3-064-678-12 (1)
Digital
Camcorder

Operating Instructions

Before operating the unit, please read this manual thoroughly,
and retain it for future reference.
Owner's Record
The model and serial numbers are located on the bottom. Record the
serial number in the space provided below. Refer to these numbers
whenever you call upon your Sony dealer regarding this product.
Model No. DSR-250
Serial No.
DSR-250
©2000 Sony Corporation

Advertisement

Table of Contents

Troubleshooting

loading

Related Manuals for Sony DSR-250

Summary of Contents for Sony DSR-250

  • Page 1: Operating Instructions

    Owner’s Record The model and serial numbers are located on the bottom. Record the serial number in the space provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product. Model No. DSR-250 Serial No.
  • Page 2 Congratulations on your purchase of this Sony Digital camcorder. With your Digital camcorder, you can capture life’s precious moments with superior picture and sound quality. Your Digital camcorder is loaded with advanced features, but at the same time it is very easy to use.

  • Page 3: Table Of Contents

    Table of contents Getting started Using this manual ... 4 Checking supplied accessories ... 6 Step 1 Installing the microphone ... 7 Step 2 Preparing the power supply ... 8 Step 3 Inserting a cassette ... 13 Recording – Basics Recording a picture ...

  • Page 4: Getting Started

    — Getting started — Using this manual As you read through this manual, buttons and settings on your camcorder are shown in capital letters. e.g. Set the POWER switch to ON. When you carry out an operation, you can hear a beep or a melody sound to indicate that the operation is being carried out.
  • Page 5 Using this manual Note on TV color systems TV color systems differ from country to country. To view your recordings on a TV, you need an NTSC system-based TV. Copyright precautions Television programs, films, video tapes, and other materials may be copyrighted. Unauthorized recording of such materials may be contrary to the provision of the copyright laws.

  • Page 6: Checking Supplied Accessories

    Checking supplied accessories Make sure that the following accessories are supplied with your camcorder. 1 Wireless Remote Commander (1) (p. 188) 2 Size AA (R6) battery for Remote Commander (2) (p. 189) 3 Memory Stick Reader/Writer (1), USB cable (1), Driver software (CD ROM) 4 “Memory Stick”...

  • Page 7: Step 1 Installing The Microphone

    Step 1 Installing the microphone Install the supplied microphone. Be sure to connect the microphone plug to the MIC IN +48V connector. (1) Attach the wind screen to the microphone. (2) Loosen the microphone holder screw and open the cover. (3) Place the microphone into the holder with the model name (ECM-NV1) facing upward, close the cover, and tighten the screw.

  • Page 8: Step 2 Preparing The Power Supply

    Step 2 Preparing the power supply The following power supplies can be used with the camcorder. •BP-L40 (A)/L60A/L90A lithium-ion battery pack •NP-1B Ni-Cd Battery Pack (The DC-L1Battery Adaptor is required.) •BP-90A Ni-Cd Battery Pack (The DC-L90 Battery Adaptor is required.) •AC power (The AC-550, AC-DN1/DN2A, or CMA-8A AC Adaptor is required.) Alternatively, you can make combined use of internal and external batteries, by mounting one of the above batteries as an internal battery and connecting, such as a BP-...

  • Page 9: Step 2 Preparing The Power Supply

    Step 2 Preparing the power supply Installing the battery pack (1) Attach the battery pack against the rear of the camcorder, aligning the side line of the battery pack with the line on the camcorder. (2) Slide the battery pack down until its “bLOCK” arrow points at the matching line on the camcorder.
  • Page 10 Step 2 Preparing the power supply Setting up the type of the battery pack Set up the type of the battery pack installed to the camcorder, using the menu. If you do not set the type, the battery remaining indicator will not indicate the correct capacity. (1) Push the CUSTOM PRESET/MENU switch in the MENU direction and release it to display the menu.

  • Page 11: Using An Ac Adaptor

    Step 2 Preparing the power supply Using an AC adaptor When using an AC-550 AC Adaptor Connect the camcorder to the AC power supply as shown in the following figure, and turn the POWER switch of the AC-550 ON. DC IN 12V When using an AC-DN1 AC Adaptor Mount the AC-DN1 on the camcorder in the same way as a battery pack, then connect to the AC power source.

  • Page 12: Avoiding Breaks In Operation Due To Dead Batteries

    Step 2 Preparing the power supply Avoiding breaks in operation due to dead batteries If you use both an internal battery pack and an external battery connected to the DC IN 12V connector at the same time, you can avoid breaks in operation due to the dead batteries.

  • Page 13: Step 3 Inserting A Cassette

    Step 3 Inserting a cassette The camcorder can use standard-size and mini-size DVCAM/DV cassettes. Before inserting a cassette, make sure that no cassette is in the cassette compartment. Inserting a cassette forcibly may damage internal parts of the camcorder. (1) Install the power source (p. 8). (2) While sliding OPEN in the direction of the arrow, open the cassette lid.

  • Page 14: Step 3 Inserting A Cassette

    Step 3 Inserting a cassette Note Internal parts of the camcorder may become bent or otherwise damaged if you attempt to insert a mini-size cassette in the wrong direction (such as with the cassette turned backside front so the reel holes face the cassette holder window or with the cassette turned sideways so that a short side enters first).

  • Page 15: Recording - Basics

    — Recording – Basics — Recording a picture Your camcorder automatically focuses for you. (1) Remove the hood cap and pull the hood cap string to fix it. (2) Install the power source and insert a cassette. See “Step 2” and “Step 3” for more information (p.
  • Page 16 Recording a picture To turn off the TALLY lamps When you turn off the TALLY lamp located on the viewfinder, set the TALLY switch located on the front of the viewfinder to OFF, and when you turn off the TALLY lamp located on the rear, set the TALLY switch located below the TALLY lamp to OFF.

  • Page 17: Using The Nd Filter

    Recording a picture Using the ND filter Using the ND filter (the ND filter 1 setting corresponds to 1/4 of the quantity of light and the ND filter 2 setting corresponds to 1/32 of the quantity of light), you can record a picture clearly by adjusting light amounts, even if you shoot under too bright conditions.
  • Page 18 Recording a picture Usable cassettes The camcorder can use standard-size and mini-size DVCAM/DV cassettes. (To ensure high-quality playback, editing, and storage of recorded contents, we recommend using highly reliable DVCAM cassettes). The following table lists the cassettes that can be used in the camcorder. Model name PDV-64ME/64MEM/64N/94ME/124ME/124MEM /124N/184ME/184MEM/184N...

  • Page 19: Adjusting The Viewfinder Position

    Left eye adaptor By fitting a left eye adaptor, you can use the camcorder with your left eye to the viewfinder. For details, contact your Sony dealer. Adjusting the viewfinder screen The following adjustments are provided to improve the visibility of the viewfinder screen.
  • Page 20 1) Diopter: A unit to indicate the degree of convergence or divergence of a bundle of rays. Eyepiece focusing knob To modify the adjustment range Using an optional part allows you to modify the adjustment range to –2 to +1 diopters or –0.5 to +3 diopters. For details, consult your Sony dealer.
  • Page 21 Recording a picture Contrast and brightness adjustment Carry out these adjustments with the color bars displayed. (1) Push the CUSTOM PRESET/MENU switch in the MENU direction and release it to display the menu in standby or recording mode. (2) Turn the SEL/PUSH EXEC dial to select (3) Turn the SEL/PUSH EXEC dial to select COLOR BAR, then press the dial.

  • Page 22: Using The Lcd Screen

    Recording a picture Using the LCD screen While sliding OPEN in the direction of the battery pack, then open the LCD panel. The picture being shot is displayed on the LCD screen. To turn off the LCD screen, set the LCD switch to OFF or close the LCD panel with the LCD screen facing toward the camcorder body.

