Amana AM9S96 Manual

Heating Input: 40,000-120,000 BTU/h
Standard Features
• Heavy-duty stainless-steel tubular heat exchanger
• Stainless-steel secondary heat exchanger
• Single-stage gas valve
• Durable Silicon Nitride igniter
• Quiet single-speed induced draft blower
• Self-diagnostic control board with constant
memory fault code history output to a LED
• All models comply with California 40 ng/J
Low NOx emissions standard
• Can no longer be installed in California's
South Coast Air Quality Management District
(SCAQMD) on or after October 1, 2019.
• AHRI Certified; ETL Listed
SS-AM9S96/AC9S96
Amana® is a trademark of Maytag Corporation or its related companies and used under license to Goodman Company, L.P., Houston, Texas.
Cabinet Features
• Designed for multi-position installation -
AM9S96: upflow, horizontal left or right
AC9S96: downflow, horizontal left or right
• Certified for direct vent (2-pipe)
or non-direct vent (1-pipe)
• Easy-to-install top venting with optional side venting -
AM9S96/upflow models only
• Convenient left or right connection
for gas and electrical service
• Cabinet air leakage (Q
• Heavy-gauge steel cabinet with durable finish
• Fully insulated heat exchanger and blower section
• Airtight solid bottom or side return with
easy-cut tabs for effortless removal in
bottom air-inlet applications
* Complete warranty details available from your local dealer or at www.amana-hac.com. To receive the Lifetime Heat Exchanger Limited
Warranty (good for as long as you own your home), 10-Year Unit Replacement Limited Warranty and 10-Year Parts Limited Warranty, online
registration must be completed within 60 days of installation. Online registration is not required in California or Québec.
www.amana-hac.com
AM9S96/AC9S96
Single-Stage, Multi-Speed
ECM Gas Furnace
Up to 96% AFUE
Contents
Nomenclature ............................................2
Product Specifications ............................... 3
Dimensions ................................................5
Airflow Specifications ................................7
Wiring Diagram ........................................19
Accessories ..............................................20
) ≤ 2%
Leak
2/22
Supersedes 8/21
