OWNER'S MANUAL
BOTTOM FREEZER
REFRIGERATOR
Read this owner's manual thoroughly before operating the
appliance and keep it handy for reference at all times.
ENGLISH
LBNC12231* / LBNC12241* / LBNC12251*
www.lg.com
MFL71400030
Copyright © 2019-2020 LG Electronics Inc. All Rights Reserved.
Rev.06_121120
Advertisement
Table of Contents
Related Manuals for LG LBNC12251V.APZCNA0
Summary of Contents for LG LBNC12251V.APZCNA0
- Page 1 OWNER’S MANUAL BOTTOM FREEZER REFRIGERATOR Read this owner's manual thoroughly before operating the appliance and keep it handy for reference at all times. ENGLISH LBNC12231* / LBNC12241* / LBNC12251* www.lg.com MFL71400030 Copyright © 2019-2020 LG Electronics Inc. All Rights Reserved. Rev.06_121120...
-
Page 2: Table Of Contents
14 OPERATION Before Use Control Panel Sabbath Mode Water Dispenser Storing Food Humidity Controlled Crispers Refrigerator Shelves Door Bins 21 SMART FUNCTIONS LG ThinQ Application Smart Diagnosis 22 MAINTENANCE Cleaning 23 TROUBLESHOOTING FAQs Before Calling for Service 29 LIMITED WARRANTY CANADA... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Safety Messages Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and follow all safety messages. - Page 4 IMPORTANT SAFETY INSTRUCTIONS • Do not bend or pinch the power cord excessively or place heavy objects on it. Operation • This appliance is intended to be used in household and similar applications such as: - staff kitchen areas in shops, offices and other working environments; - farm houses and by clients in hotels, motels and other residential type environments;...
- Page 5 IMPORTANT SAFETY INSTRUCTIONS Maintenance • Do not use a hair dryer to dry the inside of the refrigerator. • Do not light a candle to remove odors in the refrigerator. • In the event of a refrigerant leak, move flammable objects away from the refrigerator. Ensure the area is adequately ventilated and contact an authorized service center.
-
Page 6: Caution
IMPORTANT SAFETY INSTRUCTIONS Risk of Fire and Flammable Materials This appliance contains a small amount of isobutane refrigerant (R600a), which is combustible. When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged. Refrigerant squirting out of the pipes could ignite or cause an eye injury. -
Page 7: Product Overview
PRODUCT OVERVIEW PRODUCT OVERVIEW Product Features The images in this guide may be different from the actual components and accessories, which are subject to change by the manufacturer without prior notice for product improvement purposes. Exterior Refrigerator Fresh food compartment. Freezer Frozen food compartment. - Page 8 PRODUCT OVERVIEW Interior † This feature is only available on some models. Control Panel Sets the refrigerator and freezer temperatures. LED Interior Lighting Lights up the inside of the refrigerator. Adjustable Refrigerator Shelf The refrigerator shelves are adjustable to meet individual storage needs. †...
- Page 9 PRODUCT OVERVIEW • Do not use the egg tray in the freezer. To keep eggs fresh longer, do not store them on the top shelf of the refrigerator or in the vegetable drawer. Door Bin Stores chilled food, drinks, or condiments. †...
-
Page 10: Installation
10 INSTALLATION INSTALLATION Before Installing label, or the Tech Sheet that is located under the front of the refrigerator. • To remove any remaining tape or glue, rub the Installation Overview area briskly with your thumb. Tape or glue Please read the following installation instructions residue can also be easily removed by rubbing a first after purchasing this product or transporting small amount of liquid dish soap over the... - Page 11 INSTALLATION Ambient Temperature Install this appliance in an area where the temperature is between 55 °F (13 °C) and 110 °F (43 °C). If the temperature around the appliance is too low or high, cooling ability may be adversely affected. Installing the Rear Spacers This feature is only available on some models.
