- Page 1 Vodafone Direct E-mail configuration for HTC S710 (WM 2006 Standard)
-
Page 2: Table Of Contents
........... E RROR OOKMARK NOT DEFINED OWNLOAD AND CONFIGURATION CHANGING THE TELEPHONE’S GPRS CONFIGURATION ..ERROR! BOOKMARK NOT DEFINED. VODAFONE DIRECT E-MAIL / HTC TYTN II QUICK START GUIDEERROR! BOOKMARK NOT DEFINED. RROR OOKMARK NOT DEFINED OW DO KNOW IF... -
Page 3: What You Will Need ........................................................ E Rror ! Bookmark Not Defined
You can use Vodafone Direct E-mail to link your HTC S710 to up to 5 e-mail accounts, thus You can use Vodafone Direct E-mail to link your HTC S710 to up to 5 e-mail accounts, thus allowing you to send and receive your e-mails wherever and whenever you like. -
Page 4: Downloading The Software And Activation
Downloading the software and activation There are 2 possible download methods 1 – Start the download using the activation text message 1.01 – When you receive the text message shown opposite, click on http://push.proximus.be If you get a connection error please go straight to the chapter on Changing the telephone’s GPRS configuration (Page 10) 2 –... - Page 5 2.02 – Press Menu. 2.03 – Select Address Bar. 2.04 – Enter the address push.proximus.be, then press OK. 5 / 18...
-
Page 6: Download And Configuration
3 - Download and configuration 3.01 – Choose your language, enter your telephone number and then click on Next. 3.02 – Press Download the software. 3.03 – press Yes. 3.04 – The software will then start downloading: Please wait. Depending on the type of network available, the download time may vary from a few seconds in 3G mode to 3 minutes in GPRS mode. - Page 7 3.05 – The licence agreement is displayed. Choose I accept. 3.06 – Please wait while the software is installed. 3.07 – At the end of installation press Done. 3.08 – Please wait during this activation phase. 7 / 18...
- Page 8 3.09 – Then the screen shown opposite asks you to enter your 10-digit Proximus telephone no. Type it in without spaces (e.g. 0475123456). Then choose Next. 3.10 – Please wait during this further activation phase. 3.11 –Configure the existing e-mail account which you would like to synchronise with your PDA: •...
- Page 9 3.13 - Your e-mail is configured. Press Done. 3.14 – You can now start to send and receive messages. N.B.: You will receive two e-mails on this account: • A welcome e-mail, • A second e-mail containing your Vodafone Direct E-mail password (a 6- digit number).
-
Page 10: Changing The Telephone's Gprs Configuration
Changing the telephone’s GPRS configuration You only need to do this if you have previously been unable to download the software. 1.01 – Open the Start menu from the main page. 1.02 – Press Settings. 1.03 – Press Connections. 10 / 18... - Page 11 1.04 – Press GPRS. 1.05 – Press New. 1.06 – Complete as follows: - Connection name: Mobile Internet - Connect to: Internet - Access point name: internet.proximus.be - Authentication type: None Then click Done. 1.07 - Press Done. 11 / 18...
- Page 12 1.08 – Press Menu/Advanced. 1.09 – In Internet Connection, select Mobile Internet, then press Done. 1.10 - Press Done. 1.11 - Press Done. You can now continue with downloading and installing Vodafone Direct E-mail (Page 4). 12 / 18...
- Page 13 Vodafone Direct E-mail / HTC S710 quick start guide How do I know if I am actually connected to Vodafone Direct E-mail? Open the Start menu, then press Direct E-mail. The status is displayed at the top of the Vodafone Direct E-mail window: Connected since ...:...
-
Page 14: What Are The Additional Settings
What are the additional settings? There are 3 elements which can be configured from the telephone. To access them from Vodafone Direct E-mail, open the Menu then select Settings. Connection schedule allows you to define the operating range for Vodafone Direct E-mail Message limit allows you to configure how many messages are kept in each mailbox [enter the maximum number] 14 / 18... -
Page 15: Frequently Asked Questions
Mailboxes allows you to add/delete/edit mailboxes. So you can monitor incoming e-mails in separate mailboxes. In the same way, when sending e- mails, you can choose the appropriate e-mail account. How to change your password or Personal Information from a PC Your management URL: (changing your password) http://push.proximus.be... -
Page 16: Yahoo France Yahoo Fr )
Appendix: Activating the POP protocol for Yahoo France and G-mail Appendix: Activating the POP protocol for Yahoo France and G-mail Yahoo France (@yahoo.fr) Yahoo France (@yahoo.fr) Click on Options Click Forwarding and POP Access 16 / 18... -
Page 17: Google Mail Gmail Com )
Check Web and POP access then click on Confirm Google Mail (@gmail.com) Click on Settings. 17 / 18... - Page 18 Click Forwarding and POP, Choose Enable POP for mail that arrives from now on, then click on Save Changes. 18 / 18...
