D E S C R I P T I O N
The Fail-Safe VRMC, VRM and
2VRM Series fluorescent
luminaires combine a low
profile, surface modular design
with the latest in energy-
efficient technology. Their
Energy Saving Ballast
complies with Federal Energy
Efficiency Standards while a
dihedral recessed top allows
for cooler operation. Other
features include a die-formed
housing, surface or stem
B
B
mounting (single or
continuous row), full seam-
welded corners and a broad
selection of attractive door
frames. U.L. listed and C.S.A.
certified.
Ballast Type
Options
(add as suffix)
LE3=
Energy Saving
GL=Internal Single
Ballast
Element Fusing
LEOC8= Energy Saving
GM=Dual Element
Ballast
Fusing
(T-8 Lamp Only)
EL4=Emergency Lighting
EB_ _= Generic Electronic
self-contained
Ballast
SMB=Side Mounted
No. of Ballasts
Ballast For Stem
1 or 2
Applications .
Lamp Size
(Recommended For 4
2=T12
Point Suspension)
8=T8
RIF1=Radio Interference
5=T5 Biax
Suppressor
EKO=End Plate with 7/8"
(For specific electronic
KO (Required for
ballast specify brand and
Continuous Row
catalog number)
Mounting)
RLS=Rotor-Lock Socket
(T8 Lamps Only)
6S=Six TORX-head
Screws(3 per side)
SC=Safety Chain
FAIL-SAFE
®
VRMC
VRM
2VRM
1 ' x 4 ' , 2 ' x 2 ' , 2 ' x 4 '
2 , 3 , O R 4 L A M P S
VA N D A L R E S I S TA N T
L U M I N A I R E
• Housing is die-formed code
gauge prime CRS. Smooth
sides permit flush joints
when continuous row
mounting. Die-formed
captive lampholder
brackets
• Ballasts are CBM/ETL Class
"P" and positively secured
by mounting by mounting
bolts. Pressure lock
lampholders
• Electrostatically applied
baked white polyester
powder enamel finish
• Positive cam action steel
latches with baked white
enamel finish
• Die formed, heavy gauge,
flat steel door with
reinforced mitered corners
and baked white enamel
finish. Positive light seals.
Frame and lens are secured
to housing with 4 or 6
stainless steel TORX
®
screws