-
Page 12: Reversing Doors And Leveling
12 INSTALLATION Dimensions and Clearances • Check the dimensions of the appliance and the installation path to ensure there is sufficient room to move the refrigerator through doors or narrow openings. • The installation location chosen for the refrigerator should allow space behind the unit for connections and airflow and space in front to open the doors and drawers. -
Page 13: Turning On The Power
INSTALLATION NOTE • A flare nut wrench works best, but an open-end wrench will suffice. Do not over-tighten. Open both doors, and check to make sure that they close easily. If the doors do not close easily, tilt the refrigerator slightly more to the rear by turning both leveling legs to the left. -
Page 14: Operation
14 OPERATION OPERATION Before Use Checklist Clean the refrigerator. Clean the refrigerator thoroughly and wipe off all dust that accumulated during shipping. CAUTION • Do not scratch the refrigerator with a sharp object or use a detergent that contains alcohol, a flammable liquid or an abrasive when removing any tape or adhesive from the refrigerator. -
Page 15: Control Panel
OPERATION Control Panel Depending on the model, some of the following functions may not be available. The actual control panel may differ from model to model. Control Panel Features Freezer Indicates the set temperature of the freezer compartment in Fahrenheit (°F). The default freezer temperature is 0°F. -
Page 16: Sabbath Mode
Clean water tank periodically and keep them clean • If water dispenses unexpectedly, turn off the at all times. water supply and contact an LG Electronics Customer Information Center. Hold the handle of the water tank and lift it. NOTE •... -
Page 17: Storing Food
OPERATION Lift the water tank and pull it out. CAUTION • Keep children away from the dispenser to prevent children playing with or damaging the controls. • Do not hang on to or place heavy objects on the refrigerator’s dispenser. NOTE •... - Page 18 18 OPERATION • Vegetables with skins (carrots, peppers) NOTE - Place in plastic bags or plastic container and • If doors are opened or closed too often, warm store in crisper. air may penetrate the refrigerator and raise its • Fish temperature.
-
Page 19: Humidity Controlled Crispers
OPERATION Type A NOTE • Allow hot foods to cool at room temperature for 30 minutes, and then package and freeze. Cooling hot foods before freezing saves energy. Packaging Successful freezing depends on correct packaging. When you close and seal the package, it must not allow air or moisture in or out. -
Page 20: Refrigerator Shelves
20 OPERATION Refrigerator Shelves To assemble the bin, slide it in above the desired support and push down until it snaps The shelves in the refrigerator are adjustable to into place. meet individual storage needs. CAUTION Adjusting the shelves to fit items of different heights will make finding the exact item you want •... -
Page 21: Smart Functions
SMART FUNCTIONS SMART FUNCTIONS LG ThinQ Application • Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow the instructions for audible diagnosis provided This feature is only available on models with the in the LG ThinQ application. -
Page 22: Maintenance
22 MAINTENANCE MAINTENANCE Cleaning To help remove odors, wash the inside of the refrigerator with a mixture of baking soda and warm water. Mix 2 tablespoons of baking soda to 1 WARNING quart of water (26 g soda to 1 liter water.) Be sure the baking soda is completely dissolved so it does •... -
Page 23: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING FAQs Frequently Asked Questions What are the best temperature settings for my refrigerator and freezer? The default setting for the refrigerator is 37° Fahrenheit (3° Celsius). The default setting for the freezer is 0° Fahrenheit (-18° Celsius). Adjust these settings as necessary to keep food at desired temperatures. - Page 24 24 TROUBLESHOOTING Problem Possible Cause & Solution Cooling system runs Refrigerator is replacing an older model. too much. • Modern refrigerators require more operating time but use less energy due to more efficient technology. Refrigerator was recently plugged in or power restored. •...
