- Page 1 OWNERS'S MANUAL REFRIGERATOR- FREEZER Please read carefully the manual instruction and safety caution before operating your refrigerator and retain it for future reference GR-M602GSH GR-M603GPH GR-M602GLC GR-M702GSH GR-M703GPH GR-M702GLC P/No : MFL67239905 www.lg.com...
-
Page 2: Table Of Contents
CONTENTS IMPORTANT SAFETY INFORMATION ....3 INSTALLATION ............11 INNER PARTS ............12 OPERATIONS ............13 Starting Before Setting The Temperature Door Alarm Self Test Controls For Refrigerator Compartment Fast Freezing Child Lock Hygiene Fresh (Optional) Controls For Freezer Compartment Ice Making Vegetable Drawer Refreshment Center (Optional) -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION WARNING Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. Do not damage the refrigerant circuit. Do not use electrical appliances inside the food storage compartment of the appliance, unless they are of the type recommended by the manufacturer. - Page 4 IMPORTANT SAFETY INFORMATION BASIC SAFETY PRECAUTIONS This guide contains many important safety messages. Always read and obey all safety messages. This is the safety alert symbol. It alerts you to safety messages that inform you of hazard that can hurt you or others or cause damage to the product. All safety messages will be preceded by the safety alert symbol and the hazard signal word WARNING, or CAUTION.
- Page 5 IMPORTANT SAFETY INFORMATION 1. When connecting the power Unplug the power plug when cleaning, Do not change the mains handling or replacing the interior lamp of the cable and do not change its length. It may damage refrigerator. the cable and cause fire •...
- Page 6 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Do not place heavy or dangerous Do not cling to the doors, door objects such on baskets, drawers or shelves. the top of the appliance. These may cause the refrigerator When opening or closing the to fall or lead to hand injuries.
- Page 7 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Do not use drier to dry the inside, nor light a Don't use heating candle to remove odor. devices close to the It may cause explosion or appliance. fire. It may cause fire. Do not use the combustible spray near the Do not use the refrigerator if it has been refrigerator.
- Page 8 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Only qualified technician When any strange smell or smoke is should disassemble, detected from the refrigerator, disconnect repair or alter the the power plug Service refrigerator. Down-block center immediately and office contact to the service center.
- Page 9 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Place all the components in the right places Do not remove the cover before connecting the power. on the back. Do not use an Adapter Never leave lit candles or incense on the on the back.
- Page 10 IMPORTANT SAFETY INFORMATION Do not put any living animal into Do not use products such as grinding the refrigerator. sponge, brush, iron, or even special products to clean stainless steel, soap It may cause the animal products such as alcohol, kerosene, died.
-
Page 11: Installation
THIS REFRIGERATOR IS MANUFACTURED WITH GREAT CARE, AND UTILIZES THE LATEST IN TECHNOLOGY. WE ARE CONFIDENT THAT YOU WILL BE FULLY SATISFIED WITH IT'S PERFORMANCE AND RELIABILITY. BEFORE YOU START YOUR REFRIGERATOR, PLEASE READ THIS BOOKLET CAREFULLY . IT PROVIDES EXACT INSTRUCTIONS FOR INSTALLATION, OPERATION AND MAINTENANCE, AND ALSO SUPPLIES SOOME USEFUL HINTS. -
Page 12: Inner Parts
INNER PARTS FREEZER Twisting Ice Serve Type Ice Making COMPARTMENT Lamp Shelf Freezer Temperature Freezer Door Rack Control Dial REFRIGERATOR COMPARTMENT Refrigerator Door Rack Deodorizer (Optional) Green Ion Door Cooling Fresh Zone (Optional) Egg Tray Lamp Shelves Refreshment Center (Optional) (Optional) Hygiene Fresh (Optional) -
Page 13: Operations
OPERATIONS STARTING When your refrigerator is first installed, allow it 2-3 hours to stabilize at normal operating temperatures prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. BEFORE SETTING THE TEMPERATURE The temperature of the refrigerator is kept constant regardless of changes in room temperature. -
Page 14: Fast Freezing
OPERATIONS FOR EXTERNAL CONTROLLER MODEL Display graphic can be different, depend on the type of your refrigerator. Type a Type b Press 'REFRIGERATOR' button to control refrigerator temperature. Whenever pressing the button, the LED emits light. Press ‘HYGIENE FRESH’ button to operate hygiene motor (optional). The number showing up on the LED luminesce indicate the temperature of refrigerator compartment. -
Page 15: Hygiene Fresh (Optional)
OPERATIONS HYGIENE FRESH (OPTIONAL) CAUTION Before installing or using the product, make sure to read the owner's manual carefully to use the product accurately as intended. This HYGIENE FRESH filter has the antibacterial function of removing the virus or bacteria inside the refrigerator and the deodorizer function to remove the scent. The function has tested and has been certificated by authorized institutions Intertek Life of the filter is about 1 to 2 years. - Page 16 OPERATIONS Set replacement timing (Initialization) After the user replaces the filter, the user can set the time for the next replacement. Close the refrigerator door and press the • button on the display panel on the front side of the he front side of the During use notify When switched...
