SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
SERVICE MANUAL
Wireless type
Models
MSZ-FA25VA -
MSZ-FA35VA -
Indication of model name
MSZ-FA25VA -
MSZ-FA35VA -
NOTE:
This service manual describes technical data of the indoor units.
•As for outdoor units MUZ-FA25VA-
MUZ-FA35VAH-
E1
•As for outdoor units MXZ-3A54VA-
refer to service manual OB377.
All manuals and user guides at all-guides.com
(WH)
E1
(WH)
E1
E1
E1
, MUZ-FA35VA-
E1
, refer to service manual OB372.
, MXZ-4A71VA-
E1
CONTENTS
1. TECHNICAL CHANGES ····································2
2. PART NAMES AND FUNCTIONS······················3
3. SPECIFICATION·················································5
4. NOISE CRITERIA CURVES ·······························6
5. OUTLINES AND DIMENSIONS ·························7
6. WIRING DIAGRAM ············································8
7. REFRIGERANT SYSTEM DIAGRAM ················8
8. SERVICE FUNCTIONS ······································9
9. TROUBLESHOOTING······································11
10. DISASSEMBLY INSTRUCTIONS·····················31
11. PARTS LIST······················································35
12. OPTIONAL PARTS···········································38
, MUZ-FA25VAH-
and
E1
E1
and MXZ-4A80VA-
,
E1
E1
No. OB371
Advertisement
Table of Contents
Related Manuals for Mitsubishi Electric MSZ-FA25VA-E1 WH
Summary of Contents for Mitsubishi Electric MSZ-FA25VA-E1 WH
-
Page 1: Table Of Contents
All manuals and user guides at all-guides.com SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS No. OB371 SERVICE MANUAL Wireless type Models MSZ-FA25VA - (WH) MSZ-FA35VA - (WH) CONTENTS 1. TECHNICAL CHANGES ····································2 2. PART NAMES AND FUNCTIONS······················3 3. SPECIFICATION·················································5 4. NOISE CRITERIA CURVES ·······························6 5. -