- Page 25 TROUBLESHOOTING Problem Possible Cause & Solution Refrigerator or Incorrect temperature control settings. Freezer section is too • If the temperature is too cold, adjust the control one increment at a time and wait for the cold. temperature to stabilize. Refer to the Control Panel for more information. Frost or ice crystals Condensation from food with a high water content has frozen inside of the food form on frozen food...
- Page 26 26 TROUBLESHOOTING Problem Possible Cause & Solution Icemaker is not Doors are opened often or for long periods of time. making enough ice. • If the doors of the unit are opened often, ambient air will warm the refrigerator which will prevent the unit from maintaining the set temperature.
- Page 27 TROUBLESHOOTING Problem Possible Cause & Solution Refrigerator wobbles Leveling legs are not adjusted properly. or seems unstable • Refer to the Reversing Doors and Leveling section. Floor is not level. • It may be necessary to add shims under the leveling legs or rollers to complete installation. Lights do not work.
- Page 28 28 TROUBLESHOOTING Problem Possible Cause & Solution Pulsating or high- Your refrigerator is designed to run more efficiently to keep your food items at the pitched sound desired temperature. The high efficiency compressor may cause your new refrigerator to run longer than your old one, but it is still more energy efficient than previous models.
-
Page 29: Limited Warranty
Should your LG Refrigerator ("Product") fail due to a defect in materials or workmanship under normal and proper use, during the warranty period set forth below, LG will, at its option, repair or replace the Product. This limited warranty is valid only to the original retail purchaser of the Product (“You”) and applies only when purchased lawfully and used within the United States... - Page 30 Or by mail: LG Electronics Customer Service P.O. Box 240007 Huntsville, AL 35813 ATTN: CIC PROCEDURE FOR RESOLVING DISPUTES: ALL DISPUTES BETWEEN YOU AND LG ARISING OUT OF OR RELATING IN ANY WAY TO THIS LIMITED WARRANTY OR THE PRODUCT SHALL BE RESOLVED EXCLUSIVELY THROUGH BINDING ARBITRATION, AND NOT IN A COURT OF GENERAL JURISDICTION.
- Page 31 Notice of Dispute. In the event you intend to commence an arbitration proceeding, you must first notify LG in writing at least 30 days in advance of initiating the arbitration by sending a letter to LG at LG Electronics, USA, Inc. Attn: Legal Department- Arbitration 111 Sylvan Avenue, Englewood Cliffs, NJ 07632.
- Page 32 Opt Out. You may opt out of this dispute resolution procedure. If you opt out, neither you nor LG can require the other to participate in an arbitration proceeding. To opt out, you must send notice to LG no later than 30 calendar days from the date of the first consumer purchaser’s purchase of the product by...
-
Page 33: Canada
ARE NOT PERMITTED. PLEASE SEE THE SECTION TITLED “PROCEDURE FOR RESOLVING DISPUTES” BELOW. Should your LG Refrigerator ("Product") fail due to a defect in materials or workmanship under normal and proper use, during the warranty period set forth below, LG Electronics Canada, Inc. (“LGECI”) will, at its option, repair or replace the Product upon receipt of proof of the original retail purchase. - Page 34 (ASC), as determined by LG Canada. If your Product is located outside a 150 km radius from a ASC, as determined by LG Canada, it will be your responsibility to bring the Product, at your sole expense, to the ASC for in-warranty repair.
- Page 35 If you and LG are unable to resolve the dispute within 30 days of LG’s receipt of the Notice of Dispute, the dispute shall be resolved by binding arbitration in accordance with the procedure set out herein.
- Page 36 Except as otherwise provided for, LG waives any rights it may have to seek attorneys’ fees and expenses from you if LG prevails in the arbitration.
- Page 37 Memo...
- Page 38 38 Memo...
- Page 39 Memo...
- Page 40 LG Customer Information Center For inquiries or comments, visit www.lg.com or call: U.S.A. 1-800-243-0000 1-888-542-2623 CANADA Register your product Online! www.lg.com...
