- Page 1 COLOUR TELEVISION Owner’s Instructions Before operating the unit, please read this manual thoroughly, and retain it for future reference. ON-SCREEN MENUS PICTURE IN PICTURE DNIe Jr (Digital Natural Image engine Junior) TELETEXT Register your product at www.samsung.com/global/register...
-
Page 3: Table Of Contents
◆ C ONNECTING AND REPARING Control Panels ... ■ Connection Panels ... ■ Infrared Remote Control (All Functions Except Teletext) ... ■ Infrared Remote Control (Teletext Functions) ... ■ Inserting the Batteries in the Remote Control... ■ Connecting to an Aerial or Cable Television Network ... ■... - Page 4 Contents ◆ U SING THE ELETEXT EATURE Teletext Feature ... ■ Displaying the Teletext Information ... ■ Selecting a Page by Number... ■ Using FLOF to Select a Page... ■ Storing Teletext Pages ... ■ ◆ A DDITIONAL NFORMATION ON Connecting to the AV-1 or 2 Input/Outputs...
-
Page 5: Control Panels
If the remote control no longer works or you have lost it, you can use controls on the panel of the TV to: ◆ Switch on the TV when it is in Standby mode and select channels ( ◆ Access the menu ( MENU ). -
Page 6: Connection Panels
Refer to the documentation supplied with your equipment for detailed connection instructions and associated safety precautions. English - 6 ➢ This figure shows the Standard Connector-jack panel. The actual configuration on your TV may be different, depending on the model. Side of TV... - Page 7 Available format for Component Inputs : 480i ➢ When using the mono equipment such as camcorders, video disc players and some video game device, connect to the “AUDIO-L” input connector. Rear of TV ˇ COMPONENT (DVD) VIDEO (Y/P ) and AUDIO (L/R) inputs for Component.
-
Page 8: Infrared Remote Control (All Functions Except Teletext)
RESPECTIVELY SOUND MENU DISPLAY TURBO SOUND ➣ Operation of remote control may be affected by bright artificial light near to the TV set. English - 8 ➢ The actual configuration on your TV may be different, depending on the model. -
Page 9: Infrared Remote Control (Teletext Functions)
TELETEXT PREVIOUS PAGE TELETEXT REVEAL - PIP FUNCTIONS (OPTION); - PIP ON/OFF (PIP) - STILL - INTERCHANGE THE MAIN AND SUB PICTURE (SWAP) - SOURCE SELECTION (TV/VIDEO) - SIZE SELECTION (SIZE) - LOCATION SELECTION (POSITION) - CHANNEL SELECTION (P English - 9... -
Page 10: Inserting The Batteries In The Remote Control
) display (Option) The “ ”(Signal Strength) symbol is displayed by pressing the “INFO ( )” button. This symbol displays signal strength for your watching TV channel. The more signal bar is the better TV gets sensitivity on current channel. -
Page 11: Switching Your Television On And Off
Switching Your Television On and Off The mains lead is attached to the rear of your television. Plug the mains lead into an appropriate socket. ➢ The main voltage is indicated on the rear of the television and the frequency is 50 or 60Hz. Press the “... -
Page 12: Becoming Familiar With The Remote Control
Press this button, and the “--” or “---” symbol is displayed. Enter the two or three-digit channel number. Press the PRE-CH button. The TV will switch to the last channel viewed. To quickly switch between two channels that are far apart, tune to one channel, then use the number button to select second channel. -
Page 13: Plug & Play Feature
The message Check antenna input. is displayed. ➢ If any language is not selected on the Language menu, the Language menu will disappear about 30 seconds later. Make sure that the antenna is connected to the TV. Press the ENTER ( ) button. Result: The Auto Store menu is displayed with Area selected. -
Page 14: Viewing The Demonstration
Viewing the Demonstration Setup √ √ Plug & Play Language : English √ √ Time √ √ Child Lock √ √ Blue screen : Off √ √ Melody : On √ √ Demonstration Move Enter Return Choosing Your Language Setup √... -
Page 15: Channels
Storing Channels Automatically You can scan for the frequency ranges available to you (and availability depends on your country). Automatically allocated programme numbers may not correspond to actual or desired programme numbers. However you can sort numbers manually and clear any channels you do not wish to watch. Press the MENU ( ) button. -
Page 16: Storing Channels Manually
Storing Channels Manually Channel √ √ Auto Store √ √ Manual Store √ √ Add/Delete √ √ Sort Move Enter Return Manual Store Programme : P 3 √ √ Color System : AUTO √ √ Sound System : BG Search : 46MHz Channel : C 1... - Page 17 Storing Channels Manually If you do not know the channel numbers, select Search by pressing the ▲ or ▼ button. Press the œ or √ button to start the search. Result: The tuner scans the frequency range until the first channel or the channel that you selected is received on your screen.