  • Page 23: Adjusting The Brightness Of The Lcd Screen

    Recording a picture Adjusting the brightness of the LCD screen To adjust the brightness of the LCD screen, press LCD BRIGHT + or –. – LCD BRIGHT To darken Even if you do the LCD screen adjustment using the LCD BRIGHT +/– buttons The recorded picture will not be affected.

  • Page 24: Using The Zoom Feature

    Recording a picture After recording (1) Close the LCD panel. (2) Eject the cassette. (3) Set the POWER switch to OFF. (4) Remove the battery pack. Using the zoom feature To zoom with the zoom lever Press the power zoom lever a little for a slower zoom. Press it deeper for a faster zoom. Using the zoom function sparingly results in better-looking recordings.
  • Page 25 Recording a picture To zoom with the zoom ring Using the zoom ring, you can control the zoom by your desired speed and you can make fine adjustments. During recording, turn the zoom ring to the desired speed. For wide-angle For telephoto Note If you turn the zoom ring quickly, the zoom may not respond to the zoom ring...

  • Page 26: Indicators Displayed During Recording

    Recording a picture Indicators displayed during recording The indicators are not recorded on the tapes. [a] [b] [c] JUL 4 2001 [a] Remaining battery capacity indicator This appears after you turn on the power and wait for a while. When uREMAIN is set to LI-ION in the menu settings, “Li”...

  • Page 27: Shooting Backlit Subjects (Back Light)

    Recording a picture On remaining battery capacity indicator The camcorder cannot detect the type of the battery pack automatically. According to your battery pack, set up the uREMAIN item properly (p. 10). A wrong setup does not indicate the correct battery capacity. Shooting backlit subjects (BACK LIGHT) When you shoot a subject with the light source behind the subject or a subject with a light background, use the backlight function.

  • Page 28: Spot Light

    Recording a picture Spot light This function prevents people’s faces, for example, from appearing excessively white when shooting subjects lit by strong light, such as in the theater. Press SPOT LIGHT in standby, recording, or memory mode. indicator appears on the LCD screen or in the viewfinder. To cancel, press SPOT LIGHT again.

  • Page 29: Checking The Recording - End Search / Editsearch / Rec Review

    Checking the recording – END SEARCH / EDITSEARCH / Rec Review You can use these buttons to check the last recorded picture or shoot so that the transition between the last recorded scene and the next scene you record is smooth. Searching the end point of the recording —...

  • Page 30: Playback - Basics

    Playing back a tape You can monitor the playback picture on the LCD screen or in the viewfinder. You can also control playback using the Remote Commander supplied with your camcorder. (1) Install the power source. (2) Set the POWER switch to ON and insert the recorded tape. (3) Set the MEMORY/CAMERA/VTR selector to VTR.

  • Page 31: Playing Back A Tape

    Playing back a tape When monitoring on the LCD screen You can turn the LCD panel over and move it back to the camcorder body with the LCD screen facing out. To select the audio output channel via the speaker or PHONES jack Select the channels using the AUDIO MONITOR selector.

  • Page 32: Using The Data Code Function

    Playing back a tape Using the data code function Your camcorder automatically records not only images on the tape but also the recording data (date/time or various settings when recorded) (Data code). Press DATA CODE on the camcorder or on the Remote Commander supplied with your camcorder in playback mode.

  • Page 33: Various Playback Modes

    Playing back a tape If the aperture adjustment is set to minimum “CLOSE” is displayed at the location of the aperture value. Various playback modes To operate video control buttons, set the MEMORY/CAMERA/VTR selector to VTR. To view a still picture (playback pause) Press X during playback.
  • Page 34 Playing back a tape When you play back a tape in reverse Horizontal noise may appear at the center, or the top and bottom of the screen. This is not a malfunction. Note on DV-formatted tapes You can play back DV-formatted tapes on this camcorder if the tape is recorded in SP mode.

  • Page 35: Viewing The Recording On A Monitor

    Viewing the recording on a monitor Connect your camcorder to your monitor or VCR with the A/V connecting cable to watch the playback picture on the monitor screen. You can operate the video control buttons in the same way as when you monitor playback pictures on the LCD screen. Refer to the operating instructions of your monitor or VCR.

  • Page 36: Advanced Recording Operations

    Shooting with manual adjustment Under normal conditions, this unit automatically makes various adjustments as it shoots. However, you can adjust the following functions manually to suit your preference. Functions you can adjust by setting the AUTO MODE switch to OFF Iris, gain, shutter speed, and white balance Functions you can adjust in menu settings Deactivating the SteadyShot...
  • Page 37 Shooting with manual adjustment Adjusting the iris Adjust the iris manually depending on the depth of field. (1) Set the AUTO MODE switch to OFF while the camcorder is in standby, recording, or memory mode. (2) Set the IRIS switch to MAN. The iris indicator appears on the LCD screen or in the viewfinder.

  • Page 38: Adjusting The Gain

    Shooting with manual adjustment Adjusting the gain (1) Set the AUTO MODE switch to OFF while the camcorder is in standby, recording, or memory mode. (2) Set the AGC switch to OFF. The gain indicator appears on the LCD screen or in the viewfinder.
  • Page 39 Shooting with manual adjustment Setting the gain values for the positions of the GAIN selector (1) Push the CUSTOM PRESET/MENU switch in the MENU direction and release it to display the menu in standby, recording, or memory mode. (2) Turn the SEL/PUSH EXEC dial to select (3) Turn the SEL/PUSH EXEC dial to select GAIN LEVEL, then press the dial.

  • Page 40: Adjusting The Shutter Speed

    Shooting with manual adjustment Adjusting the shutter speed (1) Set the AUTO MODE switch to OFF while the camcorder is in standby, recording, or memory mode. (2) Set the SHUTTER switch to ON. The shutter speed set by the SHTR SPEED item in the menu settings will be indicated on the LCD screen or in the viewfinder.
  • Page 41 Shooting with manual adjustment Adjusting the shutter speed value (1) Push the CUSTOM PRESET/MENU switch in the MENU direction and release it to display the menu in standby, recording, or memory mode. (2) Turn the SEL/PUSH EXEC dial to select (3) Turn the SEL/PUSH EXEC dial to select SHTR SPEED, then press the dial.

  • Page 42: Shooting With The Zebra Pattern

    Shooting with manual adjustment Shooting with the zebra pattern You can set the camcorder to display a zebra pattern (diagonal stripes) in the portion of the picture on the LCD screen or in the viewfinder with a subject whose brightness exceeds a certain level.

  • Page 43: Releasing The Steadyshot Function

    Shooting with manual adjustment Releasing the SteadyShot function When the SteadyShot function is working, the camcorder compensates for camera- shake. You can release the SteadyShot function when you do not need to use it. The indicator appears on the LCD screen or in the viewfinder. Do not use the SteadyShot function when shooting a stationary object with a tripod.

  • Page 44: Adjusting The Ae Shift

    Shooting with manual adjustment Adjusting the AE shift You can adjust the AE shift in accordance with shooting conditions and a subject. (1) Push the AE SHIFT switch in the direction of the arrow and release it in standby, recording, or memory mode. The AE shift indicator appears on the LCD screen or in the viewfinder.

  • Page 45: Focusing Manually

    Focusing manually You can gain better results by manually adjusting the focus in the following cases: •The autofocus mode is not effective when shooting – subjects through glass coated with water droplets – horizontal stripes – subjects with little contrast with backgrounds such as walls and sky •When you want to change the focus from a subject in the foreground to a subject in the background •Shooting a stationary subject when using a tripod...

  • Page 46: Focusing Manually

    Focusing manually To obtain the correct focus First, focus on a subject manually with the zoom set toward the “T” (telephoto) side, then adjust the zoom by pressing the “W” side of the lever gradually. When you shoot close to the subject Focus at the end of the “W”...

