Sharp EL-6710S Service Manual

L Name : LI-359003
S
Type : CHIP
I
POWER SUPPLY AC :
POWER SUPPLIES
AC ADAPTOR
MEMORY PROTECT
DIMENSIONS (mm) (When OPEN)
149.6 (W) 176.5 (D) 9.0 (H)
(When CLOSED)
149.6 (W) 91.0 (D) 13.0 (H) (mm)
CALCULATIONS
Four arithmetic calculation, Constant calculation, Power
calculation, Chain calculation, Reciprocal calculation, %
calculation, Add-on (discount) calculation
Parts marked with "
ones for maintaining the safety and performance of the set.
SERVICE MANUAL
X DC : O
CR2032 x 1 pc
0.003 W
Approx. 7 minutes
Yes
" is important for maintaining the safety of the set. Be sure to replace these parts with specified
SHARP CORPORATION
REPLACEMENT MODEL
EL-6710S
MODEL
STANDARD FUNCTION
D
I
S
P
L
A
Y
ELEMENT : TN-LCD
S
UPPER LINE : 12 digits
NUMERAL :
E
LOWER LINE : 12 digits
C
T
I
O
N
KEY SYSTEM : Rubber key
OTHER SPECIFICATIONS
Display :
3 lines of 12 digits
Memory capacity : 34,440 bytes
Clock mode :
Accuracy : 30 seconds / month at 25°C / 77°F
–
Display : Year, month, date, day of the week, hour, minute,
seconds, AM / PM
Clock system : 12 hour / 24-hour format (switchable), world clock
function, daylight saving time / summer time display,
daily alarm
Telephone mode
(Business, Personal,
Entry and recall of telephone listing (name, number,
Other) E-mail address, URL)
Schedule mode :
Entry and recall of schedule (year, month, day, hour,
minute and item), day of the week confirmation,
schedule alarm
Calculator mode : 12 digits (with calculation status symbols) arithmetic
calculations, percentage, square root, memory
calculation, etc.
Currency / unit
Conversion :
A kinds of currencies and unit (editable on the display)
Operating temperature : 0 to 40 °C (32°F to 104°F)
Power supply : 3V ... (DC) (Lithium battery CR2032 x 1)
Battery life : Approx. 2 year at ambient temperature of 25°C (77°F),
assuming the following daily use : 30 minutes display,
alarm sounding for 20 seconds and key touch tone
turned on / off 100 times.
Weight : Approx. 115 g (including battery)
Accessories :
1 lithium battery (installed), operation manual
12 digits 1M
PARTS NAME : CH-70189
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
TS