-
Page 18: Skipping Unwanted Channels
Skipping Unwanted Channels Channel √ √ Auto Store √ √ Manual Store √ √ Add/Delete √ √ Sort Move Enter Return Add/Delete P 1 : Added P 2 : Added P 3 : Added P 4 : Added P 5 : Added Move Enter Return... -
Page 19: Sorting The Stored Channels
Sorting the Stored Channels This operation allows you to change the programme numbers of stored channels. This operation may be necessary after using auto store. You can delete the channels you do not want to keep. Press the MENU ( ) button. -
Page 20: Changing The Picture Standard
Changing the Picture Standard Picture √ √ Mode : Dynamic √ √ Custom √ √ Color Tone : Normal √ √ Size : Normal √ √ Digital NR : Off √ √ DNIe Jr : On √ √ Move Enter Return Picture √... -
Page 21: Adjusting The Picture Settings
Adjusting the Picture Settings Your television has several settings which allow you to control picture quality. Press the MENU ( ) button. Result: The main menu is displayed. Press the ▲ or ▼ button to select Picture. Result: The options available in the Picture group are displayed. -
Page 22: Selecting The Picture Size
Selecting the Picture Size Picture √ √ Mode : Dynamic √ √ Custom √ √ Color Tone : Normal √ √ Size : Normal √ √ Digital NR : Off √ √ DNIe Jr : On √ √ Move Enter Return Picture √... -
Page 23: Extra Picture Settings
Extra Picture Settings ◆ Digital NR If the signal received by your television is weak, you can activate this feature to reduce any static and ghosting that may appear on the screen. Press the MENU ( ) button. Result: The main menu is displayed. Press the ▲... -
Page 24: Setting The Blue Screen
Setting the Blue Screen Setup √ √ Plug & Play Language : English √ √ Time √ √ Child Lock √ √ Blue screen : Off √ √ Melody : On √ √ Demonstration Move Enter Return Setup √ √ Plug &... -
Page 25: Changing The Sound Standard
Changing the Sound Standard You can select the type of special sound effect to be used when watching a given broadcast. Press the MENU ( ) button. Result: The main menu is displayed. Press the ▲ or ▼ button to select Sound. Result: The options available in the Sound group are displayed. -
Page 26: Adjusting The Sound Settings
Adjusting the Sound Settings Sound √ √ Mode : Standard √ √ Equalizer √ √ Auto Volume : Off √ √ Pseudo Stereo : Off √ √ Turbo Sound : Off Move Enter Return Equalizer Move Adjust Return English - 26 The sound settings can be adjusted to suit your personal preferences. -
Page 27: Extra Sound Settings
Extra Sound Settings ◆ Auto Volume Each broadcasting station has its own signal conditions, and so it is not easy for you to adjust the volume every time the channel is changed. This feature lets you automatically adjust the volume of the desired channel by lowering the sound output when the modulation signal is high or by raising the sound output when the modulation signal is low. -
Page 28: Selecting The Melody
Selecting the Melody Setup √ √ Plug & Play Language : English √ √ Time √ √ Child Lock √ √ Blue screen : Off √ √ Melody : On √ √ Demonstration Move Enter Return Setup √ √ Plug & Play Language : English √... -
Page 29: Selecting The Sound Mode
Selecting the Sound Mode The “DUAL I-II” button displays/controls the processing and output of the audio signal. When power is switched on, the mode is automatically preset to either “Dual-I” or “Stereo”, depending on the current transmission. Type of broadcast Regular broadcast (Standard audio) Regular +... -
Page 30: Setting And Displaying The Current Time
Setting and Displaying the Current Time Setup √ √ Plug & Play Language : English √ √ Time √ √ Child Lock √ √ Blue screen : Off √ √ Melody : On √ √ Demonstration Move Enter Return Time Clock -- : -- am Sleep Timer... -
Page 31: Setting The Sleep Timer
Setting the Sleep Timer You can set your TV to automatically turn off after a preset interval. Press the MENU ( ) button. Result: The main menu is displayed. Press the ▲ or ▼ button to select Setup. Result: The options available in the Setup group are displayed. -
Page 32: Switching The Television On And Off Automatically
