- Page 1 User Manual L 74484 WVFL Washing Machine...
-
Page 2: Table Of Contents
14. TECHNICAL DATA..................... 26 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it. -
Page 3: Safety Information
ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference. -
Page 4: Safety Instructions
If a tumble dryer is stacked on the top of the washing • machine, make sure to use the correct stacking kit approved by AEG (see more details in chapter "Accessories - Stacking kit"). 2. SAFETY INSTRUCTIONS 2.1 Installation 2.2 Electrical connection... -
Page 5: Product Description
ENGLISH • This appliance complies with the • Make sure that you remove all metal E.E.C. Directives. objects from the laundry. • Do not put a container to collect 2.3 Water connection possible water leakage under the appliance. Contact the Authorised •... - Page 6 Only appropriate using the correct stacking kit accessories approved by manufactured and approved by AEG. AEG ensure the safety The compatible stacking kits are: standards of the appliance. If • SKP11/STA9 - If the tumble dryer unapproved parts are used, depth is 54 cm or 60 cm.
-
Page 7: Control Panel
ENGLISH 4. CONTROL PANEL 4.1 Control panel description Glätten Koch/Bunt Auffrischen + Vorwäsche Baumwolle Extra Leise Super Eco Pflegeleicht 20 Min.- 3Kg Leichtbügeln Jeans Feinwäsche Wolle/ Spülen Seide Schleudern/ Daunen Pumpen Ein/Aus On/Off button (Ein/Aus) Extra rinse button (Extra Spülen) Programme knob Stain button (Flecken) Display... -
Page 8: Programmes
Spin area: Spin speed indicator No Spin indicator Rinse Hold indicator 1) Only available for Spin/Drain programme. Display indicators: Washing phase Rinses phase Spin phase Child safety lock Door locked You cannot open the appliance door when the symbol is on. - Page 9 ENGLISH Programme Maximum Programme description Temperature range load (Type of load and soil level) Maximum spin speed White cotton and coloured cotton. Normal 8 kg 1400 rpm soil and light soil. Koch/Bunt 95°C - Cold White cotton and coloured cotton. Heavy soil 8 kg 1400 rpm and normal soil.
- Page 10 Programme Maximum Programme description Temperature range load (Type of load and soil level) Maximum spin speed Cottons and synthetics items with light soil 20 Min. - 3 kg 3 kg 40°C - 30°C 1200 rpm level or worn only once.
- Page 11 ENGLISH Programme Maximum Programme description Temperature range load (Type of load and soil level) Maximum spin speed Steam programme for cotton and synthetic 1.5 kg items. This cycle helps to dewrinkle the laun- Glätten dry. 40°C 1) To reduce the creases of the laundry, this cycle regulates the water temperature and performs a soft wash and spin phase.
- Page 12 Programme ■ ■ ■ ■ ■ ■ Feinwäsche ■ ■ ■ Wolle/Seide ■ ■ Daunen ■ ■ ■ Schleudern/Pumpen ■ ■ ■ ■ Spülen ■ ■ ■ ■ Jeans 20 Min. - 3 kg ■ ■ Super Eco ■...
-
Page 13: Consumption Values
ENGLISH 6. CONSUMPTION VALUES The data of this table are approximate. Different causes can change the data: the quantity and type of laundry, the water and ambient tempera- ture. At programme start the display shows the duration programme for the maximum load capacity. -
Page 14: Settings
7. SETTINGS 7.1 Acoustic signals • To activate/deactivate this option, press Temp. and U./Min. at the same The acoustic signals operate when: time until the indicator comes on/ • You activate the appliance. goes off. • You deactivate the appliance. -
Page 15: Before First Use
ENGLISH • The washing programme stops with 8.7 U./Min. the water in the drum. The drum turns With this option you can decrease the regularly to prevent the laundry default spin speed. creases. • The door stays locked. You must drain The display shows the indicator of the set the water to unlock the door. - Page 16 10.3 Filling the detergent and additives 4. To use liquid detergent, turn the flap down. Compartment for prewash phase, soak programme or stain remover. Compartment for washing phase. Compartment for liquid additives (fabric conditioner, starch). Maximum level for quantity of liquid additives.
- Page 17 ENGLISH 10.8 Starting a programme • The indicator of Start/Pause flashes. with the delay start • The display shows: the default temperature, the spin speed, the 1. Press button Zeitvorwahl again and indicators of the programme again until the display shows the phases and the programme number of minutes or hours of delay.
- Page 18 10.14 Draining water out after Before starting the new programme the appliance end of cycle could drain the water. In this The washing programme is completed, case, make sure that the but there is water in the drum: detergent is still in the...
-
Page 19: Hints And Tips
ENGLISH 11. HINTS AND TIPS 11.3 Detergents and additives WARNING! Refer to Safety chapters. • Only use detergents and additives specially made for washing machines: 11.1 The laundry load – powder detergents for all types of fabric, • Divide the laundry in: white, coloured, –... -
Page 20: Care And Cleaning
To know the water hardness in your area, Use the correct quantity of the water contact your local water authority. softener. Obey the instructions that you find on the packaging of the product. 12. CARE AND CLEANING 12.3 Maintenance wash WARNING! Refer to Safety chapters. - Page 21 ENGLISH 12.6 Cleaning the drain filter Do not clean the drain filter if the water in the appliance is hot.
- Page 22 www.aeg.com...
- Page 23 ENGLISH 12.7 Cleaning the inlet hose and the valve filter 45° 20° 12.8 Emergency drain 0° C, remove the remaining water from the inlet hose and the drain pump. Because of a malfunction, the appliance 1. Disconnect the mains plug from the cannot drain the water.
-
Page 24: Troubleshooting
13. TROUBLESHOOTING • - The appliance door is open or WARNING! not closed correctly. Please check the Refer to Safety chapters. door! 13.1 Introduction • - The mains supply is unstable. Wait until the mains supply is stable. The start of the appliance does not occur •... - Page 25 ENGLISH Problem Possible solution The appliance does not Make sure that the drain hose is in the correct position. The fill with water and drain hose may be too low. immediately. The appliance does not Make sure that the sink spigot is not clogged. drain the water.
-
Page 26: Technical Data
Problem Possible solution Add more laundry in the drum. The load may be too small. The cycle is shorter than The appliance calculates a new time according to the laundry the time displayed. load. See the ‘Consumption Values’ chapter. - Page 27 ENGLISH 15. ENVIRONMENT CONCERNS marked with the symbol with the Recycle the materials with the symbol household waste. Return the product to Put the packaging in applicable your local recycling facility or contact containers to recycle it. Help protect the your municipal office.
- Page 28 www.aeg.com/shop...
