Sony Walkman ICF-CD823 Operating Instructions

FM/AM
CD Clock Radio
Operating Instructions
Dream Machine is a trademark of Sony Corporation.
ICF-CD823
Sony Corporation 2000
Printed in Malaysia
Owner's Record
3-046-170-21 (1)
The model number and the serial number are
located on the bottom.
Record the serial number in the space provided
below. Refer to them whenever you call upon
your Sony dealer regarding this product.
Model No. ICF-CD823
Serial No.
WARNING
To prevent fire or shock
hazard, do not expose the
unit to rain or moisture.
This symbol is intended to alert the user
to the presence of uninsulated
"dangerous voltage" within the
product's enclosure that may be of
sufficient magnitude to constitute a risk
of electric shock to persons.
This symbol is intended to alert the user
to the presence of important operating
and maintenance (servicing) instruc-
tions in the literature accompanying the
appliance.
The graphical symbols are on the bottom of the
enclosure.
INFORMATION
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the
equipment and receiver.
—Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/
TV technician for help.
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate
this equipment.
CAUTION
The use of optical instruments with this
product will increase eye hazard.
Before You Begin
Thank you for choosing the Sony CD clock radio!
It will give you many hours of reliable service
and listening pleasure.
Before operating the unit, please read these
instructions thoroughly and retain them for
future reference.
Features
• Built-in CD Player with Shuffle/Repeat
function.
• You can wake up to any track of a CD.
• PLL (Phase Locked Loop) Synthesized Tuner
with 5 random memory presets for easy one
button tuning.
• Dual alarm.
• Alarm setting dial—easy to set alarm time and
modes.
• Extendable snooze—snooze time can be
extended from 8 to 60 minutes in maximum
every time you use.
• Summer time (daylight saving time)
calculation.
Precautions

