Instructions-Parts
Alternator
Conversion Kit
For converting an XM plural-component sprayer wall power supply to a turbine power
supply. For professional use only.
Not for use in explosive atmospheres.
Part No. 256991
Important Safety Instructions
Read all warnings and instructions in the XM
Plural-Component Sprayer Operation manual.
Save these instructions.
For patent information, see www.graco.com/patents
Get other manuals https://www.bkmanuals.com
313293C
EN
r_256991_313293_13a
Advertisement
Table of Contents
Related Manuals for Graco 256991
Summary of Contents for Graco 256991
- Page 1 For professional use only. Not for use in explosive atmospheres. Part No. 256991 Important Safety Instructions Read all warnings and instructions in the XM Plural-Component Sprayer Operation manual. Save these instructions. For patent information, see www.graco.com/patents r_256991_313293_13a Get other manuals https://www.bkmanuals.com...
-
Page 2: Table Of Contents
Technical Data ......8 Graco Standard Warranty ....10 Graco Information . -
Page 3: Component Identification
Component Identification Component Identification Power Supply Cable Connections Alternator Conversion Kit Cable Connections r_256991_313293_10 r_256991_313293_9 . 1: Typical Installation Key: Alternator USB Module Display Module Fluid Control Module Power Supply Filter Assembly Power Supply Cable CAN cable 15V779 (communication/power) CAN cable 15V778 (communication/power) CAN cable 15V782 (USB power cable) CAN cable 15V783 (Display power cable) 313293C... -
Page 4: Installation
Installation Installation 6. Disconnect CAN cable (H) from USB front CAN con- nector and display module (C). See F . 1 on page NOTE: It is required to remove the power supply before install- Cable (H) will not be used for alternator conversion kit. ing the alternator conversion kit. -
Page 5: Install Alternator
Installation Install Alternator Install Regulator Assembly 1. Use screws (14) to install alternator (1) inside junc- 1. Position regulator (6) for proper air flow direction. tion box (JB). r_256991_313293_1 . 5: Install Regulator Assembly 2. Connect pressure gauge (12), elbow (7), safety valve (9), elbow fitting (10) and nipple fitting (5) to air regulator (6). -
Page 6: Setup
Setup Setup Connect Hose Connect Cables 1. Connect tubing (15) between the air regulator outlet Use reference labels located near CAN connectors to fitting (10) and the alternator air inlet (M). properly connect components that are connected with the alternator. Each CAN cable is marked with the part number. -
Page 7: Parts
Parts Parts 256991, Alternator Conversion Kit r_256991_313293_11 Ref. Part Description Qty. Ref. Part Description Qty. 194337 WIRE, ground 255728 MODULE, alternator 100284 NUT, hex 3† 15V782 CABLE, I.S. CAN, male/ female, 20 111307 WASHER, lock, external 21† 15Y861 TUBE, spark arrest, alternator 4†... -
Page 8: Technical Data
Technical Data Technical Data Alternator Module Maximum Air Working Pressure 19 psi (1.13 MPa, 1.31 bar) Minimum Air Working Pressure 17 psi (0.13 MPa, 0.12 bar 313293C Get other manuals https://www.bkmanuals.com... - Page 9 Technical Data 313293C Get other manuals https://www.bkmanuals.com...
-
Page 10: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