  • Page 47: Adjusting The White Balance

    Adjusting the white balance White balance adjustment makes white subjects look white and allows more natural color balance for camera recording. Normally, white balance is automatically adjusted. You can obtain better results by adjusting the white balance manually when lighting conditions change quickly or when recording outdoors: e.g., neon signs, fireworks.
  • Page 48 Adjusting the white balance To recall a white balance value from memory Before beginning shooting, set the WHITE BAL switch to the A or B position. This automatically sets the camcorder to the white balance adjustment saved in the corresponding memory. Shooting when lighting conditions have changed •When lighting conditions have changed, readjust the white balance while the camcorder is in standby mode.
  • Page 49 Adjusting the white balance (1) Set the AUTO MODE switch to OFF while the camcorder is in standby, recording, or memory mode. (2) Set the ATW switch to OFF. (3) Set the WHITE BAL switch to PRESET. (4) Set the position as follows with the WHT PRESET switch. Position Shooting conditions 5800K...

  • Page 50: Presetting The Adjustment For Picture Quality - Custom Preset

    Presetting the adjustment for picture quality – Custom preset You can preset the camcorder to record the picture with the desired picture quality. When you preset, we recommend that you check the picture quality by displaying the picture onto the monitor screen, which is connected to the camcorder. (1) Turn the CUSTOM PRESET/MENU switch in the CUSTOM PRESET direction and release it to display the CUSTOM PRESET menu in standby or memory mode.
  • Page 51 Presetting the adjustment for picture quality – Custom preset Items to be adjusted Meaning Item Color intensity COLOR LVL Sharpness SHARPNESS WB SHIFT White balance Auto Gain-limit AGC LIMIT RESET Sets items above to the default settings. To cancel using the custom preset Select OFF in step 4, then press the SEL/PUSH EXEC dial.

  • Page 52: Using The Guide Frame

    Using the guide frame You can easily make the picture be on a horizontal or vertical line using the guide frame. The guide frame is not recorded. (1) Push the CUSTOM PRESET/MENU switch in the MENU direction and release it to display the menu in standby, recording, or memory mode. (2) Turn the SEL/PUSH EXEC dial to select (3) Turn the SEL/PUSH EXEC dial to select GUIDEFRAME, then press the dial.

  • Page 53: Marking An Index

    Marking an Index If you mark an index at the scene you want to search for, you can easily search for the scene later (p. 77). In recording mode [a]: Press INDEX MARK. The “INDEX MARK” indicator appears on the LCD screen or in the viewfinder for seven seconds and after the indicator disappears, the index marking is complete.

  • Page 54: Adjusting The Recording Level Manually - Sound Recording Level

    Adjusting the recording level manually – Sound recording level You can adjust the recording sound level. We recommend that you check the recording level before recording. You can adjust the channel 1 and channel 2 separately. (1) Select the audio input using the AUDIO INPUT (CH-1/CH-2) switches. To select the audio input for channel 1, use the AUDIO INPUT (CH-1) switch, and for channel 2, use the AUDIO INPUT (CH-2) switch.

  • Page 55: Sound Recording Level

    Adjusting the recording level manually– Sound recording level Notes on the recording level of the channel 1 • You can adjust the level from both the MIC IN +48V and AUDIO IN CH1 connectors. •You can also adjust the level using the AUDIO LEVEL knob located on the front, however, when the AUDIO LEVEL knob located on the side panel is near minimum level, you cannot turn up the volume using the AUDIO LEVEL knob located on the front.

  • Page 56: Connecting An Optional External Microphone

    Connecting an optional external microphone You can also use an external 48-V microphone by connecting it to the MIC IN +48V connector. (The optional CAC-12 Microphone Holder is required.) Installing the optional CAC-12 Microphone Holder Remove the two retaining screws (M3 12) for the optional microphone holder, then use these screws to attach the CAC-12 Microphone Holder.

  • Page 57: Connecting An Optional External Microphone

    Connecting an optional external microphone To fit optional microphones (operable with a 48 V supply) other than the ECM-670 Use the same fitting procedure as for the ECM-670, but note the following differences with respect to the microphone adaptor. ECM-672: no microphone adaptor required. Slender microphones (19 mm (3/4 inch) diameter): use the microphone adaptor supplied with the CAC-12.

  • Page 58: Using An External Audio System Or Microphone

    Using an external audio system or microphone Connect an audio mixer or other external audio system component to the AUDIO IN CH1/CH2 connectors. (1) Connect an audio mixer or other external audio system component to the AUDIO IN CH1/CH2 connector. (2) Set the AUDIO INPUT switch that corresponds to the channel that the cable is connected to REAR.

  • Page 59: Backing Up Recordings To Another Tape

    Backing up recordings to another tape You can easily make backup copies of recordings to the VCR connected to your camcorder with the DV connecting cable (i.LINK cable). Setting EXT RECCTL in the menu settings to ON synchronizes the recording start/pause operation of the external VCR with the START/STOP button on your camcorder.

  • Page 60: Using A Video Light

    Using a video light You can use the Anton Bauer Ultralight 2 or equivalent. Use a video light powered by 12 V with maximum power consumption of 30 W. •If you connect the video light to the LIGHT connector on the camcorder and set the LIGHT switch to AUTO, you can turn the light on and off automatically as you start and stop the recording.

  • Page 61: Superimposing The Date And Time On A Picture

    Superimposing the date and time on a picture You can superimpose the date/time indication directly on the picture, besides the date/ time display as data code. (1) Push the CUSTOM PRESET/MENU switch in the MENU direction and release it to display the menu in standby mode. (2) Turn the SEL/PUSH EXEC dial to select (3) Turn the SEL/PUSH EXEC dial to select DATE REC, then press the dial.

  • Page 62: Recording A Still Image On A Tape - Tape Photo Recording

    Recording a still image on a tape – Tape Photo recording You can record still images on tapes with all the pixels in the progressive mode. See page 64 for details. This mode is useful when you print images using a video printer (not supplied).

  • Page 63: Recording A Still Image On A Tape Tape Photo Recording

    Recording a still image on a tape – Tape Photo recording To do tape photo recording using the Remote Commander Press PHOTO on the Remote Commander. Your camcorder immediately records an image on the LCD screen or in the viewfinder. When you do tape photo recording during normal CAMERA recording You cannot check an image on the LCD screen or in the viewfinder by pressing PHOTO lightly.

  • Page 64: Shooting With All The Pixels - Prog. Scan

    Shooting with all the pixels – PROG. SCAN When you handle the digital images on your PC, set PROG. SCAN to ON before shooting. You can record the images on a tape with higher resolution. Since the image taken in progressive mode would be stabilized even in pause mode, it is especially useful when you analyze high-speed actions such as sports scenes.
  • Page 65 Shooting with all the pixels – PROG. SCAN On digital zooming You cannot use digital zooming in this mode. When the auto logo insert function is activated You cannot use the progressive mode. Refer to the extra operating instructions, “Auto Logo Insert for Copyright Protection.”...

  • Page 66: Using The Wide Mode

    Using the wide mode You can record a 16:9 wide picture to watch on a 16:9 wide-screen monitor (16:9WIDE). Black bands appear on the LCD screen or in the viewfinder during recording in 16:9WIDE mode [a]. The picture during playback on a normal monitor [b] or on a wide- screen monitor [c] is compressed in the widthwise direction.

  • Page 67: Using The Fader Function

    Using the fader function You can fade the picture in or out to give your recording a professional appearance. STBY FADER OVERLAP* WIPE* DOT* (Random) * Fade in only MONOTONE When fading in, the picture gradually changes from black-and-white to color. When fading out the picture gradually changes from color to black-and-white.

  • Page 68: Using The Fader Function

    Using the fader function (1) When fading in [a] In standby mode, press FADER until the desired fader indicator flashes. When fading out [b] In recording mode, press FADER until the desired fader indicator flashes. The indicator changes as follows: FADER t MONOTONE t OVERLAP t WIPE t DOT t no indicator The last selected fader mode is indicated first.

