Kit Instructions
Pressure Roller
Model 244512, Series C / Model 16W441, Series A
3600 psi (24.8 MPa, 248 bar) Maximum Fluid Inlet Pressure*
•
20 in. (50 cm) heavy-duty extension
•
45° swivel adapter
•
9 in. (23 cm) roller frame
•
1/2 in. (13 mm) nap roller cover
*Use the lowest pressure that provides an even paint supply to
the roller; typically less than 300 psi (2.1 MPa, 21 bar)
Important Safety Instructions
Read all warnings and instructions in this man-
ual. Save these instructions.
NOTICE
Never leave water in the pump, gun, or pressure roller.
Doing so could cause corrosion and damage from
freezing. For storage, flush the system with Graco
™
Pump Armor
or mineral spirits/paint thinner.
Get other manuals https://www.bkmanuals.com
To find your local Graco/Magnum
authorized service center:
• 1-888-541-9788
• Magnum.Graco.com
• Graco/Magnum Authorized
Service Centers list 302367
ti22333a
332981A
EN
