TV Mount Installation Guide
Thank you for choosing Stanley – the hardware of choice
for Architects, Contractors, and Home Owners for its quality,
performance and dependability.
Enclosed are your step-by-step instructions for an install made
easy.
Model: TMR-105T
www.stanleymounts.com
Advertisement
Related Manuals for Stanley TMR-105T
Summary of Contents for Stanley TMR-105T
- Page 1 Model: TMR-105T TV Mount Installation Guide Thank you for choosing Stanley – the hardware of choice for Architects, Contractors, and Home Owners for its quality, performance and dependability. Enclosed are your step-by-step instructions for an install made easy. If you get stuck, give customer service a call at 1-855-816-6868 You can also reach us at contact@stanleymounts.com...
-
Page 2: Getting Started
Caution: Please read the entire manual before proceeding View warranty and disclaimer on page 14 Getting Started Before we start lets make sure we have the correct mount and all the required tools and hardware to complete the installation. The TV is a Flat Panel TV is between 32” - 60” and weighs no more than 55lbs. -
Page 3: Parts & Hardware
Caution: This product contains small items that could be a choking hazard if swallowed. Parts & Hardware Caution: Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts or previously used parts! Wall Plate Wall Plate Covers x2... - Page 4 Step 1: Attach Pull Cables to TV Attach Pull Cable to the TV bracket as show in the image.
- Page 5 Step 2: Attach Rails to TV Caution: Hand tighten with screwdriver only, Check what screw size will fit over tightening may damage the TV! in your TV. (F,G,H,I,J,K) Do not use a drill for this step! If your TV has a curved back F x4 you may need to use longer screws with spacers.
- Page 6 Step: 3A Install Wall Plate on Drywall with Wood Stud Note: For Concrete skip to Step 3B Use the stud finder to locate 2 studs. Then draw a vertical line on the center of each stud. Level the wall plate and align it with the center of the studs.
- Page 7 Remove the wall plate and drill the pilot holes with a 3/16” drill bit Align the wall plate with the pilot holes and insert 4 bolts through the washer in the pilot holes and tighten. Tools Required: Drill 3/16” Drill Bit...
- Page 8 Step: 3B Install Wall Plate on Concrete Level the wall plate and make 4 marks with pencil to show where to drill the pilot holes. Remove the wall plate and drill the pilot holes with a 3/8” drill bit. Tools Required: Pencil Level Drill Caution: The minimum depth of the concrete must be 8”.
- Page 9 Insert the anchors into the 4 pilot holes. Tap with a hammer Align the wall plate with the pilot holes and anchors and insert 4 bolts through the washer into the anchors and tighten. Tools Required: Hammer Wrench...
- Page 10 Step: 4 Hang Your TV Warning: Always use 2 people to lift your TV. To hang your TV, clip the TV Rails to the mounted wall plate. After the TV is hanging properly on the wall mount, press on the bottom of the TV to lock it in place.
- Page 11 Pull the release cords down while gently pulling the bottom of the TV from the wall. Install the wires for the TV. Push the bottom of the TV body onto bracket till you hear a “Click” “click” A “Click” ensures the TV is secured...
- Page 12 Usage: Magnet Tabs Take the magnet tabs hanging from the TV Mount and hang them on the metal frame of the TV Mount. Magnet Tabs...
- Page 13 Usage: Tilt Gently pull the top of the TV out to adjust the TV to the proper viewing angle. If you need to adjust the tension, use a screwdriver.
- Page 14 SUNCRAFT SOLUTIONS INC. LIMITED WARRANTY SUNCRAFT SOLUTIONS INC. LIMITED WARRANTY SUNCRAFT SOLUTIONS, INC. warrants its products to be free of defects in material and for a particular purpose and warranties of merchantability. SUNCRAFT SOLUTIONS, INC. will not workmanship for the product’s Warranty Period. The Warranty Period commences on the original be liable for any damages whatsoever arising out of the use or inability to use its products, even if purchase date of the product and the sales receipt serves as proof of purchase.
-
Page 15: General Disclaimer
GENERAL DISCLAIMER General Disclaimer Disclaimer – Suncraft Solutions Inc. has extended every effort to ensure to accuracy and is damaged or missing. In the event that replacement parts or hardware are needed, please contact completeness of this manual. However, Suncraft Solutions Inc. does not claim that the information Customer Service at 1-855-816-6868 or service@suncraftsolutions.com .
