Sony KP-61V90 Dimension Manual

KP-61V90

FRONT VIEW

36 3/8"
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION
RECOMMEND THAT THE PRODUCT ITSELF
MEASUREMENTS.
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX (201) 986 3062 • b2b.sel.sony.com
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
TOP VIEW
48 3/4 "
54 "
48 1/2 "
61"
SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
61" Projection TV
DESCRIPTION:
DIMENSIONS
(WHD): 54" x 61 1/2" x 26 1/2 "
WEIGHT :
186 Lbs (approx.)
S-
Video
24 3/8"
Video
L
MONO
Audio
12 1/4"
R
61 1/2
40 1/2"
20 1/2"
BE USED TO MAKE THE ACTUAL
POWER
REQUIREMENTS:
POWER
CONSUMPTION: 170w(max)
JACK PACK
IN
Video 1 Video 3 Video 4
OUT
VHF/UHF
AUDIO
Fix/Var
Y
L
Pb
MONO
Audio
R
Pr
26 1/2"
WE
120V AC
60Hz
1w(stby)
AUX
CONV