  • Page 69: Using Special Effects - Digital Effect

    Using special effects – Digital effect You can add special effects to recorded pictures using the various digital functions. The sound is recorded normally. STILL You can record a still image so that it is superimposed on a moving picture. FLASH (FLASH MOTION) You can record still images successively at constant intervals.
  • Page 70 Using special effects – Digital effect (1) In standby or recording mode, press DIGITAL EFFECT. The digital effect indicator appears. (2) Turn the SEL/PUSH EXEC dial to select the desired digital effect mode. The digital effect indicator changes as follows: STILL y FLASH y LUMI.

  • Page 71: Superimposing A Still Image In A "Memory Stick" On A Moving Picture - Memory Mix

    Superimposing a still image in a “Memory Stick” on a moving picture – MEMORY MIX You can superimpose a still image you have recorded on a “Memory Stick” on the top of the moving picture you are recording. M. CHROM (Memory chromakey) You can swap a blue area of a still image such as an illustration or a frame with a moving picture.

  • Page 72: Stick" On A Moving Picture Memory Mix

    Superimposing a still image in a “Memory Stick” on a moving picture – MEMORY MIX Before operation Insert a recorded “Memory Stick” and a tape to be recorded into your camcorder. (1) Set the MEMORY/CAMERA/VTR selector to CAMERA. (2) Press MEMORY MIX in standby mode. The last recorded or last composed image appears on the lower part of the screen as a thumbnail image.
  • Page 73 Superimposing a still image in a “Memory Stick” on a moving picture – MEMORY MIX Items to be adjusted M. CHROM M. LUMI C. CHROM M. OVERLAP As the bar is shorter, the effect is enhanced. To change the still image to be superimposed Do either of the following: –...

  • Page 74: Interval Recording

    Interval recording You can make a time-lapse recording by setting the camcorder to automatically record and standby sequentially. You can achieve an excellent recording for flowering, emergence, etc., with this function. [a] Recording time [b]Waiting time (1) Push the CUSTOM PRESET/MENU switch in the MENU direction and release it to display the menu in standby mode.
  • Page 75 Interval recording (6) Turn the SEL/PUSH EXEC dial to select ON, then press the dial. (7) Push the CUSTOM PRESET/MENU switch in the MENU direction and release it to erase the menu display. The interval recording indicator flashes. (8) Press START/STOP to start interval recording. The interval recording indicator lights up.

  • Page 76: Frame By Frame Recording - Cut Recording

    Frame by frame recording – Cut recording You can make a recording with a stop-motion animated effect using cut recording. To create this effect, alternately move the subject a little and make a cut recording. We recommend that you use a tripod, and operate the camcorder using the Remote Commander after step 6.

  • Page 77: Advanced Playback Operations

    — Advanced Playback Operations — Searching for a recording by index – Index search You can automatically search for the point where an index is marked and start playback from that point (Index search). Use a tape with cassette memory for convenience. Use the Remote Commander for this operation.
  • Page 78 Searching for a recording by index – Index search If a tape has a blank portion between recorded portions The index search function may not work correctly. If you mark an index onto an external input signal “LINE” appears in the CH column. The index of the recording start point when recorded from external audio equipment The index mark is not recorded in cassette memory when recorded from external audio...

  • Page 79: Searching The Boundaries Of Recorded Tape By Title - Title Search

    Searching the boundaries of recorded tape by title – Title search If you use a tape with cassette memory, you can search for the boundaries of recorded tape by title (Title search) (p. 158). Use the Remote Commander for this operation. (1) Set the MEMORY/CAMERA/VTR selector to VTR.

  • Page 80: Searching A Recording By Date - Date Search

    Searching a recording by date – Date search You can automatically search for the point where the recording date changes and start playback from that point (Date search). Use a tape with cassette memory for convenience. Use the Remote Commander for this operation. Use this function to check where recording dates change or to edit the tape at each recording date.
  • Page 81 Searching a recording by date – Date search If a tape has a blank portion between recorded portions The date search function may not work correctly. Searching for the date without using cassette memory (1) Set the MEMORY/CAMERA/VTR selector to VTR. (2) Set CM SEARCH in without cassette memory, skip this step.

  • Page 82: Searching For A Photo - Photo Search/Photo Scan

    Searching for a photo – Photo search/ Photo scan You can search for a still picture you have recorded on a tape (photo search). You can also search for still pictures one after another and display each picture for five seconds automatically regardless of cassette memory (photo scan).

  • Page 83: Scan

    Searching for a photo – Photo search/Photo scan Searching for a photo without using cassette memory (1) Set the MEMORY/CAMERA/VTR selector to VTR. (2) Set CM SEARCH in (3) Press SEARCH MODE on the Remote Commander repeatedly, until the photo search indicator appears.

  • Page 84: Playing Back A Tape With Digital Effects

    Playing back a tape with digital effects During playback, you can process a scene using the digital effect functions: STILL, FLASH, LUMI. and TRAIL. (1) In playback or playback pause mode, press DIGITAL EFFECT and turn the SEL/PUSH EXEC dial until the desired digital effect indicator (STILL, FLASH, LUMI.

  • Page 85: Editing

    — Editing — Dubbing a tape Using the A/V connecting cable Connect your camcorder to the VCR using the A/V connecting cable. Recording quality by analog input, however, is not satisfying for professional use. Before a dubbing Set DISPLAY to LCD in the menu settings. (Default setting is LCD.) (1) Insert a blank tape (or a tape you want to record over) into the VCR, and insert the recorded tape into your camcorder.
  • Page 86 Dubbing a tape Connect using an S video cable (not supplied) to obtain high-quality pictures With this connection, you do not need to connect the yellow (video) plug of the A/V connecting cable. Connect an S video cable (not supplied) to the S video jacks of both your camcorder and the VCR.
  • Page 87 Dubbing a tape You can connect only one VCR using the DV connecting cable (i.LINK cable) Pictures processed by the digital effect function Pictures processed by the digital effect function are not output through the DV IN/ OUT connector. If you record a playback pause picture with the DV IN/OUT connector The recorded picture becomes rough.

  • Page 88: Dubbing Only Desired Scenes - Digital Program Editing

    Dubbing only desired scenes – Digital program editing You can duplicate selected scenes (programs) for editing onto a tape without operating the VCR. Scenes can be selected by frame. To use this function, a DV connecting cable (i.LINK cable) (not supplied) will be required.
  • Page 89 Dubbing only desired scenes – Digital program editing Preparation 2: Adjusting the synchronization of the VCR You can adjust the synchronization of your camcorder and the VCR. Remove the cassette from the camcorder beforehand. We recommend that you prepare a pen and paper for notes. (1) Insert a recordable tape into the VCR.
  • Page 90 (14)Turn the SEL/PUSH EXEC dial to select Errors in editing If you connect your camcorder to Sony equipment with the DV jack, the range of errors is within +/– 5 frames. The range may become wider in the following conditions: •The interval between CUT-IN and CUT-OUT is less than five seconds (p.
  • Page 91 Dubbing only desired scenes – Digital program editing Operation 1: Making Programs (1) Insert the tape for playback into your camcorder, and insert a tape for recording into the VCR. (2) Push the CUSTOM PRESET/MENU switch in the MENU direction and release it to display the menu.
  • Page 92 Dubbing only desired scenes – Digital program editing (6) Press the SEL/PUSH EXEC dial, or MARK on the Remote Commander. The CUT-IN point of the first program is set, and the top part of the program mark changes to light blue. (7) Search for the end of the first scene you want to insert using the video control buttons, then pause playback (p.
  • Page 93 Dubbing only desired scenes – Digital program editing Erasing all programs (1) Select VIDEO EDIT in the menu settings. Turn the SEL/PUSH EXEC dial to select ERASE ALL, then press the dial. (2) Turn the SEL/PUSH EXEC dial to select EXECUTE, then press the dial. All the program marks flash, then the settings are canceled.