-
Page 17: Controls For Freezer Compartment
OPERATIONS CONTROLS FOR FREEZER COMPARTMENT To lower the temperature in the freezer, turn the knob counter-clockwise and set to a higher number. To raise the temperature in the freezer, turn the knob clockwise and set to a smaller number. When the freezer compartment is not cold enough in winter, adjust the control for the freezer to High ( Knob is for quick freezing in the freezer compartment. -
Page 18: Refreshment Center (Optional)
OPERATIONS REFRESHMENT CENTER (OPTIONAL) 1. Tilting: Grasp the front pocket and slightly lift it up Then pull it forward to tilt the transparent door bin. Tilt 2. Closing: Then place the door bin in its original Click position until you hear a "click" DEFROSTING Defrosting takes place automatically. -
Page 19: Suggestions On Food Storage
SUGGESTIONS ON FOOD STORAGE STORING FOOD Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important factor in maintaining its freshness and flavor. Do not store food which goes bad easily at low temperatures, such as bananas, pineapples, and melons. -
Page 20: Cleaning
CLEANING It is important that your refrigerator be kept clean INiR PARTS - Wash compartment shelves, to prevent undesirable odors. Spilled food should door racks, storage trays and magnetic door be wipe up immediately, since it may acidify and seals etc. Use a lukewarm solution of mild stain plastic surfaces if allowed to settle. -
Page 21: General Information
GENERAL INFORMATION VACATION TIME ANTI-CONDENSATION PIPE During average length vacations, you will probably The outside wall of the refrigerator cabinet may find it best to leave the refrigerator in operation. sometimes get warm, Place freezable items in freezer for longer life. especially just after When you plan to be away for an extended period, installation. -
Page 22: Important Warnings
IMPORTANT WARNINGS DO NOT USE AN EXTENSION CORD ABOUT GROUNDING (EARTHING) If possible, connect the refrigerator to its own In the event of an electric short circuit, grounding individual electrical outlet to prevent it and other (earthing) reduces the risk of electric shock by appliances or household lights from causing an providing an escape wire for the electric current. -
Page 23: Before Calling For Service
BEFORE CALLING FOR SERVICE SERVICE CALLS CAN OFTEN BE AVOIDED! IF YOU FEEL YOUR REFRIGERATOR IS NOT OPERATING PROPERLY, CHECK THESE POSSIBLE CAUSES FIRST : PROBLEM POSSIBLE CAUSES REFRIGERATOR DOES Has a house fuse blown or circuit breaker tripped? NOT OPERATE Has the power cord plug been removed or loosened from the electrical wall outlet? Temperature control not set on proper position. -
Page 24: Earth/ Grounding Construction (Optional)
EARTH (GROUNDING) CONSTRUCTION (OPTIONAL) It is recommended to install the earth to prevent electric shock in case of electricity leakage. How to connect the earth wire: • Connect the earth wire's metal ring end to the earth screw on the back of the refrigerator. •...
