Horizon Fitness BOOK BINDER BQ-470 Important Information Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

BOOK BINDER
BOOK BINDER
Important Information
• This manual is designed to help you to install, operate and maintain the BQ-470/
BQ-470D Book Binder. Please read and understand this manual, and keep it in a
safe and convenient place.
• Do not operate the BQ-470/BQ-470D until you read and understand the
instructions in this manual.
• Horizon International Inc. shall not be liable for incidental consequential
damages resulting from: improper or inadequate maintenance by the customer,
unauthorized modification or misuse, or operation outside of the environmental
specifications for the product.
• Horizon International Inc. pursues a policy of continuing improvement in design
and performance of the product. Therefore, the product design and
specifications are subject to change without prior notice and without our legal
obligation.
• All rights are reserved. No part of this manual may be photocopied, reproduced
or translated to another language without the prior written consent of Horizon
International Inc.
151210/BQ470/30E/HN,TM,HK/F7/IXI/PXI
BQ-470/BQ-470D
UM202064-30(000)
I