  • Page 94: Using With An Analog Video Unit And A Pc - Signal Convert Function

    Using with an analog video unit and a PC – Signal convert function You can convert the analog input signal to the digital signal and output it from the DV IN/OUT connector on this camcorder. You can capture images and sound from an analog video unit connecting a PC which has the i.LINK connector to your camcorder.
  • Page 95 Using with an analog video unit and a PC – Signal convert function Notes •When you edit the captured image and sound from the analog video unit by a PC, you need to install an appropriate software which can exchange video signals between the camcorder and a PC.

  • Page 96: Recording Video Or Tv Programs

    Recording video or TV programs Using the A/V connecting cable You can record a tape from another VCR or a TV program from a TV that has video/ audio outputs. Use your camcorder as a recorder. (1) Insert a blank tape (or a tape you want to record over) into your camcorder. If you want to record a tape from the VCR, insert a recorded tape into the VCR.

  • Page 97: Recording Video Or Tv Programs

    Your camcorder works in the commander mode, VTR 2. Commander modes 1, 2 and 3 are used to distinguish your camcorder from other Sony VCRs to avoid remote control misoperation. If you use another Sony VCR in the commander mode VTR 2, we recommend changing the commander mode or covering the sensor of the VCR with black paper.
  • Page 98 Recording video or TV programs Using a DV connecting cable (i.LINK cable) Simply connect the DV connecting cable (i.LINK cable) (not supplied) to DV IN/OUT and to DV IN/OUT of the DVCAM/DV products. With a digital-to-digital connection, video and audio signals are transmitted in digital form for high-quality editing. (1) Insert a blank tape (or a tape you want to record over) into your camcorder, and insert the recorded tape into the VCR.
  • Page 99 Your camcorder works in the commander mode, VTR 2. Commander modes 1, 2 and 3 are used to distinguish your camcorder from other Sony VCRs to avoid remote control misoperation. If you use another Sony VCR in the commander mode VTR 2, we recommend changing the commander mode or covering the sensor of the VCR with black paper.

  • Page 100: Audio Dubbing

    Audio dubbing You can record an audio sound to add to the original sound on a tape by connecting audio equipment or a microphone. If you connect audio equipment, you can add sound to your recorded tape by specifying the starting and ending points. The original sound will not be erased.
  • Page 101 We recommend that you add new sound on a tape recorded with your camcorder If you add new sound on a tape recorded with another camcorder (including an other DSR-250), the sound quality may deteriorate. When dubbing through the MIC IN +48V connector or AUDIO IN CH1/CH2 connectors You can adjust the recording level manually (p.
  • Page 102 Audio dubbing Dubbing with the AUDIO IN CH1/CH2 connectors For details on setup of the AUDIO IN CH1/CH2 connectors, see “Using an external audio system or microphone” on page 58. You can check the picture on a monitor by connecting the monitor to the VIDEO IN/ OUT jack or VIDEO OUT connector.

  • Page 103: Adding An Audio Sound On A Recorded Tape

    Audio dubbing Adding an audio sound on a recorded tape (1) Insert the recorded tape into your camcorder. (2) Set the MEMORY/CAMERA/VTR selector to VTR on your camcorder. (3) Locate the recording start point by pressing N. Then press X at the point where you want to start recording to set your camcorder to the playback pause mode.

  • Page 104: Monitoring The New Recorded Sound

    Audio dubbing Monitoring the new recorded sound To play back the sound First, select channels using the AUDIO MONITOR selector, then adjust the balance between the channels 1/2 (CH1/2) and the channels 3/4 (CH3/4) by selecting AUDIO MIX in the menu settings (p. 120). VTR SET AUD I O M I X A/V DV OUT...

  • Page 105: Setting Time Values

    Setting time values The camcorder uses two types of time values: time code values and user bits. The time value is displayed on the LCD screen, in the viewfinder, or on the display window. The user bits are convenient when using multiple cameras at the same event. When you record the picture, time code data will be recorded automatically.

  • Page 106: Setting Time Values

    Setting time values (10) Turn the SEL/PUSH EXEC dial to select SET, then press the dial. (11) Turn the SEL/PUSH EXEC dial to select TC FORMAT, then press the dial. (12) Turn the SEL/PUSH EXEC dial to select the frame mode, then press the dial. AUTO: Automatically sets the mode in accordance with the inserted cassette.
  • Page 107 Setting time values Drop-frame mode In the NTSC standard, the time code value is based on 30 frames per second, but the exact video frame frequency is in fact 29.97 frames per second and the real time, or 18 frames per 10 minutes. Drop-frame mode corrects for this by skipping two frame counts at the beginning of every minute which is not a multiple of ten.
  • Page 108 Setting time values Setting the user bits value You can set the user bits as eight-digit hexadecimal values (base 16) to have the date, time, scene number, and other information inserted into the time code. (1) Set the MEMORY/CAMERA/VTR selector to VTR or CAMERA. (2) Push the CUSTOM PRESET/MENU switch in the MENU direction and release it to display the menu.

  • Page 109: Switching The Time Value

    Setting time values Switching the time value DISPLAY SELECT Switch the DISPLAY SELECT switch as follows: TC: Displays the time code. This is indicated as “00:00:00:00” or “00:00.00:00”. U-BIT: Displays user bits. This is indicated as “00 00 00 00”. Time code/user bits Note The time code and user bits cannot be displayed properly if the tape does not have time...

  • Page 110: Superimposing A Title

    Superimposing a title If you use a tape with cassette memory, you can superimpose the title while recording or after recording. When you play back the tape, the title is displayed for five seconds from the point where you superimposed it. You can select one of eight preset titles and two custom titles (p.

  • Page 111: Superimposing A Title

    Superimposing a title If you set the REC/SAVE switch of the cassette to SAVE You cannot superimpose or erase the title. Slide the REC/SAVE switch to REC. To use a custom title If you want to use the custom title, select If the tape has a blank portion You cannot superimpose a title on that portion.
  • Page 112 Superimposing a title Title setting •The title color changes as follows: WHITE y YELLOW y VIOLET y RED y CYAN y GREEN y BLUE •The title size changes as follows: SMALL y LARGE You cannot input more than 12 characters in LARGE size. •If you select the title size “SMALL,”...

  • Page 113: Erasing A Title

    Superimposing a title Erasing a title (1) Set the MEMORY/CAMERA/VTR selector to VTR or CAMERA. (2) Push the CUSTOM PRESET/MENU switch in the MENU direction and release it to display the menu. (3) Turn the SEL/PUSH EXEC dial to select (4) Turn the SEL/PUSH EXEC dial to select TITLEERASE, then press the dial.

  • Page 114: Making Your Own Titles

    Making your own titles You can make up to two titles and store them in cassette memory. Each title can have up to 20 characters. (1) Press TITLE in the standby, playback, or playback pause mode. (2) Turn the SEL/PUSH EXEC dial to select (3) Turn the SEL/PUSH EXEC dial to select CUSTOM1 SET or CUSTOM2 SET, then press the dial.
  • Page 115 Making your own titles To change a title you have stored In step 3, select CUSTOM1 SET or CUSTOM2 SET, depending on which title you want to change, then press the SEL/PUSH EXEC dial. Turn the SEL/PUSH EXEC dial to select [C], then press the dial to delete the title.

  • Page 116: Labeling A Cassette

    Labeling a cassette If you use a tape with cassette memory, you can label a cassette. The label can consist of up to 10 characters and is stored in cassette memory. When you insert the labeled cassette and set the MEMORY/CAMERA/VTR selector to VTR, CAMERA, or MEMORY, the label is displayed for about five seconds.
  • Page 117 Labeling a cassette To change the label you have made Insert the cassette to change the label, and operate in the same way as you do to make a new label. If you set the REC/SAVE switch of the cassette to SAVE You cannot label the tape.

