- Page 1 OWNERS MANUAL LCD DISPLAY TD-P863 - TD-P863E For information on warranties and service please visit www.toshiba.eu/services...
-
Page 2: Table Of Contents
Contents Important Safety Information ........2 Vesa Wall Mount Measurements ......7 When Using a Wall Bracket ........7 Connecting to external equipment ......7 Daisy Chain Connection via HDMI Output .....9 Daisy Chain Connection via DisplayPort Output ..9 Control Buttons on the Display ......10 Turning the Display On/Off ........ -
Page 3: Important Safety Information
• Please place the product in a position that electric Important Safety cables cannot be affected by the operations on the product. Information • Follow all warnings and instructions marked on the product. CAUTION • Follow the on screen instructions for operating the related features. - Page 4 • Do not interfere on your products screen or any other Safety checks surface with a sharp object. Upon completion of service or repair work, request the service technician to perform safety checks to ensure • Do not keep your product in a humid environment. that the product is in proper operating condition.
- Page 5 monitor where it cannot be pushed, pulled over, or other than mentioned in user manual additional knocked down. requirements may be necessary. • Care should be taken to route all cords and cables connected to the monitor so that they cannot be pulled or grabbed by curious children.
- Page 6 Leaked battery Exclusion Clause fluid that gets into your eye or your clothing may Toshiba shall under no circumstances be liable for loss cause a skin irritation or damage your eye. and/or damage to the product caused by: CAUTION i) fire;...
- Page 7 but not limited to the following, loss of profit, Moving the Display: interruption of business, the loss of recorded data Moving the display requires at least four people. whether caused during normal operation or misuse Attempting to move the display with one person may of the product.
-
Page 8: Vesa Wall Mount Measurements
Vesa Wall Mount Measurements Hole Pattern Sizes (mm) Screw Sizes min. (mm) Length (X) max. (mm) Thread (Y) When Using a Wall Bracket Please use a wall bracket appropriate for the size and weight of the LCD display and two people are required for the installation. - Page 9 Rear Side (2) 1. Audio Out 2. Audio In 3. Ethernet 4. RJ12 (service use only) 5. Video In 6. YPbPr 7. SPDIF Coaxial Out English - 8 -...
-
Page 10: Daisy Chain Connection Via Hdmi Output
Daisy Chain Connection via HDMI Output DISPLAY 4 DISPLAY 3 DISPLAY 1 DISPLAY 2 HDMI In HDMI Out HDMI Cable • Maximum Connection w/HDCP: 7 • Maximum Connection wo/HDCP: No limit Daisy Chain Connection via DisplayPort Output DISPLAY 4 DISPLAY 3 DISPLAY 1 DISPLAY 2 DisplayPort In... -
Page 11: Control Buttons On The Display
Control Buttons on the Display To turn on the Display: Press the centre of the joystick in, the Display will turn on. To turn the Display off: Press the centre of the joystick in and hold it down for a few seconds, the Display will turn into standby mode. -
Page 12: Turning The Display On/Off
Turning the Display On/Off Press the Standby button on the remote or press the centre of the joystick in located on rear left side of the Display to switch it on from standby . Press the centre of the joystick in and hold it down for a few seconds or press the Standby button on the remote to switch display into standby mode. -
Page 13: Remote Control
Standby: Switches On / Off the Display Remote Control Numeric buttons: Enters a number or a letter in the text box on the screen. Signage: Displays Signage Settings menu Volume +/-: Increases or decreases the volume CMS: Opens the predefined Start url (in Signage Settings>Link options menu). -
Page 14: First Time Installation
USB device. not selectable. Please note this information as it Media Browser Menu will be required if contacting Toshiba regarding You can play photo, music and movie files stored on your monitor refer to the Signage Settings Menu a USB disk by connecting it to your Display. Connect... -
Page 15: Cec And Cec Rc Passthrough
This feature will only work if all of the following cir- case volume control keys are directed to connected cumstances occur: audio device. • The USB device is plugged in. Note: ARC is supported only via the HDMI1 input. System Audio Control •... -
Page 16: Display Menu Contents
Display Menu Contents System - Picture Menu Contents You can change the picture mode to suit your preference or requirements. Picture mode can Mode be set to one of these options: Text, Game, Sports, Signage and Natural. Signage mode has been developed to enhance Dynamic contrast, colors and sharpness levels. Contrast Adjusts the light and dark values on the screen. - Page 17 System - Sound Menu Contents Volume Adjusts the volume level. Equalizer Selects the equalizer mode. Custom settings can be made only when in User mode. Balance Adjusts whether the sound comes from the left or right speaker. Sets headphone volume. Please ensure before using headphones that the headphone volume is set to a low Headphone level, to prevent damage to your hearing.
