Cooper Lighting Wall Bracket Specification Sheet

D I M E N S I O N S (2)
Wall Bracket Series
Wall Cloud Series
(4)
O R D E R I N G I N F O R M AT I O N
Catalog
Number (1, 3, 5)
(WITH WHITE ENDS / 1 LIGHT)
6212
6313
6414
(WITH WHITE ENDS / 2 LIGHT)
6222
6424
(WALL CLOUD)
6232
6434
6434E (3)
6434-REB1
(1)
NOTES: For complete product data, reference the Fluorescent Specification binder.
number means Electronic Ballast that operates T12 lamps.
Ballast (EB81) available on a "made to order" basis.
COOPER LIGHTING - METALUX
Description
1 lamp 24", 20W T12
1 lamp 36", 30W T12
1 lamp 48", 40W T12
2 lamp 24", 20W T12
2 lamp 48", 40W T12
2 lamp 24", 20W T12
2 lamp 48", 40W T12
2 lamp 48" with LE3, 40W T12
2 lamp 48" with LE3, 32W T8
(2)
Specifications & Dimensions subject to change without notice.
(4)
Consult your Cooper Lighting Representative for availability and ordering.
D E S C R I P T I O N
The Metalux Residential Wall
Bracket Series is an energy
efficient luminaire designed for
versatility in application and
performance. The series feature
an opal white acrylic refractor
that produces a 180° uniform
light distribution pattern. The
versatile Wall Bracket Series
combines quality and economy
in a multi-purpose wall bracket.
The luminaire is perfect for
illuminating corridors, stairwells,
lavatories, dressing rooms,
basements, utility/task and area
lighting.
The Wall Cloud Series
incorporates a vacuum formed
soft white acrylic lens for more
residential appeal.
Shipping
Wt.
7 lbs. (3.2kg)
9 lbs. (4.1kg)
12 lbs. (5.4kg)
7 lbs. (3.2kg)
12 lbs. (5.4kg)
8 lbs. (3.6kg)
13 lbs. (5.9kg)
13 lbs. (5.9kg)
13 lbs. (5.9kg)
(3)
"E" in catalog
(5)
Commercial Grade Electronic
®
W A L L B R A C K E T
W A L L C L O U D
WALL BRACKET
WALL CLOUD
SERIES
2 ' , 3 ' o r 4 '
1 o r 2 L a m p s
R E S I D E N T I A L
A L L P U R P O S E
W A L L B R A C K E T S
• Uses one or two
fluorescent lamps
(not included)
• Contemporary styling
• Die formed steel housing
• Baked white enamel finish
• Extruded smooth opal
white acrylic refractor
• 180° uniform light
distribution
• Decorative opaque injection
molded white end plates
• Easy wiring access
• Vertical wall or horizontal
ceiling mounting
application
• Suitable for damp locations
• UL/CUL Listed
COOPER LIGHTING
