Chain Saw
Instruction Manual
MODEL :
WARNING
Read rules for safe operation and instructions carefully. ECHO provides an Instruc-
tion Manual and a Safety Manual. Both must be read and understood for proper and
safe operation.
X7503196703
CS-450
Get other manuals https://www.bkmanuals.com
X750010903
12/10
Advertisement
Table of Contents
Related Manuals for Echo X7503196703
Summary of Contents for Echo X7503196703
- Page 1 Chain Saw Instruction Manual MODEL : CS-450 WARNING Read rules for safe operation and instructions carefully. ECHO provides an Instruc- tion Manual and a Safety Manual. Both must be read and understood for proper and safe operation. X750010903 X7503196703 12/10...
-
Page 2: Rules For Safe Operation
7. Only use replacement bars and chains specified by the manufacturer or the equivalent. Copyright© 2010 By Echo, Incorporated All Rights Reserved. CS-450 Get other manuals https://www.bkmanuals.com... - Page 3 SAE Standard J335 are standard your body. on ECHO chain saws to reduce the 10. Do not operate a chain saw that is possibility of forest fires. damaged, improperly adjusted, or not Do not operate the chain saw with a completely and securely assembled.
-
Page 4: Table Of Contents
CONTENTS RULES FOR SAFE OPERATION ....................... SYMBOLS AND SIGNS ........................EMISSION DATA ..........................PACKING LIST ............................ NOMENCLATURE OF PARTS ......................OPERATOR SAFETY ......................... CORRECT USE OF CHAIN BRAKE ....................10 PREPARATION FOR USE ........................11 FUEL AND LUBRICANT ........................13 OPERATION ............................ - Page 5 CLATURE OF PARTS” section will help you locate them. Make sure the decals are legible and that you understand and follow the instructions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. CS-450 Get other manuals https://www.bkmanuals.com...
-
Page 6: Emission Data
Maintenance Section of this manual. PACKING LIST The ECHO product you purchased has been fac- After opening the carton, check for damage. Im- tory pre-assembled for your convenience. Due to... -
Page 7: Nomenclature Of Parts
WARNING!! Read and follow all safety precaution in the instruction manual. Failure to follow instructions could result in serious personal injury. * If a decal cannot be read, a new one can be ordered from your ECHO dealer. CS-450 Get other manuals https://www.bkmanuals.com... -
Page 8: Operator Safety
NOMENCLATURE OF PARTS Spiked bumper - Device, fitted in front of the Instruction manual - Included with unit. Read guide bar mounting point, acting as a pivot when before operation and keep for future reference to learn proper, safe operating techniques. in contact with a tree or log. - Page 9 To reduce the risk of serious or fatal injury, persons with pacemakers should consult with their physician and the pacemaker manufacturer before operating this machine. In the absence of such information, ECHO does not recommend the use of ECHO products by anyone who has a pacemaker. VIBRATION AND COLD •...
-
Page 10: Correct Use Of Chain Brake
You should inquire through local government of- fices, your employer or your local dealer to ensure that your chain saw conforms to the required safety standard. ECHO chain brakes have been designed and tested to comply with international safety standards as follows. Rotational kickback : ANSI Standard B175.1 - 2000... -
Page 11: Preparation For Use
PREPARATION FOR USE WARNING Saw chain is sharp! Always wear gloves when handling assembly, otherwise serious WARNING personal injury may result. Using improper replacement components or remov- ing safety devices may result in serious or fatal NOTE injury. The machine may be delivered with guide bar, tip guard, and saw chain separated. - Page 12 Guide bar studs 6. Mount guide bar on studs and slide toward Clutch clutch to make saw chain installation easier. In- stall chain with cutters on top of guide bar facing Guide bar forward. adjuster 7. Unlock the chain brake, and install the clutch hole Hole cover over the guide bar studs.
-
Page 13: Fuel And Lubricant
Power Blend X Universal 2-Stroke Oil meets these standards. Engine problems due to inadequate lubrication caused by failure to use an ISO-L-EGD (ISO/CD 13738) and J.A.S.O. FD certified oil, such as Echo premium Power Blend X will void the two-stroke engine warranty. - Page 14 • Do not use used or reclaimed oil to avoid various oiler problems. • Use ECHO bar and chain oil. • When ECHO bar and chain oil is not available: Use motor oil, etc. • Use bar and chain oil of the following grades: SAE No.
-
Page 15: Operation
OPERATION WARNING Moving parts can amputate fingers or cause severe injuries. Keep hands, clothing and loose objects away from all openings. Always stop engine, disconnect spark plug, and make sure all moving parts have come to a com- plete stop before removing obstructions, clearing debris, or servicing unit. WARNING Engine exhaust IS HOT, and contains Carbon Monoxide (CO), a poison gas. - Page 16 WHEN THE ENGINE IS COLD CAUTION Make sure the bar and chain are free from any obstruction when starting the chain saw. Chain brake • Move chain brake lever fully forward to lock chain brake before starting. • Fill the fuel tank with fuel mixture. Do not over fill. •...
- Page 17 NOTE If engine does not stop, pull choke control knob Throttle trigger out fully to stop engine. Return the unit to your authorized ECHO dealer to check and repair stop switch before starting the engine again. CHECKING CHAIN TENSION • Chain tension should be checked frequently during work and corrected as necessary.