- Page 18 Save model Copies the model information data of the unit to a connected USB device. This information information will be required is you contact Toshiba about your monitor Display Life Time Displays the duration of life of the unit. Controls Sets the OSD (On Screen Display) rotation of your Display.
- Page 19 Select ASCII/HEX protocol for UART 0. Default value is ASCII. There is no need to restart the Display after selection in order to work with the protocols correctly. If the selection is changed, the latest selected protocol will be preserved and started when UART 0 the Display is booted up.
- Page 20 You will need to enter the correct PIN to carry out this operation. installation Note: Enter the PIN you have defined during the First Time Installation process. If you have forgotten the pin used, please contact Toshiba service center. English - 19 -...
-
Page 21: Connectivity
them more convenient to use on a home network. This Connectivity standard allows you to view and play photos, music and videos stored on your media server connected to your To configure wired or wireless settings please refer home network. to the Network/Internet Settings section in the 1. -
Page 22: Internal Usb Operations
be displayed as Speed Dial options along with the Internal USB Operations Edit Speed Dial and the Add to Speed Dial options. Your Display has an internal memory. There are 4 You can press the Internet button on the remote operations available that can be performed with the to open the initial internet browser page. -
Page 23: Hdmi Out
a splitter. In this case, same image will be displayed external power source, RTC is able to function for in all connected Displays. a minimum of 14 days. To be able to stream the same image to all connected • If RTC is used as time source, manual date- Displays using a MST compliant device, DP Stream time set is enabled from Date/Time option in the Setting option in the System>Settings>More menu... -
Page 24: Video Wall Settings
Display to a network and displaying the IP address of the Display. Use the commands in the RS232 Command Table which can be found on Toshiba website.For Video Wall Settings example, if “GETVOLUME” command is entered,... -
Page 25: Scheduler Settings
maximum number that can be set is 50. For example; RS232 HEX COMMANDS For a 2x3 video wall matrix, Row count option should be set as 2 and Column count option should be set Protocol Test Steps as 3. Number of cells in a video wall matrix will be RJ12 and DSUB9 both are connected to UART determined as shown in the template below. -
Page 26: System Features
System Features Panel Panel type 86” (218cm) 24/7 ELED Resolution 3840x2160 1895.04(H) x Active Area 1065.96(V) Horizontal 178° Visual angle Perpendicular 178° Max. brightness Typ : 500 cd/m² Max. Contrast Typ : 1200 Response time H-Frequency 270 kHz V-Frequency 120 Hz Audio 2 x 12 W Audio Output Power Network Connection... - Page 27 Using Your LCD display Product More Effectively Paying attention to the following points with respect to your product will provide a stable performance and also prolong its life. Daily Care • Environmental Factors Do not directly expose your product to humidity, high temperature, fire, direct sun light and dust while using it. The vent holes of your product will allow it perform safer without system overheating.
-
Page 28: Notification
Notification TRADEMARK ACKNOWLEDGMENT The terms HDMI and High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. Manufactured under license from Dolby Laboratories. Dolby Audio and the double-D symbol are trademarks of Dolby laboratories. -
Page 29: Trouble Shooting & Tips
Trouble Shooting & Tips Display does not turn on Make sure the power cord is plugged in securely to the mains socket. Check if batteries are of the remote exhausted. Press the Standby button on the Display. No picture This means your Display is not receiving any signal. Check if the correct source is selected. - Page 30 Dimensions Unit (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) 86” 1146 1975 1899 1069 Weight : 66 Kg English - 29 -...
- Page 31 Disposal... The following information is only for EU-member states: Disposal of products The crossed out wheeIed dust bin symbol indicates that products must be collected and disposed of separately from household waste. Integrated batteries and accumulators can be disposed of with the product. They will be separated at the recycling centres.
