  • Page 1 SKM 100 Instruction manual...
  • Page 2 Tastensymbole / Button icons / Icônes de touches / Simboli dei tasti / Símbolos de las teclas / Símbolos dos botões / Символы кнопок / 按键图标 Taste ON/OFF ON/OFF button / Touche ON/OFF ON/OFF Tasto ON/OFF / Botón ON/OFF / Botão ON/OFF Кнопка...

  • Page 3: Table Of Contents

    Polar diagrams and frequency response curves of the microphone heads ..........24 For more detailed information on the individual sections of this instruction manual, visit the SKM 100 G3 product page on our website at www.sennheiser.com. There you can also view an animated instruction manual.

  • Page 4: Important Safety Instructions

    • Only use attachments/accessories specified by Sennheiser. • When replacement parts are required, only use replacement parts spec- ified by Sennheiser or those having the same characteristics as the orig- inal part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

  • Page 5: The Skm 100 G3 Radio Microphone Family

    The SKM 100 G3 radio microphone family The SKM 100 G3 radio microphone is part of the evolution wireless series generation 3 (ew G3). With this series, Sennheiser offers high-quality state-of-the-art RF transmission systems with a high level of operational reliability and ease of use.

  • Page 6: Areas Of Application

    The SKM 100 G3 radio microphone family Areas of application The radio microphone family can be combined with the EM 100 G3 stationary receiver. The EM 100 G3 stationary receiver is available in the same UHF frequency ranges and is equipped with the same frequency bank system with factory-preset frequencies.

  • Page 7: Delivery Includes

    Delivery includes Delivery includes The packaging contains the following items: 1 SKM 100 G3 radio microphone incl. microphone head 2 AA size batteries, 1.5 V 1 microphone clamp 1 instruction manual 1 frequency information sheet...

  • Page 8: Product Overview

    Product overview Product overview Overview of the SKM 100 radio microphone ¶ ² ´ ¿ » · º ¸ µ ¾ º ¹ µ µ ³ Microphone head (interchangeable) · Name and pick-up pattern of the microphone head (siehe Seite 4) »...

  • Page 9: Overview Of The Displays

    Product overview Overview of the displays After switch-on, the radio microphone displays the standard display “Frequency/Name”. For further illustrations and examples of the different standard displays, refer to Seite 12. The display backlighting is automatically reduced after approx. 20 seconds. 533.875 ew100 G3 MUTE...

  • Page 10: Putting The Radio Microphone Into Operation

    Inserting the batteries/accupack For powering the radio microphone, you can either use two 1.5 V AA size batteries or the rechargeable Sennheiser BA 2015 accupack. Unscrew the lower part of the radio microphone from the radio micro- » phone’s body by turning it counterclockwise.

  • Page 11: Charging The Accupack

    Use the LA 2 charging adapter to insert the radio microphone into the L 2015 charger (both the charger and the charging adapter are avail- able as optional accessories – information on accessories can be found on our web site at www.sennheiser.com). LA 2 L 2015 The L 2015 charger can only charge individual BA 2015 accupacks or –...

  • Page 12: Changing The Color-Coded Protection Ring

    Protection rings in different colors are avail- able as accessories (information on accessories can be found on our web site at www.sennheiser.com). The protection rings allow you to clearly identify each radio microphone. º Remove the color-coded protection ring as shown.

  • Page 13: Using The Radio Microphone

    Using the radio microphone Using the radio microphone To establish a transmission link, proceed as follows: 1. Switch the receiver on (see the instruction manual of the receiver). 2. Switch the radio microphone on (see below). The transmission link is established and the receiver’s RF level display “RF”...

  • Page 14: Deactivating The Lock Mode Temporarily

    Using the radio microphone Deactivating the lock mode temporarily You can activate or deactivate the automatic lock mode via the “Auto Lock” menu item (siehe Seite 17). If the lock mode is activated, you have to temporarily deactivate it In order to be able to operate the radio micro- phone: Move the multi-function switch upwards/downwards.

  • Page 15: Using The Operating Menu

    Using the operating menu Using the operating menu The buttons Button Function of the button Press the • Switches the radio microphone on and off ON/OFF button • Cancels the entry and returns to the current ON/OFF standard display (ESC function) •...