-
Page 18: Cutting Instruction
Pushing the saw too hard will slow the engine and cut- ting will actually be more difficult. NOTE Some material may adversely affect the housings of your ECHO chain saw. (Example: Palm Tree Acid, fertilizer, etc.) To avoid housing deterioration, carefully remove all packed Kickback saw dust around clutch and guide bar area and wash with water. - Page 19 FELLING THE TREE 3 m (10 feet) WARNING Retreat Direction of fall A falling tree can seriously damage anything it may 45° hit - a car, a house, a fence, a power line, or another tree. There are ways to make a tree fall where you 45°...
- Page 20 LIMBING Limbing a fallen tree is much the same as bucking. Never stand on the tree that you are limbing. When limbing, caution is the word. Be careful of the tip touching other limbs. Always use both hands. Don’t cut with the saw overhead or aligned vertically with your body.
- Page 21 When the brake lever trips, the chain should stop. Immediately release the throttle trigger. WARNING If the chain does not stop immediately, return the saw to your authorized ECHO dealer for repair. Chain brake function When the lever is pushed forward, chain brake instantly stops the chain.
- Page 22 AUTOMATIC CHAIN BRAKE End of the guide bar may be placed at the Kickback produced from the tip of the guide bar will height of about 50 cm (20 in.). trip the automatic chain brake. To make sure that the automatic chain brake operates properly, follow these steps: 1.
-
Page 23: Chain And Guide Bar Combination
Chain and guide bar gauge size must be identical. Use Bar/Chain combinations shown in table above. IMPORTANT If your kick guard is damaged or lost, contact your Echo dealer for a replacement. For the name of the Echo dealer nearest you, Call: 1-800-432-ECHO (3246) or on the web at www.echo-usa.com. -
Page 24: Maintenance And Care
Wear gloves to protect hands from sharp edges and hot surfaces. Your ECHO chain saw is designed to provide many hours of trouble free service. Regular scheduled maintenance will help your chain saw achieve that goal. If you are unsure or are not equipped with the necessary tools, you may want to take your unit to an ECHO Service Dealer for maintenance. -
Page 25: Carburetor Adjustment
Accelerate engine to full throttle to check for authorized ECHO service dealer. smooth transition from idle to high speed. If engine hesitates turn “L” needle CCW 1/8 turn IMPORTANT and repeat acceleration. - Page 26 AIR FILTER Cleaner cover knob Air cleaner cover • Check before every use. Spark plug • Loosen cleaner cover knob and remove air cleaner cover and filter. • Brush off dust lightly, or clean with compressed Air filter cover air, or replace the air filter. •...
- Page 27 GUIDE BAR • Clean before using. - Clean the groove of the guide bar with a small Groove screwdriver. - Clean oil holes with a wire. Oil hole Clutch • Reverse guide bar periodically. (Sprocket) • Check sprocket and the clutch and clean the bar mount area before installation of the bar.
- Page 28 ExhAuST PORT ClEANINg Level 2 Tools required: T-Wrench, 4 & 5 mm Hex Wrench, Wood or plastic scraper Parts Required: As needed: Muffler gasket 1. Remove air cleaner cover and remove spark plug lead. 2. Remove guide bar and saw chain. See "Guide Bar and Saw Chain Installation/Removal."...
-
Page 29: Setting The Saw Chain
SETTING SAW CHAIN 20BPX, 95VP : 30° Proper filing tools for setting saw chain are avail- able from your Echo dealer. Keep this angle • For setting saw chain, round file (33SL : 4.5 mm dia. or 20BPX, 95VP : 3/16 in.) and flat file are used. - Page 30 One fifth of file diameter remains above cutter edge • Place the depth gauge tool firmly on guide bar so that depth gauge protrudes. Depth gauge tool Then file top of depth gauge with the flat file until flat with top of the depth gauge tool. Remove until flat with tool - Be sure to round off the front edge of the...
-
Page 31: Troubleshooting
TROUBLESHOOTING r o t r o t i a r i l l r o t r e l i l y i l y r o t r e l f f u r e l h t i r u t r / n r i a... -
Page 32: Storage After Use
Recoil starter Power transmission Automatic centrifugal clutch Fuel Mixture ratio 50 : 1 ratio with ECHO Power Blend X™, ISO-L- EGD (ISO/CD 13738), JASO M345-FD two- stroke, air-cooled engine oil. Gasoline Use 89 octane unleaded. Do not use fuel containing methyl alcohol, more than 10 % ethyl alcohol or 15 % MTBE. -
Page 33: Warranty Statements
The owner shall demonstrate reasonable care and use, and follow preventative maintenance, storage, fuel and oil usage as prescribed in the operator’s manual. Should a product difficulty occur, you must, at your expense, deliver or ship your ECHO unit to an authorized ECHO servicing dealer for warranty repairs (within the applicable warranty period), and arrange for pick-up or return of your unit after the repairs have been made. - Page 34 89 octane or higher. Gasohol which contains a maximum 10% ethanol (grain alcohol) or 15% MTBE (methyl/tertiary/butyl/ether) is also approved. The prescribed mixing ratio of gasoline to oil is listed on the ECHO oil label and covered in your operator’s manual.
- Page 35 HOW WILL A COVERED PART BE CORRECTED? If there is a defect in a part covered by this warranty, any ECHO Inc. Authorized Service Dealer will correct the defect. You will not have to pay anything to have the part adjusted, repaired or replaced. This includes any labor and diagnosis for warranted repairs performed by the dealer. In addition, engine parts not expressly covered under this warranty but whose failure is a result of a failure of a covered part will be warranted.
-
Page 36: Servicing Information
ECHO Inc., 400 Oakwood Road, Lake Zurich, IL 60047 (800-673-1558). Always check the ECHO Web Site for updated information. Safety Videos are available from your Echo dealer. A $5.00 shipping charge will be required for each video. EChO, INCORPORATED...
