Sony VAIO PCV-J200 Specifications

Video Audio Integrated Operation
FEATURES
• 900 MHz † AMD Duron ™ processor
• 200 MHz FSB
• 128 MB PC-133 SDRAM (expandable to 512 MB)
††
• 40 GB Ultra ATA/100 Hard Drive
• DVD/CD-RW Combo Drive
• High-speed Internet ready with
10Base-T/100Base-TX Fast Ethernet
®
• i.LINK (IEEE 1394) interface and
1

USB connections

™
• Programmable VAIO Smart Keyboard
• V.90 compatible data/fax modem
• Wheel mouse
• External stereo speakers
Sony Electronics Inc.
Personal Network Solutions Company
16765 West Bernardo Drive, San Diego, CA 92127
For more information: 1.800.4SONYPC (476-6972)
Web address: http://www.sony.com/vaio
Computer Interface: The computer industry lacks standards, and therefore, there are a
multitude of varying software packages and add-on hardware options. This personal computer
is not manufactured to any specific software, and Sony does not and cannot make any
warranty or representation with respect to the performance of this product with any particular
software packages and/or non-Sony add-on hardware option except those mentioned in this
document. Sony hereby disclaims any representations or warranty that this product is
compatible with any combination of non-Sony products you may choose to connect. While
Sony representatives or Sony authorized dealers may be able to assist you and may make
recommendations, they are NOT authorized to vary or waive this disclaimer. Purchasers must
determine for themselves the suitability and compatibility of the hardware and software in each
and every particular instance. Some pre-installed software titles may not include full
documentation. Software titles pre-installed on the Sony Desktop Computer are subject to
change without notice. Simulated graphic shown on display.
©2001 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without
written permission is prohibited. Sony, i.LINK, Multiscan, Trinitron, DVgate, Media Bar,
MovieShaker, PictureGear, and VAIO are trademarks of Sony. Intel, the Intel Inside logo, and
Pentium are registered trademarks of Intel Corporation. Microsoft, Windows and the Windows
logo are trademarks of Microsoft Corporation. All other trademarks are trademarks of their
respective owners. This product meets the standards of the International Energy Star Program
for energy efficiency. Features and specifications are subject to change without notice.
Non-metric weights and measurements are approximate.
Printed in U.S.A. 1/01
900 MHz
Home Movie Editing
DVD/CD-RW Combo Drive
®
i.LINK
and USB Connectors
10Base-T/100Base-TX Fast Ethernet

ADDITIONAL SPECIFICATIONS

Model
PCV-J200
Processor
† ™
900 MHz AMD Duron Processor
Cache Memory
192 KB total on chip
Front Side Bus Speed
200 MHz
Standard RAM
128 MB PC-133 SDRAM, expandable to 512 MB
Hard Drive
40 GB †† Ultra ATA/100 Hard Drive
DVD-ROM/CD-RW Combo Drive
4.8X max.DVD-ROM
4x4x24 max. CD-RW
Floppy Disk Drive
3.5" 1.44 MB Floppy Disk Drive
Modem
V.90 Modem
Ethernet
10Base-T/100Base-TX Fast Ethernet
Expansion Slots
Four PCI (two occupied)
Expansion Bays
One External 5.25" Half-Height (one occupied)
One External 3.5" (occupied)
Two Internal 3.5" (one occupied)
Port Connectors
Three USB (three rear)
One PS/2 ® Mouse
One PS/2 Keyboard
One VGA
One Serial
One Parallel
One 6pin i.LINK
One Headphone Out
One Line In
One Microphone
Supplied Accessories
Speakers
VAIO Smart Keyboard
PS/2 Wheel Mouse
RJ-11 Phone Cord
Power Cord
Power Requirements
100-120V -3A (50/60Hz)
Power Management
ACPI 1.0 Compliant
Advanced Power Management (APM version 1.2)
PCV-J200
Sony VAIO PC
† ™
AMD Duron processor
(IEEE 1394) Interface
1
Dimensions (CPU)
6.7"(W) x 12"(H) x 14.4"(D)
Weight (CPU)
18.7 lbs.
Service
One Year Limited Expressed Repair Service (upon
registration; 90 days without registration)*
Limited Warranty
One Year Parts and Labor (upon registration; 90 days
without registration)*
Telephone Support
Hardware: One Year
Software and Operating System: 90 Days
Pre-Installed Software
Operating System
Microsoft ® Windows ®
Sony Original Software
DVgate ™
Media Bar ™
MovieShaker ™
OpenMG ™ Jukebox
PictureGear ™
Smart Capture
™
VisualFlow
Other Software Applications
™
Adaptec Direct CD
Adaptec Easy CD Creator
®
Adobe Acrobat Reader
®
Adobe Photo Deluxe
™
Apple QuickTime
ArcSoft PhotoPrinter 2000 Pro
Corel ® WordPerfect ®
Quicken ® 2001 New User Edition
Microsoft ® Outlook ® Express
VAIO Smart ™ Keyboard
Online Center
America Online ® **
CompuServe ® 2000**
EarthLink TotalAccess
Netscape ® Communicator
Prodigy Internet ™ **
Tool Center
McAfee VirusScan
Sony Application Recovery CD(s)
Sony System Recovery CD(s)
† MHz denotes microprocessor internal clock speed; other factors may
affect application performance.
†† GB means one billion bytes when referring to hard drive capacity.
Accessible capacity may vary.
* Certain restrictions apply.
** Requires payment of additional fees or subscription for use.
1 i.LINK is a trademark of Sony used only to designate that a product
contains an IEEE 1394 connector. All products with an i.LINK connector
may not communicate with each other.
®
i.LINK
(IEEE 1394)
Millennium Edition
™
™ **
®
