Sanyo PLC-XF41 Specifications

7 7 0 0 A N S I L U M E N S
PLC-XF41
XGA Digital Multimedia Projector
INCREDIBLY BRIGHT 7700 ANSI LUMENS
Utilizing four high-output 200 watt UHP lamps as its light
source, the PLC-XF41 delivers an incredible 7700 ANSI
lumens of brightness.
OUTSTANDING CONTRAST RATIO – 800:1
Through its new high-contrast optical system, the PLC-XF41 is
able to achieve an outstanding contrast ratio of 800:1. A 10-bit
digital gamma correction circuit is employed to effectively
suppress overwhelming whites in bright images and excessive
blacks in dark images.
SANYO's NEW PROGRESSIVE IC
A newly developed progressive integrated circuit provides
highly improved playback of moving images. 1080 interlaced
signals are converted into progressive signals while 2-3
pulldown doubles the resolution of images from DVD playback.
NETWORK CONTROL/ADMINISTRATION
An optional network board allows for simple control and
management of the projector via a CAT5 network connection.
The network board, which can memorize and store up to 55 PC
modes, can also be used in parallel with RS-232 controllers.
REAL COLOR MANAGER
The Real Color Manager System provides white balance
adjustment and gamma correction from a PC using the
included image adjustment software by simply comparing the
on-screen image to a printed color chart.
NEW ONE-TOUCH LENS REPLACEMENT
Attaching the included One-Touch lens mount adapters to your
projector and lenses makes installation and removal of our
optional lenses quick and easy.
PRESENTATION TECHNOLOGIES
PLC-XF41
Multi-Versatile
Interface
(POA-MD11DVI)
( POA-MD16VD1)
(POA-MD03VD2A)
(POA-MD04VGA)
Type Short Fixed Short Zoom
Part No. LNS-W01 LNS-W02
Zoom No Yes (power)
Throw Ratio 1.2:1 1.35 – 1.8:1
F Stop 2.5 2.5 – 2.9
Length 9.4"
Weight 12.8 lbs.
Issued 3/03
T R U E X G A
21605 Plummer Street
Chatsworth, CA 91311
Ph: 888-337-1215 (toll-free)
Fax 818.717.2719
www.sanyolcd.com
L e n s S p e c i f i c a t i o n s
On-Axis Standard
Short Fixed Zoom 1
LNS-W03 LNS-S01
No Yes (power)
0.8:1 1.8 – 2.9:1
2.6 2.6 – 3.5
8.34" 9.25"
5.5 lbs. 6.6 lbs 3.7 lbs.
D I G I T A L M U L T I M E D I A P R O J E C T O R
S p e c i f i c a t i o n s
Resolution
Brightness
Uniformity
LCD Panel System
Number of Pixels
Contrast Ratio
Projection Lens
Image Size
Aspect Ratio
Throw Distance
Zoom/Focus
Throw Ratio
Zoom Ratio
Power Lens Shift
Digital Keystone Correction
Projection Lamp
Scanning Frequency
Dot Clock
Color System
Computer Compatibility
Voltage
BTU Rating
dB Rating
Power Consumption
Dimensions (WxHxD)
Net Weight
User Maintenance
Detachable Input Panels
POA-MD11DVI
POA-MD16VD1
POA-MD03VD2A
POA-MD04VGA
Fixed Input/Output Panel
Included Accessories
Optional Accessories
Warranty
Because its products are subject to continuous improvement, SANYO reserves the right to
modify product design and specifications without notice and without incurring any obligations.
Standard Standard
Zoom 2 Zoom 3
LNS-S02 LNS-S03
Yes (power) Yes (power)
2.0 – 2.6:1 2.6 – 3.5:1
2.0 – 2.3 1.7 – 2.6
7.0" 8.2" 13.8"
4.2 lbs. 8.2 lbs.
XGA (1024 x 768)
7700 ANSI Lumens (4-Lamp mode)
3850 ANSI Lumens (2-Lamp mode)
90% (corner to corner)
1.8" TFT polysilicon type x 3
2,359,296 (786,432 x 3)
800:1
Lens Sold Separately
Dependent on Lens
4:3
Dependent on Lens
Dependent on Lens
Dependent on Lens
Dependent on Lens
Up/Down Ratio 10:0 – 0:10 or 8:1 – 1:8
Left/Right Ratio 3:2 – 2:3
+ 40° / - 20°
200W UHP x 4
H Sync: 15-120kHz, V Sync: 50-120Hz
230MHz
PAL/PAL-M/PAL-N/SECAM/NTSC/NTSC4.43
UXGA, SXGA, XGA, SVGA, VGA, MAC
100-240V AC; 50/60/Hz (auto sense/select)
3924
46.0
1150W
22.9"x9.9"x30.8"
81.6 lbs.
Clean air filters, replace lamp assembly
Digital Visual Interface (DVI-I) • Left & Right Audio (RCA x
2) • Control (Min DIN 8-pin)
RGB & Component (5-BNC) • Left & Right Audio (RCA x 2)
• Control (Min DIN 8-pin)
Composite & Y/C (2-BNC) • S-Video
• Left & Right Audio (RCA x 2)
VGA (D-Sub 15) • Left & Right Audio (RCA x 2)
• Control (Min DIN 8-pin)
Serial in/out (D-Sub 9 x 2) • Audio out (RCA x 2)
• USB (type B) • Wired RC jack (Stereo mini);
Wired/Wireless I/R Remote Control w/Mouse Pad and
Laser Pointer • 2 "AA" Batteries • AC power cord
• VGA and DVI Cables • Wired remote cable
• PS/2, Serial, MAC Control cables • Light Block Sheets •
Dust cover • MAC/VGA and DVI/VGA Adapters • Lens
Mount Adapters (POA-LNA02 & POA-LNA01) • Real Color
Manager CD-ROM • Owner's manual
POA-MD08HD - HD-SDI Input Panel
POA-MD09VD3 - Faroudja™ Input Panel
POA-MD13NET - Network Board
POA-MD15SDI - SD-SDI Board
POA-LNA02 - Lens Mount Adapter
(for LNS-W02, W02KS, M01, S01 lenses)
POA-LNA01 - Lens Mount Adapter (for all other lenses)
PLCCSE14 - Hard Shipping Case
6102924831 - Replacement Lamp
Three years parts and labor; 90 days original lamp;
Quick Repair Program under warranty
Semi-Long
Zoom Long Fixed
LNS-M01 LNS-T01
Yes (power) NO
3.5 – 4.6:1 7.0:1
2.0 - 2.6 2.0
6.9" 8.6"
4.2 lbs. 8.4 lbs.
Long Zoom
LNS-T02
Yes (power)
4.6 – 6.0:1
2.0 – 2.9
9.6"
6.8 lbs.
© 2003 SANYO
