Sierra Grill Chimenea Medium
User Instructions - Please keep for future reference
Tools required (not included)
Tools list
IMPORTANT – Carefully remove any packaging before use, but retain the safety instructions.
These instructions form part of the product.
Please take note of all of the safety warnings listed in these instructions.
Please read these instructions in their entirety and retain them for future reference.
These instructions should be stored with the product.
This product is for domestic use ONLY and should not be used commercially or for contract purposes.
Produced in China for La Hacienda Ltd
Hangar 27, Site C, Aston Down Airfield, Nr Stroud, Glos, GL6 8HR, UK
www.lahacienda.co.uk
56016MZ
V1.0
Advertisement
Related Manuals for La Hacienda Sierra 56016MZ
Summary of Contents for La Hacienda Sierra 56016MZ
- Page 1 These instructions should be stored with the product. This product is for domestic use ONLY and should not be used commercially or for contract purposes. Produced in China for La Hacienda Ltd Hangar 27, Site C, Aston Down Airfield, Nr Stroud, Glos, GL6 8HR, UK...
- Page 2 (do not drag) the product across the floor. • The unit may be left outside all year if a La Hacienda Chimenea Cover is used to help protect it from bad weather. • As this model is made from cast iron and steel, the surface will age and develop surface rust as soon as it is placed outside and from first use.
- Page 3 Parts list 1 (1x) 5 (1x) 15 (3x) 10 (1x) 2 (1x) 11 (1x) 6 (2x) 3 (1x) A (6x) Washer, split washer & nut set 7 (1x) 12 (1x) B (6x) Bolt, washer, split washer & nut set 13 (1x) 4 (1x) 8 (2x) C (3x)
- Page 4 Assembly Instructions IMPORTANT - Remove any packaging before use, but retain the safety instructions and store them with this product. ASSEMBLY STEP 1 - Attach the 3 legs (15) to bottom bowl (11) by pushing pre-attached bolts on legs through the bowl and adding a washer, lock washer and nut set (A) to each each bolt.