  • Page 118: Erasing The Cassette Memory Data

    Erasing the cassette memory data You can erase data stored in cassette memory, each item’s data can be erased separately. You can also erase all items’ data once. Erasing each item’s data separately (1) Set the MEMORY/CAMERA/VTR selector to VTR or CAMERA. (2) Push the CUSTOM PRESET/MENU switch in the MENU direction and release it to display the menu.

  • Page 119: Erasing The Cassette Memory Data

    Erasing the cassette memory data To cancel erasing Select RETURN in step 6 or 7, then press the SEL/PUSH EXEC dial. Erasing all the data in cassette memory (1) Set the MEMORY/CAMERA/VTR selector to VTR or CAMERA. (2) Push the CUSTOM PRESET/MENU switch in the MENU direction and release it to display the menu.

  • Page 120: Customizing Your Camcorder

    Changing the menu settings To change the mode settings in the menu settings, select the menu items with the SEL/ PUSH EXEC dial. The default settings can be partially changed. First, select the icon, then the menu item and then the mode. (1) In the standby, VTR, or MEMORY mode, push the CUSTOM PRESET/MENU switch in the MENU direction and release it.
  • Page 121 Changing the menu settings To make the menu display disappear Push the CUSTOM PRESET/MENU switch in the MENU direction and release it. Menu items are displayed as the following icons: TC/UB SET MANUAL SET CAMERA SET VTR SET LCD SET MEMORY SET CM SET TAPE SET...
  • Page 122 Changing the menu settings Icon/item Mode SHTR SPEED — GAIN LEVEL — AUTO SHTR z ON PROG. SCAN z OFF SETUP z 0 % D ZOOM z OFF 16:9WIDE z OFF STEADYSHOT z ON FRAME REC z OFF INT. REC z OFF Notes on the SteadyShot function •The SteadyShot function will not correct excessive camera-shake.
  • Page 123 Changing the menu settings Icon/item Mode AUDIO MIX — A/VtDV OUT z OFF LCD COLOR — GUIDEFRAME z OFF CONTINUOUS z OFF MULTI SCRN QUALITY z SUPER FINE FINE STANDARD Meaning To adjust the balance between the channels 1/2 (CH1/2) and channels 3/4 (CH3/4) (p.
  • Page 124 Changing the menu settings Icon/item Mode PRINT MARK z OFF PROTECT z OFF SLIDE SHOW — DELETE ALL — FORMAT z RETURN PHOTO SAVE — CM SEARCH z ON TAPE TITLE — TITLE DSPL z ON TITLEERASE — Formatting erases all information on the “Memory Stick” Check the contents of the “Memory Stick”...
  • Page 125 Changing the menu settings Icon/item Mode ITEM ERASE — ERASE ALL — REC MODE z DVCAM DV SP AUDIO MODE z FS32K FS48K z AUTO qREMAIN DATA CODE z DATE/CAM DATE A REF LVL z –12dB –20dB Notes on AUDIO MODE •You cannot dub audio sound on a tape recorded in the Fs48K (16-bit) mode.
  • Page 126 Changing the menu settings Icon/item Mode CLOCK SET — LTR SIZE z NORMAL z LI-ION uREMAIN LOGO INS — WORLD TIME — BEEP z NORMAL COMMANDER z ON Meaning To reset the date or time (p. 128). To display selected menu items in normal size.
  • Page 127 Changing the menu settings Icon/item Mode DISPLAY z LCD V-OUT/LCD EXT RECCTL z OFF DATE REC z OFF COLOR BAR z OFF VIDEO EDIT — EDIT SET — HRS METER OPERATION DRUM RUN TAPE RUN THREADING Notes •If you press DISPLAY with DISPLAY set to V-OUT/LCD in the menu settings, the picture from a TV or VCR will not appear on the LCD screen even when your camcorder is connected to outputs on the TV or VCR (except using a DV connecting cable (i.LINK cable)).

  • Page 128: Resetting The Date And Time

    Resetting the date and time The date and time are set at the factory. Set the time according to the local time in your country. If you remove power sources from your camcorder for about four months, the date and time settings may be released because the vanadium-lithium battery installed in your camcorder will have been discharged (p.

  • Page 129: Memory Stick" Operations

    — “Memory Stick” Operations — Using a “Memory Stick” – introduction You can record and play back still images on the “Memory Stick” supplied with your camcorder. You can easily play back, record or delete still images. You can exchange image data with other equipment such as a personal computer etc., using the Memory Stick Reader/Writer supplied with your camcorder or a PC card adaptor for Memory Stick (not supplied).
  • Page 130 •Macintosh and Mac OS are trademarks of Apple Computer, Inc. •All other product names mentioned herein may be the trademarks or registered trademarks of their respective companies. Furthermore, “™” and “®” are not mentioned in each case in this manual. are trademarks of Sony Corporation.
  • Page 131 Using a “Memory Stick” – introduction Inserting a “Memory Stick” Open the “Memory Stick” cover, and insert the “Memory Stick” with the Sony logo pointing toward the LCD panel and the b mark pointing inward. Access lamp To eject a “Memory Stick”...

  • Page 132: Image Quality Settings

    Using a “Memory Stick” – introduction Selecting the image quality mode You can select the image quality mode in still picture recording. The default setting is SUPER FINE. (1) Set the MEMORY/CAMERA/VTR selector to VTR or MEMORY. (2) Push the CUSTOM PRESET/MENU switch in the MENU direction and release it to display the menu.
  • Page 133 Using a “Memory Stick” – introduction Note In some cases, changing the image quality mode may not affect the image quality, depending on the types of images you are shooting. Differences in image quality mode Recorded images are compressed in JPEG format before being stored in memory. The memory capacity allotted to each image varies depending on the image quality mode selected.

  • Page 134: Recording Still Images On A "Memory Stick" - Memory Photo Recording

    Recording still images on a “Memory Stick” – Memory Photo recording You can record still images on a “Memory Stick.” Before operation Insert a “Memory Stick” into your camcorder. (1) Set the MEMORY/CAMERA/VTR selector to MEMORY. (2) Keep pressing PHOTO lightly until the desired still picture appears. The green z mark stops flashing, then lights up.
  • Page 135 Recording still images on a “Memory Stick” – Memory Photo recording While you are recording a still image You can neither turn off the power nor press PHOTO. When you press PHOTO on the Remote Commander Your camcorder immediately records the image that is on the screen when you press the button.
  • Page 136 Recording still images on a “Memory Stick” – Memory Photo recording (1) Set the MEMORY/CAMERA/VTR selector to MEMORY. (2) Push the CUSTOM PRESET/MENU switch in the MENU direction and release it to display the menu. (3) Turn the SEL/PUSH EXEC dial to select (4) Turn the SEL/PUSH EXEC dial to select CONTINUOUS, then press the dial.

  • Page 137: Recording An Image From A Tape As A Still Image

    Recording an image from a tape as a still image Your camcorder can read moving picture data recorded on a tape and record it as a still image on a “Memory Stick.” Your camcorder can also take in moving picture data through the input connector and record it as a still image on a “Memory Stick.”...

  • Page 138: Recording An Image From A Tape As A Still Image

    Recording an image from a tape as a still image Titles that are already recorded on tapes You cannot record the titles on a “Memory Stick.” When you press PHOTO on the Remote Commander Your camcorder immediately records the image that is on the screen when you press the button.
  • Page 139 Recording an image from a tape as a still image When recording the image through the DV IN/OUT connector S1 VIDEO LANC DV IN/ DV IN/OUT DV connecting cable (i.LINK cable) (not supplied) : Signal flow...

  • Page 140: Copying Still Images From A Tape - Photo Save

    Copying still images from a tape – Photo save Using the search function, you can automatically take in still images from tapes and record them on a “Memory Stick” in sequence. Before operation •Insert a recorded tape into your camcorder and rewind the tape. •Insert a “Memory Stick”...

  • Page 141: Photo Save

    Copying still images from a tape – Photo save To cancel copying Push the CUSTOM PRESET/MENU switch in the MENU direction and release it again. When the memory of the “Memory Stick” is full “MEMORY FULL” appears on the LCD screen or in the viewfinder, and the copying stops.

