Using the Remote Control

The remote control can be used to control every aspect of the display's operation and includes
more functionality than the controls on the right side of the display.
The following is a list of all buttons on the remote and their functions:
Button(s) Function
Turns the display on and off
These buttons activate and configure Picture-in-Picture (PIP), as follows:
• PIP—Selects the PIP mode: Off, Standard PIP, or PBP (Picture-by-
Picture)
1
PIP
• S-SOURCE—Selects the signal source used for the secondary window.
See "Picture-in-Picture Combinations" on page 29 for a list of possible
signal source combinations for the main and secondary windows.
• S-POS—When PIP is set to Standard PIP mode, adjusts the position of
the secondary PIP window
• SWAP—Swaps the primary and secondary sources
• FREEZE—Freezes the content of the main window
13
1 2
2
PBP