  • Page 16: Working With The Operating Menu

    Using the operating menu Display Function of the menu item LCD Contrast Adjusts the contrast of the display panel (siehe Seite 19) Reset Resets the radio microphone (siehe Seite 19) Software Revision Displays the current software revision (siehe Seite 19) Exit Exits the extended menu “Advanced...
  • Page 17 Using the operating menu Canceling an entry Press the ON/OFF button to cancel the entry. ON/OFF The current standard display appears on the display panel. To return to the last edited menu item: Press the multi-function switch so many times until the last edited menu item appears.

  • Page 18: Adjusting Settings Via The Operating Menu

    The relevant information is marked with the sync icon. For more detailed information on the operating menu, visit the SKM 100 G3 product page at www.sennheiser.com. The main menu “Menu” Adjusting the input sensitivity – “Sensitivity”...
  • Page 19 Adjusting settings via the operating menu Overview of the frequency banks and channels: Frequency bank Channels Type “1” to “20” up to 12 per System bank: frequency bank frequencies are factor-preset “U” up to 12 User bank: frequencies are freely selectable When setting up multi-channel systems, please observe the following: Only the factory-preset frequencies within one frequency bank are inter- modulation-free (siehe Seite 20).

  • Page 20: The Extended Menu "Advanced Menu

    Adjusting settings via the operating menu The extended menu “Advanced Menu” Setting transmission frequencies and the frequency bank “U” – “Tune” When you have selected one of the system banks and then select the “Tune” menu, the radio microphone automatically switches to channel 1 of the frequency bank “U”.
  • Page 21 Adjusting settings via the operating menu Activating/deactivating the pilot tone transmission – “Pilot Tone” Advanced Menu P i l o t P i l o t Name A c t i v e I n a c t i v e Pilot Tone A c t i v e Call up...

  • Page 22: Adjustment Tips

    Adjustment tips Adjustment tips Synchronizing the radio microphone with a receiver When synchronizing the radio microphone with a receiver, please observe the following: Only use a radio microphone and a receiver from the same frequency range (see the type plate on the radio microphone and the receiver). Make sure that the desired frequencies are listed in the enclosed frequency information sheet.

  • Page 23: Cleaning The Radio Microphone

    Cleaning the radio microphone Cleaning the radio microphone CAUTION! Liquids can damage the electronics of the radio micro- phone! Liquids entering the housing of the device can cause a short-circuit and damage the electronics. Keep all liquids away from the radio microphone. Use a slightly damp cloth to clean the radio microphone from time to time.

  • Page 24: If A Problem Occurs

    If a problem occurs that is not listed in the above table or if the problem cannot be solved with the proposed solutions, please contact your local Sennheiser partner for assistance. To find a Sennheiser partner in your country, search at www.sennheiser.com under “Service & Support”.

  • Page 25: Specifications

    Frequency stability RF output power at 50 Ω typ. 30 mW Pilot tone squelch can be switched off AF characteristics Compander system Sennheiser AF frequency response 80–18,000 Hz Signal-to-noise ratio ≥ 110 dBA (1 mV, peak deviation) ≤ 0.9 %...

  • Page 26: Polar Diagrams And Frequency Response Curves Of The Microphone Heads

    Specifications Approved by Canada Industry Canada RSS 210 IC: 2099A-G3SKMEM limited to 806 MHz FCC-Part 74 FCC-ID: DMO G3SKMEM limited to 698 MHz Microphone heads MMD 835-1 MMD 845-1 MME 865-1 Microphone type dynamic dynamic condenser Sensitivity 2.1 mV/Pa 1.6 mV/Pa 1.6 mV/Pa Pick-up pattern cardioid...
  • Page 27 Specifications Frequency response curve MMD 835-1 1.000 10.000 Frequency response curve MMD 845-1 1.000 10.000 Frequency response curve MME 865-1 1.000 10.000 0° 90°...
  • Page 28 Sennheiser electronic GmbH & Co. KG Publ. 12/16 Am Labor 1, 30900 Wedemark, Germany www.sennheiser.com 529671...
