Sony VPL-HS2 Dimensional Information

VPL-HS2
RM-PJHS2 REMOTE CONTROL
FRONT
VIEW
SIDE
VIEW
LENS
BACK
VIEW
NOTE:
WHERE THERE ARE CLOSE TOLERANCES
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION
RECOMMEND THAT THE PRODUCT ITSELF
MEASUREMENTS.
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX (201) 930 7891 • b2b.sel.sony.com
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
12"
12 1/2"
8 5/8"
REMOTE
SENSOR
L R
S VIDEO VIDEO AUDIO
INVOLVED IN CABINET BUILDING
SONY WILL NOT BE RESPONSIBLE FOR
HOME THEATER
LCD PROJECTOR
12 " X 6 3/4 X 12 1/2"
8 lbs. 10 oz.
VENTILATION
VENTILATION
PJ MULTI AC IN
BE USED TO MAKE THE ACTUAL
INACCURACIES
POWER
REQUIREMENTS:
120/240V
50/60Hz
POWER
CONSUMPTION:
190w
REMOTE
SENSOR
6 3/4"
4 1/4"
1 3/4"
3 3/8"
WE
Do
Cl
Ne
