ABB-Welcome Safety ..................................3 Intended use ................................3 Environment ................................3 ABB devices ............................3 User Manual................................3 Operation ................................. 4 Standard operation ..........................4 5.1.1 Control elements ............................. 4 5.1.2 Welcome screen and status bar ......................6 Control actions ............................7 5.2.1...
ABB devices All packaging and devices from ABB bear the markings and test seals for proper disposal. Always dispose of the packaging material and electric devices and their components via the authorized collecting depots and disposal companies.
ABB-Welcome Operation Operation Standard operation 5.1.1 Control elements SD-Card Mo.31. Fig. 1: Overview of control buttons | CKA001473B7516 — 4 —...
Page 5
ABB-Welcome Operation Function Press this button accept a call. Press this button to open the door. Press this button to deactivate the doorbell. While a call is pending, this button has the "reject call" function. – Press this button to reject a call.
ABB-Welcome Operation 5.1.2 Welcome screen and status bar Fig. 2: Status bar Function Current date - Set the date by touching the button. Time - Set the correct time by touching the button. System information - Call up the address (number of the indoor station) of this panel and the current hardware and software information by touching the button.
ABB-Welcome Operation Control actions 5.2.1 Setting up the voice and video connection Fig. 3: Setting up the voice and video connection The following functions are available for setting up the voice and video connections (pressing the handset button): Function Designation of camera Set the volume by touching the respective buttons (plus and minus).
ABB-Welcome Operation 5.2.2 Opening the door Fig. 4: Opening the door When activating the door opener (by pressing the key button), the following function is available: Function The "Open door" icon is displayed when you press the door opener or activate the function "Automatic door opener".
ABB-Welcome Operation 5.2.3 Muting Fig. 5: Mute function (mute timer) The following functions are available for muting (mute timer): Function No call is pending: If you press the "Mute function" while no call is pending the bell sound of the panel is deactivated for a certain period.
ABB-Welcome Operation 5.2.4 Switching the light Fig. 6: Switching lights When activating the light switch, the following function is available: Function The "Light" icon is displayed when you press the button "Switching lights". | CKA001473B7516 — 10 —...
ABB-Welcome Operation 5.2.5 Camera surveillance In the camera surveillance you change between the pictures in the integrated camera. Here you can also make settings for the volume and the camera image. Fig. 7: Camera surveillance Function "Calling up events and picture memory / history".
ABB-Welcome Operation 5.2.6 Events and picture memory / history The panel records all events. Pressing the "History" button (1) displays the last 100 events (prior events are overwritten). Fig. 8: Events and picture storage / history Function If you have activated the function "Auto snapshots activated" in the system settings, the flashing icon in the status bar signals a newly taken snapshot.
Page 13
ABB-Welcome Operation Fig. 9: Events and picture storage / history | CKA001473B7516 — 13 —...
Page 14
ABB-Welcome Operation During a call you can take a snapshot at any time by pressing the "History" button, even when the "Automatic snapshots" function is not active. The following functions are available for the "Events and picture storage /history" function.
ABB-Welcome Operation 5.2.8 Settings 5.2.8.1 Overview Fig. 11: Overview of settings The following areas are available when pressing the "Settings" button: Function Volume – The volumes of the bell sounds Display – Different display settings Date and time – Different time settings Camera list –...
Page 17
ABB-Welcome Operation Fig. 12: Settings To change into the settings areas of the list field (1), carry out the following steps: To display the hidden functions, tap on the scroll buttons (2). Tap on one of the setting areas. Tap on button "Set" (3).
ABB-Welcome Operation 5.2.8.2 Volume Fig. 13: Setting the volume When changing to "Volume" the following functions become available: Function Bell-sound volume – Set the volume of the bell sound via the "Plus / minus" buttons. Mute timer - Use the "Plus / minus" buttons to set the time of the mute function which you activate via the "mute"...
ABB-Welcome Operation 5.2.8.3 Display Fig. 14: Display settings When changing to "Display", the following functions become available: Function Brightness - Set the brightness of the display via the "Plus / minus" buttons. Screen saver – The display is preset as digital clock –...
Page 20
ABB-Welcome Operation Screen saver Off – Select the active period for the screen saver via the fold-down menu until it switches itself off automatically. – Available are 5 / 15 / 30 minutes. – To protect the display the maximum period for the display is limited to 30 minutes.
ABB-Welcome Operation 5.2.8.4 Date / time Fig. 15: Settings of the date and time With the change to "Date and time" the following functions become available: Function Time – Set the time via the "Plus / minus" buttons. – Before the adjustment tip on ""Hours", "Minutes" or "Seconds". The active area is marked with a frame.
ABB-Welcome Operation 5.2.8.5 Camera list Fig. 16: Camera list Surveillance cameras can be integrated and set in the door communication system. When changing to "System settings Camera list" the following functions become available: Function Overview of available cameras Adjust – By tapping on this button you switch to the page for assigning a name to the selected camera.
Page 23
ABB-Welcome Operation Update list (reload) – By tapping on this button you update the list of displayed cameras. – The device searches for installed cameras in the door communication system for installed cameras and displays these. This may take several minutes. The progress of the update is indicated by a status window.
ABB-Welcome Operation 5.2.8.6 Language Fig. 17: Setting the language When changing to "Language" the following functions become available: Function Language (list field) – Here the languages available for selection are listed Scroll – To display the hidden languages tip on the scroll boxes.
