/Supplied accessories

1 遙控器（ 2 支） 2 "AAA"型鹼性電池（ 4 顆）
Remote control unit "AAA" size battery
( g 2)
Type A Type B
Stand unit
台座單位
5 台 座 基
4 台座安裝托架 (1 個 )
Stand mounting bracket
( g 1)
7 台座封蓋 (1 個 )
8 腳架旋轉鎖定螺絲
Stand cover Swivel lock screw
( g 1)
B. 裝入電池 Inserting the batteries
1 2
Type A
1 2
Type B
•
在裝入電池時，要注意電池端子 的極性要與電池艙內的極性標記（e）和（f）一致。
Place batteries with their terminals corresponding to the (e ) and f
battery compartment.
Caution
•
不可置換可能影響安全防護的錯誤型式的電池（例如，在某些鋰電池類型的情况下）。
Replacement of a battery with an incorrect type that can defeat a safeguard (for example, in the case of some lithium
battery types).
•
不可將電池丟入火焰或烤箱中，或將其擠壓或切割，都可能導致爆炸。
Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, can result in an explosion.
•
不可將電池置於可能爆炸或可燃性液體或氣體洩漏的高溫環境中。
Leaving a battery in an extremely high temperature surrounding environment can result in an explosion or the leakage
of flammable liquid or gas.
•
不可將電池置於可能導致爆炸或可燃性液體或氣體洩漏的極度低氣壓。
A battery subjected to extremely low air pressure may result in an explosion or the leakage of flammable liquid or gas.
•
如果更換的電池類型不正確，則有發生火災或爆炸的風險。
Risk of fire or explosion if the battery is replaced by an incorrect type.
Initial setup guide
3 初始設定指南
Warranty Certificate
( g 4)
保證書
Stand base
座 (1 個 ) ( g 1)
6 螺 絲 釘 ( 8 顆）
Screws
( g 8)
交流電源線
(1 顆) 9 (1 根)
AC cord
( g 1) ( g 1)
3
2"AAA"型鹼性電池
"AAA" size battery
3
2"AAA"型鹼性電池
"AAA" size battery
( ) indications in the
Recycle the battery

/Attaching the stand

組裝前請檢查以下注意事項。
1) 不要把顯示器螢幕向下。
Do not lay the Monitor
screen down.
將台座安裝托架插入台座基座。
To insert stand mounting bracket to stand base.
Back
用四顆用於組裝台座的螺絲固定台座安裝托架與
台座基座。
Fix the stand mounting bracket and the stand base with
four screws for assembling the stand.
前
Front
Take out the Monitor.
拿出顯示器
1) 撕掉顯示器螢幕一側的膠帶，然後請把袋子滑下
來。
Peel off the tape on the Monitor screen side and slide
the bag down.
2) 顯示器裝完成前請勿取下螢幕保護墊。
Do not remove the screen protection pad until the
Monitor installation is complete.
- 3 - 4
CT CT
Please check the following precautions before assembling.
2) 不要取下螢幕保護墊（紙板） 3) 始終與兩個或更多人一起工作。
請勿握住顯示器的四個角。
保護螢幕直到安裝完成。
To protect the screen, do not remove Always work with two or more people.
the screen protector pad (cardboard) Do not hold the four corners of the
until installation is complete. Monitor.
螢幕保護墊
Screen protector pad
台座安裝托架
4
Stand mounting
bracket
前
Front
確保與兩個或更多人一起工作。
Ensure to work with two or more people.
5 台座基座
將顯示部分垂直安裝到台座安裝托架上。
後
Stand base
Attach the display part to the stand mounting bracket in
an upright position.
6 螺 絲 釘
Screws
後
Back
Caution
• 小心不要讓您的手指夾在顯示部分和台座安裝托
架之間。
Be careful not to get your fingers caught between the
display part and the stand mounting bracket.
A
如示例圖所示，與
台座安裝托架中心
的 A 對齊。
Align with A in the
center of the stand
mounting bracket as
shown in the
example figure.
B
慢慢放下顯示部分，
使顯示部分的 B 卡
台座安裝 托架
在 上。
Slowly lower the
display part so that B
of the display part is
caught in the stand
mounting bracket.
