Summary of Contents for Fisher PC-R20R2
- Page 2 One blade of the power plug is wider than the other for safety purposes and will fit into the outlet , contact your dealer. If any liquid or solid object falls into the TV , unplug it and have it checked by qualified personnel before operating it further.
-
Page 3: Owner's Record
Protecting the TV To prevent internal heat build-up, do not block the ventilation openings. Do not install the TV in a hot or humid place , or in a place subject to excessive dust or mechanical vibration. Note on Caption Vision This television receiver provides display of television closed captioning in accordance with rules . -
Page 4: Power Sources
Power Sources This set should be operated only from the type of power source indicated on the serial /model plate. If you are not sure of the type of electrical power supplied to your home, consult your dealer or local power company .For those sets designed to operate from battery power, refer to the operating instructions. - Page 5 Do not defeat the safety purpose of the grounding plug. If a snapping or popping sound from a TV set is continuous or frequent while the TV is operating ,unplug the TV and consult your dealer or service technician .IT is normal for some TV sets to make...
- Page 6 Grounding or Polarization This set may be equipped with a polarized alternating current line plug (a plug having one blade wider than other ). This plug will fit into the power outlet only one way .This is a safety feature, If you are unable to insert the plug fully into the outlet , try reversing the plug .If the plug should still fail to fit , contact you electrician to replace your obsolete outlet .Do not defeat the safety purpose of the polarized plug.
-
Page 7: Replacement Parts
Service Damage Requiring Service Unplug the set from the wall outlet and refer servicing to qualified service personnel under the following conditions: When the power cord or plug is damaged or frayed. If liquid has been spilled into the set or objects have fallen into the product. -
Page 8: Radio Frequency Interference Statement
- Connect the equipment into and outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio /TV technician for help. Any special accessories needed for compliance must be specified in the instruction manual . - Page 9 MANUAL OF CONTENTS CHAPTER 1 : APPEARANCE --------------------------------------------------------------------------------10 CHAPTER 2 : TURN ON THE TV AND SETUP CHAPTER 3 : DESCRIPTION OF MENU CHAPTER 4 : DESCRIPTION OF REMOTER CHAPTER 5 : SERVICE TIPS --------------------------------------------------------------------------------- 18 CHAPTER 6 : SPECIFICATION...
-
Page 10: Control Location
3. Main Switch 4. Speakers 5. Program Down & Up Button 6. Volume Down & Up Button 7. Menu Button 8. AV/TV Button 9. Front AV In (Option) 10. Audio/Video - In/Out Jack 11. AC Power Cord 12. Terminal Antenna (75 Ohm) -
Page 11: Input And Output Terminals
CHAPTER 2 : INPUT AND OUTPUT TERMINALS VIDEO AND AUDIO INPUT/OUTPUT TERMINALS 1. Video / Audio input for playback for VCR. 2. Video / Audio output for TV monitor output. *Please keep AC cord unplugged when connecting TV system. VIDEO VIDEO NOTE: This is a mono CTV even though there are R &... -
Page 12: Operation Instructions
CHAPTER 3 : CHAPTER 3 : OPERATION INSTRUCTIONS Turn the TV set on, then power indicator will light up. After a few seconds , the currently program number is displayed on the top right -hand corner of the screen. MENU BUTTON 1.Press this button to select menu. - Page 13 Set the V-Chip OFF or ON . V-Chip MPAA 2.MPAA movie rating TVPG TV-14 Content-V Select the type of program Content-S 3.TVPG(TV Parental Guidelines) Content-L Content-D Parents can guide their children watching some programmes by the item. Espanol Portugues -13-...
-
Page 14: Scan Button
CHAPTER 4 : LOCATION OF CONTROL (REMOTE HANDSET UNIT) POWER (STAND BY) BUTTON ( Press this button to turn the TV on/off. SCAN BUTTON Press this button , you can automatically browse the every channels which you have . MUTE BUTTON ( Press once to mute the sound, press again to return to previously set sound level. -
Page 15: Language Button
This key is used to set the sleep timer in 10 minutes step up to four hours. Before the 30 minutes ,the interval is 10 minutes .After the 30 minutes ,the interval is 30 minutes . When the preset time runs to 0. TV set will go into stand by mode. -
Page 16: Lock Button
LOCK BUTTON Press the "LOCK" button ,The key locked ( disappear after five seconds and enter child locked mode. You can't use any key on the TV set. *You can cancel this mode by pressing the 'LOCK" button again. *The locked key for control or prevent your children from watching the program. -
Page 17: The Causes Of Interference
3. Replace the battery cover. Replace with new batteries when the TV set begins to show the following symptoms: Operation is unsteady or erratic. Sometimes the TV set does not function with Remote Control Unit. Remark: 1) Alkaline Batterie Recommended 2) Remove batteries when they are exhausted or if the remote control is not to be used for a long time. -
Page 18: Service Tips
CHAPTER 5 : CHAPTER 5 : SERVICE TIPS BEFORE CALLING FOR SERVICE, HAVE YOU CHECKED ( ) THE FOLLOWING CHART ON SYMPTOMS AND SOLUTIONS? Symptoms No picture, no sound Poor sound, picture OK Poor picture, sound OK Weak picture Blurred picture Double image Lines in picture Distorted picture... -
Page 19: Specifications
525(W) x 510(D) x 464(H)mm/ 20.7(W) x 20.1(D) x 18.3(H)inch : 22.8 Kg/50.26lbs : Infrared : DC 3V (1.5 x 2) : 60(W) x 200(L) x 24(D)mm/ (W) x 7.9(L) x 0.9(D)inch : 100 g(approx)/0.22lbs SANYO Sales & Marketing Corporation -19-... - Page 20 -20-...