Page 25
ABB-Welcome Operation Foreign language is set If a foreign language has been set, take the following steps for a reset: 1. Tip on the "Settings" button below the display. 2. In the list field of the "Settings" display (on the left in the display) tip on the 4th entry from the top (this entry is marked with a flag).
ABB-Welcome Operation 5.2.8.7 Door Entry System Fig. 19: Settings of the Door Entry Systems Information about the settings The settings always apply to all connected outdoor stations. With the change to "Door Entry System" the following functions become available: Function Outdoor stations –...
ABB-Welcome Operation 5.2.8.8 Firmware update Fig. 20: Firmware update The firmware updates are made available on the Internet at www.busch-jaeger.com. If the firmware for your device is to be updated, carry out the following steps: On page www.busch-jaeger.com enter the article number of the device in the "Search" section.
ABB-Welcome Operation Cleaning Caution Risk of damage to the screen surface. The screen surface can be damaged by hard or sharp objects! Never use such objects for entries on the touch screen monitor. – Use your finger or a plastic stylus.
ABB-Welcome Operation Adjusting the device 5.4.1 Terminal resistor Fig. 21: • In pure audio installations always set the terminal resistor (2) on "OFF". • In video installations or mixed audio and video installations set the terminal resistor for the the last devices of a branch on "ON".
ABB-Welcome Technical data Technical data Designation Value Display resolution: 800 x 480 Display size: 17.8 cm (7") Operating temperature -5° C to +40° C Storage temperature -20° C – +70° C Protection IP 30 Single-wire clamps 2 x 0.6 mm² – 2 x 1 mm²...
ABB-Welcome Mounting / Installation Mounting / Installation Warning Electric voltage! Risk of death due to electrical voltage of 100 to 240 V during short-circuit in the low-voltage conduit. – Low-voltage and 100 to 240 V conduits must not be installed together in a flush-mounted box!
ABB-Welcome Mounting / Installation Mounting Installation on an FM socket according to DIN 49073-1, or directly on a level wall surface. Fig. 23: 1. Open the housing of the panel by pulling the clamp on the bottom of the device.
Page 33
ABB-Welcome Mounting / Installation Fig. 25: 3. Connect the bottom part of the device according to the graphics (see chapter "Connection" on page 35). 1- 4 Fig. 26: | CKA001473B7516 — 33 —...
Page 34
ABB-Welcome Mounting / Installation Set the address of the preferred outdoor stations and the address of the indoor station on the rotary switches (see chapter "Addressing" on page 36). Fig. 27: 5. Set the master/slave function and the terminal resistor on the switches at the rear of the top part of the housing (see chapter "Setting the master/slave switch"...
ABB-Welcome Mounting / Installation Connection 83300-x Fig. 29: Function Connection for the floor call push-button • Connection for the system controller • When using several indoor stations: connection for the internal bus | CKA001473B7516 — 35 —...
8.1.1 Uniform assignment of the doorbell push-buttons ® With several outdoor stations within an ABB-Welcome system the doorbell push-buttons of each outdoor station are generally assigned uniformly. This means that all apartments can be called from all outdoor stations. This is practical for buildings with several entrances from each of which all apartments are accessible.
ABB-Welcome Addressing 8.1.2 Different assignment of the doorbell push-buttons Alternatively, the doorbell push-buttons of the various outdoor stations can be assigned differently when all apartments are to be called from one outdoor station and only some apartments from additional outdoor stations.
ABB-Welcome Addressing Assigning the doorbell push-button of an outdoor station to an apartment 8.2.1 Factory setting Fig. 32: Uniform assignment of doorbell push-buttons Designation Main entrance outdoor station Side entrance outdoor station Apartment 01 Apartment 02 Apartment 03 The doorbell push-buttons of an outdoor station are assigned to the apartments consecutively from top to bottom and left to right with the addresses 01, 02, etc.
ABB-Welcome Addressing 8.2.2 Change in the assignment of the doorbell push-buttons ("Offset") Fig. 33: Different assignment of doorbell push-buttons Designation Apartment 02 Apartment 01 Outdoor station of the left building Outdoor station of the entrance gate Outdoor station of the right building...
Button sounds (ON = active) ® The assignment to one of the four inputs of the ABB-Welcome system is made on the outdoor stations and the associated switch actuators for door and light via the setting of the address. Here the rotary knob (1) "Address of outdoor station"...
Setting of the standard outdoor station ® For several outdoor stations in an ABB-Welcome system the "standard outdoor station" must be set on the indoor stations. Here the rotary switch STATION (1) is set on the address of the standard outdoor station between 1 and 4.
ABB-Welcome Addressing 8.3.4 Setting of the door opener or light switch The setting is only made on the door/light switch actuator. It shows the respective function of the device in the ® ABB-Welcome system. The sliding switch on the device is used for setting.
Page 43
ABB-Welcome Addressing Project name: Mounting position for the outdoor station: Floor 02 | CKA001473B7516 — 43 —...
Page 44
PO box contents of this document without prior notice. 58505 Lüdenscheid The detailed specifications agreed to at the time of ordering apply to all orders. ABB accepts no Freisenbergstraße 2 responsibility for possible errors or 58513 Lüdenscheid incompleteness in this document.