3 hours after the TV was turned on by timer. This function is only available in timer “On” mode and prevents overheating or leakages, which may occur if a TV is on for too long (on holiday, for example). ) button. -
Page 33: Setting The Preferred Volume Level
Setting the Preferred Volume Level The preferred volume can be set for when the timer automatically turns on the TV. Press the MENU ( ) button. Result: The main menu is displayed. Press the ▲ or ▼ button to select Setup. -
Page 34: Activating The Child Lock
Activating the Child Lock Setup √ √ Plug & Play Language : English √ √ Time √ √ Child Lock √ √ Blue screen : Off √ √ Melody : On √ √ Demonstration Move Enter Return Child Lock √ √ Child Lock : Off Move... -
Page 35: Viewing An External Signal Source
➢ When you connect equipment to the TV, you can choose between the following sets of jacks : AV1, AV2, S-Video or Component on the TV’s rear panel, and AV2 or S-Video on the TV’s side panel. ➢ S-Video and Component signal sources are depending on the model. -
Page 36: Viewing The Picture In Picture (Pip)
➢ Not available in Component mode. You can display a sub picture within the main picture of TV program or external A/V devices such as VCR or DVD. In this way you can watch TV program or monitor the video input from any connected devices while watching TV or other video input. -
Page 37: Feature
œ or √ button. ➢ ◆ When the Source is set to TV, you can select the channel of sub picture. ◆ You can select the channel of the sub picture simply by pressing the ▲... -
Page 38: Teletext Feature
If you wish to display the actual broadcast at the same time as the teletext page, press the TTX/MIX ( Press the TV ( ) button to exit from the teletext display. (index) button. -
Page 39: Selecting A Page By Number
Selecting a Page by Number You can enter the page number directly by pressing the numeric buttons on the remote control. Enter the three-digit page number given in the content by pressing the corresponding numeric buttons. Result: The current page counter is incremented and the page is then displayed. -
Page 40: Using Flof To Select A Page
Using FLOF to Select a Page The various topics included in the teletext pages are color-coded, and can be selected by pressing the colored buttons on the remote control. Storing Teletext Pages You can store up to four teletext pages to display them later at leisure. -
Page 41: Connecting To The Av-1 Or 2 Input/Outputs
Connecting to the AV-1 or 2 Input/Outputs ➢ These figures show typical connector-jack panels. The actual configuration on your TV may be different, depending on your model. ➢ AV-1 is used for equipment with an RGB output, such as video game devices and video disc players or a VCR. -
Page 42: Connecting To The Dvd Input
➢ The RCA (VIDEO and AUDIO-L+R) connectors are used for equipment, such as camcorders, video disc players, and some video game devices. Side of the TV Connecting to the Audio Output ➢ The “MONITOR OUT” (L-AUDIO-R) connectors are used for equipment, such as an audio system (to take full advantage of the Surround sound effect). -
Page 43: Viewing Pictures From External Sources
The input sources are displayed in the following order: ◆ AV1 S-VIDEO ➢ Depending on the source selected, the pictures may appear automatically. ➢ To watch television programmes again, press the TV button and select the number of the channel required. button Component English - 43... -
Page 44: Automatic Degaussing To Remove Colour Patches
If your television will be left unattended, press the “ ” (On/Off) button to turn your television off. Troubleshooting: Before contacting Samsung after-sales service, perform the following simple checks. If you cannot solve the problem using the instructions below, note the model and serial number of the television and contact your local dealer. - Page 45 Memo English - 45...
- Page 46 Memo English - 46...
- Page 47 Memo English - 47...
- Page 48 - AFTER SALES SERVICE - Do not hesitate to contact your retailer or service agent if a change in the performance of your product indicates that a faulty condition may be present. ELECTRONICS AA68-03701A-00...
