Summary of Contents for Rollei MiniDigi
- Page 1 Owner's Manual...
-
Page 2: Table Of Contents
Table of Contents Thank you for purchasing the new Rolleiflex MiniDigi AF 5.0 digital camera, a miniature replica of the famed Rolleiflex 2.8F twin-lens-reflex camera. Specifications Frame counter ------------------- For Your Safety ----------------- Identification of parts ---------- Preparation Replaying images... -
Page 3: For Your Safety
For Your Safety For the safe and correct use of your camera, please read the following notes carefully. Our warranty may be void for damage caused by willful disregard of the instructions. The instruction alerts are to protect the user of the camera and people around him/her from possible damages and injuries. -
Page 4: Identification Of Parts
Identification of parts Viewfinder hood Strap bracket Power on/off switch Crank handle Right side view Top View TFT monitor Viewfinder cover Sports finder cover Viewing lens (dummy) Taking lens Shutter release button Mode shift button Front view... -
Page 5: Bottom Cover
Sports finder eyepiece* Image delete button Left button (reverse) Right button (forward) *The sports finder is for replicating original Rolleiflex 2.8F design, and the view through it does not exactly conform to the image the lens captures. Use of the monitor is recommended for practical shooting. -
Page 6: Inserting Battery
Preparation Bottom cover lock bar Open Replace Lithium battery Tape to remove the battery Opening Bottom cover Remove the cover by sliding it to the direction of Arrow ②, while pushing the Bottom cover lock bar to the direction of Arrow ①. Replacing Bottom cover Set the cover as shown and slide it toward the camera... -
Page 7: Attaching Neck Straps
Preparation Strap bracket Power switch button Attaching Neck straps ① Put the string attached to the strap through a Strap bracket and let the strap go through the loop as shown. ② After attaching a strap to both brackets (right and left) put the straps together and adjust length as shown. -
Page 8: Shooting
Shooting Power switch Shutter release button Winding Crank handle Press Power switch to turn power on. An image will appear on Monitor display in 1-2sec. Unfold Crank handle as shown (Arrow ① ) and turn it 360° clockwise (Arrow ② ) . *Turn the handle before shooting each picture. -
Page 9: Record Mode
Frame counter Before shooting After shooting Maximum frame number allowing predicted capturing Playback image number Shot number Record mode A frame counter is displayed in the right upper corner of the display when the camera is in a shooting mode. The upper number shows the total shot number and the lower number indicates the remaining number... -
Page 10: Deleting Images
Deleting images Mode shift button Right button (forward) Left button (reverse) Image delete button Deleting selected image Press Mode shift button to set the camera to Playback mode. Select the image to be deleted with Left and Right buttons. Press Image delete button once and DELETE ONE? sign appears in the center of the monitor accompanied by... -
Page 11: Auto Power-Off
Selecting frequency (for fluorescent lamp) Left button (reverse) Auto power-off The camera, when left without operation for longer than 60sec, automatically activates Auto power-off circuitry to turn power off. Press Power switch again to resume operation. While the camera is in Record mode, press Left button to select frequency for shooting under fluorescent lamp(s). -
Page 12: Holding The Camera
* Battery life will be approx. 2 hours in continuous use. This may become shorter under low temperature condition. *Images taken with Rolleiflex MiniDigi AF5.0 may not be replayed on mobile phones. * In photographic situations where contrast is extremely high, for example...
