main time (analog) and sub-time (digital) * Hands evacuation function (moving the minute and hour hands to the 12 o’clock position * Power Save 1: Automatically stops second hand movement and liquid...
