Safety National Conventions The following subsections describe notational conventions used in this document. Notes, Cautions, and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These blocks are notes, cautions, and warnings, and they are used as follows: NOTE: A NOTE indicates important information that helps you make better use of your computer system.
Power The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will fit only into a grounded power outlet as a safety feature.
Installation Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with this product.
Cleaning Clean the cabinet regularly with a water-dampened, soft cloth. When cleaning use a soft cotton or microfiber cloth. The cloth should be damp and almost dry, do not allow liquid into the case. Please disconnect the power cord before cleaning the product.
Other If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a Service Center. Make sure that the ventilating openings are not blocked by a table or curtain. Do not engage the LCD monitor in severe vibration or high impact conditions during operation. Do not knock or drop the monitor during operation or transportation.
Wall mount with screws Quick Start Warranty card Adapter Micro HDMI Cable USB C-C Cable Power Cable Not all signal cables will be provided for all countries and regions. Please check with the local dealer or AOC branch office for confirmation.
Adjusting Viewing Angle You are able to adjust the monitor as below: 3° 30° 3° 30° NOTE: Do not touch the LCD screen when you change the angle. Touching the LCD screen may cause damage.
Connecting the Monitor Cable Connections In Back of Monitor and Computer: 1. Micro HDMI 2. USBC 3. Power 4. Earphone Connect to PC 1. Connect the power cord to the back of the display firmly. 2. Turn off your computer and unplug its power cable. 3.
4. Reconnect the cables. Refer to the user’s manual that came with the optional wall mounting arm for instructions on attaching it to the wall. NOTE: VESA mounting screw holes are not available for all models, please check with the dealer or official department of AOC.
Adaptive-Sync function(Available for selective models) 1. Adaptive-Sync function is working with USB C/HDMI 2. Compatible Graphics Card: Recommend list is as the below, also could be checked by visiting www.AMD.com Graphics Cards • Radeon™ RX Vega series • Radeon™ RX 500 series •...
AMD FreeSync Premium function (Available for selective models) 1. AMD FreeSync Premium function is working with USB C/HDMI 2. Compatible Graphics Card: Recommend list is as the below, also could be checked by visiting www.AMD.com Graphics Cards • Radeon™ RX Vega series •...
Adjusting Hotkeys Menu/Enter Game Mode Dial Point Power/Source/Exit Menu/Enter Press to display the OSD or confirm the selection. Power Press the Power button to turn on the monitor. Press and hold for 3S to turn off the monitor. Dial Point When there is no OSD, press Dial Point key to show / hide Dial Point.
OSD Setting Basic and simple instruction on the control keys. Luminance Color Setup Picture Boost OSD Setup Game Setting Extra Exit Contrast Gamma Gamma1 Brightness Eco Mode Standard HDR Mode 1). Press the button to activate the OSD window. 2). Press DOWN or UP to navigate through the functions.
Luminance Luminance Color Setup Picture Boost OSD Setup Game Setting Extra Exit Contrast Gamma Gamma1 Brightness Eco Mode Standard HDR Mode Contrast 0-100 Contrast from Digital-register. Brightness 0-100 Backlight Adjustment. Standard Standard Mode. Text Text Mode. Internet Internet Mode. Eco Mode Game Game Mode.
Color Setup Color Setup Picture Boost OSD Setup Game Setting Extra Exit Luminance DCB Mode Color Temp. Warm Color Gamut Panel Native Green DCB Demo LowBlue Mode Blue Warm Recall Warm Color Temperature from EEPROM. Normal Recall Normal Color Temperature from EEPROM. Color Temp.
Picture Boost Luminance Picture Boost Game Setting Extra Exit Color Setup OSD Setup Bright Frame Brightness H. Position Frame Size Contrast V. Position Bright Frame On or Off Disable or Enable Bright Frame. Frame Size 14-100 Adjust Frame Size. Brightness 0-100 Adjust Frame Brightness.
OSD Setup Game Setting Extra Exit Luminance Color Setup Picture Boost OSD Setup Language English H. Position Transparence V. Position Timeout Break Reminder Volume Language Select the OSD language. Timeout 5-120 Adjust the OSD Timeout. Volume 0-100 Volume Adjustment. H. Position 0-100 Adjust the horizontal position of OSD.
Game Setting Extra Exit Luminance Game Setting Color Setup Picture Boost OSD Setup Frame Counter Game Mode Game Color Shadow Control Overdrive Adaptive-Sync Low Input Lag Game Setting Extra Exit Luminance Color Setup Picture Boost OSD Setup Low Input Lag Frame Counter Game Mode Game Color...
Extra Extra Exit Luminance Picture Boost OSD Setup Color Setup Game Setting Input Select Auto DDC/CI Resolution : 1920x1080 Off Timer Reset H. Frequency : 67 KHz Image Ratio Wide V. Frequency : 60 Hz Input Select Auto/HDMI/USB C Select Input Signal Source. Off timer 0-24hrs Select DC off time.
Press hot-key (AUTO) to auto-adjust. Please refer to Regulation & Service Information which is in the CD manual Regulation & Service or www.aoc.com (to find the model you purchase in your country and to find Regulation & Service Information in Support page.)
Specification General Specification Model Name 16G3 Driving System TFT Color LCD Viewable Image Size 39.5 cm diagonal Panel Pixel Pitch 0.17925mm(H) x 0.17925mm(V) Separate Sync. H/V TTL Display Color 16.7M Colors Horizontal Scan Range 30k-160kHz Horizontal Scan Size(Maximum) 344.16mm Vertical Scan Range...
Pin Assignments 19-Pin Color Display Signal Cable Pin No. Signal Name Pin No. Signal Name Pin No. Signal Name TMDS Data 2+ TMDS Data 0- DDC/CEC Ground TMDS Data 2 Shield TMDS Clock + +5V Power TMDS Data 2- TMDS Clock Shield Hot Plug Detect TMDS Data 1+ TMDS Clock-...
Plug and Play Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.