  • Page 142: Viewing A Still Picture - Memory Photo Playback

    Viewing a still picture – Memory Photo playback You can play back still images recorded on a “Memory Stick.” You can also play back six images at a time by selecting the index screen. Before operation Insert a “Memory Stick” into your camcorder. (1) Set the MEMORY/CAMERA/VTR selector to VTR or MEMORY.
  • Page 143 Viewing a still picture – Memory Photo playback When the auto logo insert function is activated You cannot do memory photo playback. Refer to the extra operating instructions, “Auto Logo Insert for Copyright Protection.” Screen indicators during still image playback 100–0002 Data file name On data file name...
  • Page 144 Viewing a still picture – Memory Photo playback Playing back six recorded images at a time (index screen) You can play back six recorded images at a time. This function is especially useful when searching for a particular image. (1) Set the MEMORY/CAMERA/VTR selector to VTR or MEMORY. (2) Press MEMORY INDEX to display the index screen.
  • Page 145 Viewing a still picture – Memory Photo playback Files modified with personal computers These files may not be displayed on the index screen. Image files shot with other equipment may not be displayed on the index screen either. Note When displaying the index screen, a number appears above each image. This indicates the order in which images are recorded on the “Memory Stick.”...

  • Page 146: Copying An Image Recorded On A "Memory Stick" To Tapes

    Copying an image recorded on a “Memory Stick” to tapes You can copy still images or titles recorded on a “Memory Stick” and record them to a tape. Before operation Insert a tape for recording and a “Memory Stick” for playback into your camcorder. (1) Set the MEMORY/CAMERA/VTR selector to VTR.
  • Page 147 Copying an image recorded on a “Memory Stick” to tapes Note on the index screen You cannot record the index screen. Image data modified with personal computers or shot with other equipment You may not be able to copy them with your camcorder. If you press DISPLAY in standby or recording mode You can see memory playback and the file name indicators in addition to the indicators pertinent to tapes, such as the time code indicator.

  • Page 148: Playing Back Images Continuously - Slide Show

    Playing back images continuously – SLIDE SHOW You can automatically play back images in sequence. This function is useful especially when checking recorded images or during a presentation. Before operation Insert a “Memory Stick” into your camcorder. (1) Set the MEMORY/CAMERA/VTR selector to MEMORY. (2) Push the CUSTOM PRESET/MENU switch in the MENU direction and release it to display the menu.

  • Page 149: Preventing Accidental Erasure - Image Protection

    Preventing accidental erasure – Image protection To prevent accidental erasure of important images, you can protect selected images. Before operation Insert a “Memory Stick” into your camcorder. (1) Set the MEMORY/CAMERA/VTR selector to MEMORY or VTR. (2) Play back the image you want to protect (p. 142). (3) Push the CUSTOM PRESET/MENU switch in the MENU direction and release it to display the menu.
  • Page 150 Preventing accidental erasure – Image protection Note Formatting erases all information on the “Memory Stick,” including the protected image data. Check the contents of the “Memory Stick” before formatting. If the write-protect tab on the “Memory Stick” is set to LOCK You cannot carry out image protection.

  • Page 151: Deleting Images

    Deleting images You can delete images stored in a “Memory Stick.” Deleting selected images Before operation Insert a “Memory Stick” into your camcorder. (1) Set the MEMORY/CAMERA/VTR selector to MEMORY or VTR. (2) Play back the image you want to delete (p. 142). (3) Press MEMORY DELETE.

  • Page 152: Deleting Images

    Deleting images Deleting all the images You can delete all the unprotected images in a “Memory Stick.” Before operation Insert a “Memory Stick” into your camcorder. (1) Set the MEMORY/CAMERA/VTR selector to MEMORY. (2) Push the CUSTOM PRESET/MENU switch in the MENU direction and release it to display the menu.
  • Page 153 Deleting images To cancel deleting all the images in the “Memory Stick” Select RETURN in step 5, then press the SEL/PUSH EXEC dial.

  • Page 154: Writing A Print Mark - Print Mark

    Writing a print mark – Print mark You can specify the recorded still image to be printed out. This function is useful for printing out still images later. Your camcorder conforms with the DPOF (Digital Print Order Format) standard for specifying the still images to print out.
  • Page 155 Writing a print mark – Print mark If the write-protect tab on the “Memory Stick” is set to LOCK You cannot write print marks on still images. When the auto logo insert function is activated You cannot use this function. Refer to the extra operating instructions, “Auto Logo Insert for Copyright Protection.”...

  • Page 156: Additional Information

    Compatibility of DVCAM and DV formats DVCAM format is developed as a more reliable and higher end format than consumer DV format. Here explained are the differences, compatibility, and limitations on editing about DVCAM and DV formats. Differences between DVCAM and DV formats Item Track pitch Audio sampling...
  • Page 157 Compatibility of DVCAM and DV formats Compatibility on editing using DV connectors When this digital camcorder is connected to other DVCAM or DV video equipment using DV connectors, the recording format of edited tapes is defined according to recorder’s format as described below. Source tape DVCAM-formatted DVCAM-formatted...

  • Page 158: Usable Cassettes

    * There are two types of DVCAM/DV cassettes: with cassette memory and without cassette memory. Tapes with cassette memory have Sony recommends that you use a tape with The IC memory is built in the cassette with cassette memory. Using this IC memory, your camcorder can read, write, and search data such as the date of recording or titles.
  • Page 159 Usable cassettes Copyright signal When you play back When you connect your camcorder to any other video camera recorder to dub a tape that has recorded copyright control signals for copyright protection, you may not record the tape that played back on your camcorder. When you record You cannot record software on your camcorder that contains copyright control signals for copyright protection of software.
  • Page 160 Usable cassettes Notes on the DVCAM/DV cassette When affixing a label on the DVCAM/DV cassette Be sure to affix a label only on the locations as illustrated below [a] so as not to cause malfunction of your camcorder. After using the DVCAM/DV cassette Rewind the tape to the beginning, put the cassette in its case, and store it in an upright position.

  • Page 161: About I.link

    Tips •i.LINK, a nickname for IEEE 1394 that Sony proposed, is a trademark supported by a majority of companies worldwide. •IEEE 1394 is an international standard defined by IEEE, The Institute of Electrical and Electronics Engineers, Inc.

  • Page 162: Troubleshooting

    If you run into any problem using your camcorder, use the following table to troubleshoot the problem. If the problem persists, disconnect the power source and contact your Sony dealer or local authorized Sony service facility. If “C:ss:ss” appears on the LCD screen or in the viewfinder, the self-diagnosis display function has worked.

  • Page 163: Troubleshooting

    • The tape has run out. c Rewind the tape. (p. 33) • The video head may be dirty. c Clean the heads using the Sony DVM12CL cleaning cassette (not supplied). (p. 173) • The volume is turned to minimum.
  • Page 164 Troubleshooting Symptom The new sound now being added, or that has been added to the recorded tape is not heard. The title is not displayed. The sound is muted or images do not appear when monitoring images through a monitor. The recorded sound is distorted.
  • Page 165 Troubleshooting Symptom The cassette cannot be removed from the holder. The % and Z indicators flash and no functions except for cassette ejection work. indicator does not appear when using a tape with cassette memory. Remaining tape indicator is not displayed. When operating using the “Memory Stick”...
  • Page 166 Troubleshooting Symptom You cannot write a print mark on the still image. The photo save function does not work. Others Symptom The title is not recorded. The cassette label is not recorded. While editing using the DV connecting cable (i.LINK cable), recording picture cannot be monitored.
  • Page 167 Troubleshooting Symptom The Remote Commander supplied with your camcorder does not work. The input picture does not appear on the LCD screen or in the viewfinder when your camcorder is connected to outputs on the TV or VCR. The melody or beep sounds for five seconds.