IMPORTANT SAFEGUARDS

• Operate the unit on the power source
specified in the "Specifications."
For your protection, please read these safety instructions completely before operating the
• The nameplate indicating operating voltage,
appliance, and keep this manual for future reference.
etc. is located on the bottom of the unit.
Carefully observe all warnings, precautions and instructions on the appliance and described in
• To disconnect the power cord (mains lead),
the operating instructions supplied with the appliance by Sony.
pull it out by the plug, not the cord.
• Do not leave the unit in a location near a heat
INSTALLATION
source such as a radiator or airduct, or in a
place subject to direct sunlight, excessive dust,
Water and Moisture
mechanical vibration, or shock.
• Allow adequate air circulation to prevent Do not install the appliance near water: for example, near a bathtub, washbowl, kitchen sink,
internal heat build-up. Do not place the unit laundry tub, in a wet basement, or near a swimming pool.
on a surface (a rug, a blanket, etc.) or near
Heat
materials (a curtain) which might block the
ventilation holes. Do not install the appliance near sources of heat such as radiators, heat registers, stoves, or
• Should any solid object or liquid fall into the
other appliances that produce heat.
unit, unplug the unit and have it checked by a
Ventilation
qualified personnel before operating it any
further.
Slots and openings in the cabinet and in the back or bottom are provided for necessary ventilation.
• When the casing becomes soiled, clean it with
To ensure reliable and safe operation of the appliance, and to protect it from overheating, these
a soft cloth dampened with mild detergent
slots and openings must never be blocked or covered.
solution. Never use abrasive cleansers or
Do not place the appliance on a bed, sofa, rug or other similar surface which may block the slots
chemical solvents, as they may mar the casing.
and openings.
If you have any questions or problems
Do not install the appliance in a confined space, such as a bookcase or built-in cabinet, unless
concerning your unit, please consult your
proper ventilation is provided.
nearest Sony dealer.
Carts and Stands
Do not install the appliance on an unstable table, shelf, cart or stand. Use only a cart or stand
Troubleshooting
recommended by Sony.
An appliance and cart combination should be moved with care. Quick stops, excessive force, and
Should any problem occur with the unit, make
uneven surfaces may cause the appliance and cart combination to overturn.
the following checks to determine whether or not
servicing is required. If the problem persists, Wall or Ceiling Mounting
consult the nearest Sony dealer.
If your appliance can be mounted to a wall or ceiling, mount it only as recommended by Sony.
The clock does not show the correct time.
USE
• Has an electrical power outage lasting more
than one minute occurred?
Power Source
The CD, radio or buzzer alarm does not sound
Connect the appliance to a power supply only of the type described in the operating instructions
at the preset alarm time.
or as marked on the appliance.
• Is the alarm setting dial set to the desired
ALARM MODE?
Grounding or Polarization
The radio alarm is activated but no sound
Do not defeat the grounding or polarization feature of the AC power cord. If your AC receptacle
comes on at the preset alarm time.
will not accept the power cord plug, contact your electrician to install a proper AC receptacle.
• Has a station been preset onto preset button
1?
AC Receptacle
• Has VOLUME been adjusted ?
Check to make sure that the AC receptacle holds the power cord plug firmly and securely. If the
The CD player does not operate.
power cord plug is loose, contact your electrician to replace the defective and unsafe AC
• Did you close the CD lid?
receptacle.
• Did you place the disc correctly?
The disc should be placed with the labeled Power-Cord Protection
side up.
Route the power cord so that it is not likely to be walked on or pinched by having objects placed
• Dusty or defective disc—Clean the disc with
on it, paying particular attention to the plugs, receptacles, and the point where the cord exits from
an optional cleaning cloth. Wipe the disc from
the appliance.
the center out.
• Take out the CD and leave the CD
When not in use
compartment open for about an hour to get
Unplug the power cord of the appliance from the outlet when left unused for a long period of
rid of moisture condensation.
time.
Sporadic loss of sound in CD operation.
To disconnect the cord, pull it out by grasping the plug. Never pull the plug out by the cord.
• Dusty or defective disc—Clean or replace the
disc.
Foreign Objects
• Volume too high—Reduce the volume.
Be careful that foreign objects and liquids do not enter the enclosure through openings.
• Strong vibration.
Cleaning
No sound comes from the speakers.
• Hasn't the alarm setting dial been remained
Clean the appliance only as recommended by Sony.
setting to ALARM TIME SET?
ANTENNAS
Outdoor Antenna Grounding
Specifications
If an outdoor antenna or cable system is installed, follow the precautions below.
CD player section
An outdoor antenna system should not be located in the vicinity of overhead power lines or other
System: Compact disc digital audio system
electric light or power circuits, or where it can come in contact with such power lines or circuits.
Laser diode properties: Material: GaAlAs WHEN INSTALLING AN OUTDOOR ANTENNA SYSTEM, EXTREME CARE SHOULD BE
Wavelength: 780 nm
TAKEN TO KEEP FROM CONTACTING SUCH POWER LINES OR CIRCUITS AS CONTACT
Emission duration: Continuous
WITH THEM IS ALMOST INVARIABLY FATAL.
Laser output: Less than 44.6 µW
Be sure the antenna system is grounded so as to provide some protection against voltage surges
(This output is the value measured at a
and built-up static charges. Section 810 of the National Electrical Code provides information with
distance of about 200 mm from the objective
respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to
lens surface on the optical pick-up block with
7mm aperture.) an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements for the grounding electrode.
Frequency response: 20-20,000 Hz +1 dB
–1.5
Wow and flutter: Below measurable limit
Antenna Grounding According to the National
Radio section
Electrical Code
Frequency range:
FM: 87.5-108 MHz
AM: 530-1,710 kHz
Channel step:
FM: 0.1 MHz (fixed)
AM: 10 kHz (fixed)
General
Time display:
12-hour system
Speaker:
1
77 mm (3 / inches) dia., 8
8
Power outputs:
1.2W + 1.2W (at 10% harmonic distortion)
Power requirements:
120 V AC, 60 Hz
Dimensions:
Approx. 250 153 207 mm(w/h/d)
(Approx. 9 7 / 6 1 / 8 1 / inches) incl.
8 8 4
projecting parts and controls —NEC National Electrical Code—
Mass:
Approx. 1,700 g (3 lb 12 oz)
Design and specifications are subject to change
SERVICE
without notice.
Unplug the appliance from the wall outlet and consult qualified service personnel when:
-the power cord or the plug has been damaged.
-a solid object or liquid has fallen into the cabinet.
-the appliance has been exposed to rain or moisture.
-the appliance does not appear to operate normally or exhibits a marked change in performance.
-the appliance has been dropped, or the enclosure damaged.
Do not attempt to service the appliance beyond that described in the operating instructions. For
all other servicing refer to qualified service personnel only.
Antenna Lead-in Wire
Antenna Discharge Unit
Ground Clamps
(NEC* Section 810-20)
Grounding Conductors
Electric Service (NEC* Section 810-21)
Equipment
Ground Clamps
Power Service Grounding
Electrode System
(NEC* Art 250 Part H)
