Safety Warnings CLASS 1 LASER PRODUCT KLASSE 1 LASER PRODUKT LUOKAN 1 LASER LAITE KLASS 1 LASER APPARAT PRODUCTO LASER CLASE 1 CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE REAR COVER. NO USER SERVICEABLE PARTS INSIDE.
Technical Specifications ...23 Press YSTEM Symbols Push Important Thank you for buying this SAMSUNG micro-component system. Please take time to read these instructions. They will allow you to operate your system with ease and take full advantage of its features. Note...
Front Panel View TAPE PLAY STANDBY/ON MP3-CD/CD PLAY/PAUSE RECORD/PAUSE TUNER / BAND SKIP OR SEARCH REWIND HEADPHONE JACK STOP/TUNING MODE SKIP OR SEARCH FORWARD PUSH OPEN (CD DOOR OPEN /CLOSE) TAPE SPEED CD OR TAPE REPEAT A POWER SOUND VOLUME CONTROL EQ / SUPER BASS PUSH EJECT (CASSETTE DOOR OPEN/CLOSE)
Remote Control PROGRAM / SET STANDBY/ON TUNER/BAND SLEEP POWER SOUND CD SKIP OR SEARCH CD STOP CD REPEAT 10. VOLUME CONTROL 11. TAPE REWIND 12. TAPE STOP 13. TAPE PLAY MUTE TUNER TIMER/CLOCK TIMER ON/OFF BAND PROGRAM/SET REP. A B MO/ST SLEEP EQ/S.BASS...
Where to Install Your Micro-Component System To take full advantage of your new micro-component system, fol- low these installation instructions before connecting the unit. Install the system on a flat, stable surface. Never place this unit on carpeting. Never place this unit in an outdoor area. Maintain an open space of approximately 6 inches (15 cm) on the sides and rear of the system, for ventilation purposes.
Connecting to an External Source The auxiliary input can be used to take advantage of the sound quality of your micro-component system when listening to other sources. Examples: A television A video disc player A Hi-Fi stereo video cassette recorder To connect to the external source, the source must have an audio output.
Connecting the AM (MW)/LW Aerial The AM aerial (for long and medium waves) can be: Placed on a stable surface Fixed to the wall (you must first remove the base) The AM aerial connector terminals are located on the rear of the system and are marked AM . To avoid noise interference, check that the loudspeaker wires do not run close to the aerial wires.
Setting the Clock our system is equipped with a clock which allows you to turn your system on and off automatically. You should set the clock: When you first purchase the micro-component system After a power failure After unplugging the unit For each step, you have a few seconds to set the required options.
Regarding the playback of CD-R/RW In the case of an original CD-R(Recordable) recorded in audio CD format, CD-RW(Rewitable) and editing by the user, playback is processed on the respective completed status. (The player may not be played back according to the characteristics of the CD or recorded status.) The CD-RW is comparably less reflexive than CD which causes more time delay to read.
What is MP3? MP3 means MPEG1 Layer 3, the global standard for audio signal compression technology. It uses digital compression technology to compress original sound data by up to 12 times without sound quality degradation. File Compatibility The unit will playback files created in MP3 format (Mpeg1.Layer3) with * .mp3 as their extension.
Repeating One or All Tracks on the Compact Discs You can repeat indefinitely: A specific track on a compact disc. All tracks on the compact disc selected. To repeat... Press Repeat on the Front Panel one or more times until... REPEAT 1 is displayed The current track indefinitely All songs...
Checking and Changing Programmed Tracks You can check and change your selection of tracks at any time. You must have selected at least one track. Press STOP ( ) once if you have started listening to the selection. Press PROGRAM / SET. Each time you press Program/Set, the next selection is displayed.
Searching for and Storing the Radio Stations(continued) If you do not want to store the radio station found, revert to Step 4 and search for another station. Otherwise: a Press PROGRAM/SET Result: The program number is displayed for a few seconds. b Press TUNING to assign a program number between 1 and 15.
About RDS broadcasting This unit has the RDS (Radio Data System) function, which enables for the various information such as broadcasting station, radio text, time and 30 types of programs (News, Rock, Classic, etc.) to be received from the FM RDS station together with normal radio signal.
PTY(Program Type) indication and PTY-SEARCH function The PTY information is composed of an identification symbol, which helps the FM radio to recognize the program type of each FM station. The below 30 PTY information is shown on the display by pressing the Pty button.
Listening to a Cassette Switch the system on by pressing Standby/On ( Select the TAPE function by pressing TAPE on the front panel. Open the cassette deck by pushing on the corner of the cover marked PUSH EJECT until you hear a click and then release it. Insert the pre-recorded cassette with the open edge of the tape facing downwards.
Timer Function The timer enables you to switch the system on or off at specific times. Example: You wish to wake up to music every morning. If you no longer want the system to be switched on or off automatically, you must cancel the timer. Before setting the timer, check that the current time is correct.
Power sound function This machine is equipped with the function of POWER SOUND, which amplifies bass treble output to twice as much for powerful surround-sound. Press the POWER SOUND button on the front panel. Result: P.SOUND is displayed for a few seconds. A more powerful resonant sound is diffused.
Safety Precautions The following diagrams illustrate the precautions to be taken when using or moving your micro-component system. Ambient operating conditions: Do not expose the unit to direct sun Ambient temperature 5°C-35°C radiation or other heat sources. Humidity 10-75% This could lead to overheating and malfunction of the unit.
The model and serial numbers, normally printed on the rear of the system Your warranty details A clear description of the problem Then contact your local dealer or SAMSUNG after-sales service. Problem Checks/Explanation • The main lead is not correctly plugged into a wall socket or the wall socket is not switched on.
Technical Specifications SAMSUNG strives to improve its products at all times. Both the design specifications and these user instructions are thus subject to change without notice. RADIO Usable sensitivity AM (MW) Signal/noise ratio Usable sensitivity Total harmonic distortion Signal/noise ratio...
Page 24
Contact SAMSUNG WORLD WIDE ¤ Region Country Customer Care Center Web Site AH68-01830B...