  • Page 168: Self-Diagnosis Display

    After reconnecting the power source, operate your camcorder. •A malfunction that you cannot service has occurred. c Contact your Sony dealer and inform them of the 5-digit code. (example: E:61:10) On the LCD screen or in the viewfinder...

  • Page 169: Warning Indicators And Messages

    Warning indicators and messages If indicators and messages appear on the LCD screen or in the viewfinder, check the following: See the page in parentheses “( )” for more information. Warning indicators E The battery is dead or nearly dead Slow flashing: •The battery is nearly dead.
  • Page 170 Check if the “Memory Stick” is inserted properly, or insert the “Memory Stick” with logo data. The data setting of the logo insert system is corrupted. Consult your Sony dealer or local authorized Sony service facility.

  • Page 171: Using Your Camcorder Abroad

    Using your camcorder abroad Using your camcorder abroad You can use your camcorder in any country or area with the optional AC power adaptor within 100 V to 240 V AC, 50/60 Hz. When charging the battery pack, use a commercially available AC plug adaptor [a], if necessary, depending on the design of the wall outlet [b].

  • Page 172: Maintenance Information And Precautions

    Maintenance information and precautions Moisture condensation If your camcorder is brought directly from a cold place to a warm place, moisture may condense inside your camcorder, on the surface of the tape, or on the lens. In this condition, the tape may stick to the head drum and be damaged or your camcorder may not operate correctly.
  • Page 173 LCD screen or in the viewfinder. If the above problem, [a] or [b] occurs, clean the video heads for 10 seconds with the Sony DVM12CL cleaning cassette (not supplied). Check the picture and if the above problem persists, repeat cleaning.
  • Page 174 •If any solid object or liquid get inside the casing, unplug your camcorder and have it checked by a Sony dealer before operating it any further. •Avoid rough handling or mechanical shock. Be particularly careful of the lens. •Keep the POWER switch set to OFF when you are not using your camcorder.
  • Page 175 •If you touch the liquid, wash it off with water. •If the liquid get into your eyes, wash your eyes with a lot of water and then consult a doctor. If any problem occurs, unplug your camcorder and contact your nearest Sony dealer.

  • Page 176: Specifications

    Specifications Video camera recorder System Video recording system 2 rotary heads Helical scanning system Audio recording system Rotary heads, PCM system Quantization: Fs32 kHz (12 bits, channels 1/2, channels 3/4), Fs48 kHz (16 bits, channels 1/2) Video signal NTSC color, EIA standards Usable cassette DVCAM cassette with the mark printed...

  • Page 177: Quick Reference

    4 Focus ring (p. 45) 5 START/STOP button (p. 15) 6 SHUTTER switch (p. 40) This mark indicates that this product is a genuine accessory for Sony video products. When purchasing Sony video products, Sony recommends that you purchase accessories with this “GENUINE VIDEO ACCESSORIES”...
  • Page 178 Identifying the parts and controls qd AUTO MODE switch (p. 36) qf ATW switch (p. 47) qg AGC switch (p. 38) qh GAIN selector (p. 38) qj WHITE BAL switch (p. 47) 5800K PRESET PRESET 3200K 3200K qk DISPLAY button (p. 31) ql AUDIO LEVEL button (p.
  • Page 179 Identifying the parts and controls wf Remote sensor wg TALLY lamp (p. 16) wh TALLY switch (p. 16) wj EJECT button (p. 13) wk DC IN 12V connector (p. 11) wl DC OUT 12V connector (p. 58) e; LIGHT connector (p. 60) ea START/STOP button (p.
  • Page 180 Identifying the parts and controls eh MEMORY DELETE button (p. 151) ej MEMORY MIX button (p. 71) ek MEMORY INDEX button (p. 144) el MEMORY PLAY button (p. 142) r; MEMORY +/– buttons (p. 71, 142) ra DATA CODE button (p. 31) rs TITLE button (p.
  • Page 181 Identifying the parts and controls MEMORY MEMORY AUDIO AUDIO PLAY PLAY INDEX INDEX DELETE DELETE MONITOR MONITOR CH-1 CH-1 MEMORY MIX MEMORY MIX CH-2 CH-2 DISPLAY DISPLAY DATA CODE DATA CODE END SEARCH END SEARCH SELECT SELECT U-BIT U-BIT TITLE TITLE DIGITAL EFFECT DIGITAL EFFECT...
  • Page 182 Identifying the parts and controls LINE LINE +48V th LCD screen (p. 22) tj LCD BRIGHT +/– buttons (p. 23) tk LCD switch (p. 22) tl LINE/MIC (CH1/CH2) selectors (p. 58) On BREAKER (breaker reset) button If an excessive current flows in the internal circuits, the internal circuit breaker shuts off the power supply.
  • Page 183 VIDEO OUT connector (p. 35) DV IN/OUT connector (p. 86, 98, 139) This “i.LINK” mark is a trademark of Sony Corporation and indicates that this product is in agreement with IEEE 1394- 1995 specifications and their revisions. The DV IN/OUT connector is i.LINK compatible.
  • Page 184 To remove the lens hood for attachment of the wide teleconversion lens, etc., loosen the lens hood fixing screw, and unscrew the lens hood counterclockwise. When using additional filters We recommend that you use the Sony made filters having the genuine accessory mark. Fastening the grip strap Fasten the grip strap firmly.
  • Page 185 Identifying the parts and controls ik SPOT LIGHT button (p. 28) il BACK LIGHT button (p. 27) o; ND FILTER selector (p. 17) oa FOCUS selector (p. 45) os FOCUS PUSH AUTO button (p. 45) od FADER button (p. 67) of POWER switch (p.
  • Page 186 Identifying the parts and controls Viewfinder HIGH LOW 1 TAKE/TALLY lamp This lamp is not used with the camcorder. 2 REC/TALLY lamps (p. 15) The below REC lamp is not used with the camcorder. 3 Eyepiece focusing knob (p. 20) 4 Stopper (p.
  • Page 187 Identifying the parts and controls Removing the viewfinder Remove any microphone from the viewfinder before beginning. (1) Pull the viewfinder connector out of the VF connector on the front. (2) Loosen the viewfinder left-to-right positioning ring, then pulling up the stopper, slide the viewfinder out.
  • Page 188 Identifying the parts and controls Identifying the parts and controls Remote Commander The buttons that have the same name on the Remote Commander as on your camcorder function identically to the buttons on your camcorder. 1 Transmitter Point toward the remote sensor to control your camcorder after turning on your camcorder.
  • Page 189 •Your camcorder works in the commander mode VTR 2. Commander modes 1, 2 and 3 are used to distinguish your camcorder from other Sony VCRs to avoid remote control misoperation. If you use another Sony VCR in the commander mode VTR 2, we recommend changing the commander mode or covering the sensor of the VCR with black paper.

  • Page 190: Operation Indicators

    Identifying the parts and controls Operation indicators 1 Cassette memory indicator (p. 26) 2 Remaining battery capacity indicator (p. 26) 3 Zoom indicator (p. 24)/Data file name indicator (p. 129) 4 Digital effect indicator (p. 69)/FADER indicator (p. 67)/MEMORY MIX indicator (p.

  • Page 191: Quick Function Guide

    Quick Function Guide Functions to adjust exposure (in the recording mode) •Adjusting lights amount for shooting •Shooting backlit subjects •In spotlight, such as at the theater or a formal event Functions to give images more impact (in the recording mode) •Smooth transition between scenes •Taking a still picture •Digital processing of images...

  • Page 192: Index

    F, G, H Fade in/out ... 67 FADER ... 67 FLASH MOTION ... 69 FOCUS ... 45 Format ... 124 Sony Corporation Printed in Japan FRAME REC ... 76 GAIN ... 38 Grip strap ... 184 Guide frame ... 52 Heads ...

This manual is also suitable for:

Dsr 250 - pro dvcam digital camcorderDsr-250p

Table of Contents
