Roland PDX-8 Settings Manual

for PDX-8 Owners
Trigger Settings For Percussion Sound Module
Set the trigger type and trigger parameters for the percussion sound module you are using.
Be sure to make these settings to ensure that the PDX-8 performs properly.
Below you will find the settings recommended for different percussion sound modules.
For instructions on setting the trigger parameters, refer to the Owner's Manual for your percussion
sound module.
* Leave the initial Cross Stick Cancel settings for each module unchanged.
About the Head Tension
Tighten the head so that the tension is rather firm.
Looseness in the head tension may result in problems such as failure of the PDX-8's rim shots to
sound or double triggering.
About Rim Sens (*1)
If any of the following problems occurs, adjust Rim Sens to a value in the range indicated in the
column for the corresponding percussion sound module.
• If the rim sound plays even when you strike the head, lower the Rim Sens value.
• If no rim sound plays even when the rim is struck forcefully, increase the Rim Sens value.
* When using the TD-12 and TD-20, adjust the "RimShot Adjust."
TD-3 (Percussion Sound Module)
IMPORTANT: Only the snare input is capable of
producing a rim shot.
Trigger Type
( )
Scan Time ( )
Mask Time ( )
Rim Sensitivity
(
Rim Gain ( )
TD-6V (Percussion Sound Module)
IMPORTANT: Only the 2(snare) input is capable of
producing a rim shot.
TrigTyp
Mask Time
Rim Sens
PDX-8 Trigger Parameter
80r
1.0
8
10
)
1.1
PD-80R
8ms
11
Copyright © 2006 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any
form without the written permission of ROLAND CORPORATION.
TD-12/TD-20
(Percussion Sound Module)
IMPORTANT: Only the inputs listed below are
capable of producing a rim shot.
TD-12: 2 (SNARE), 3–5 (TOM1–3), 11–12 (AUX1–2)
TD-20: 2 (SNARE), 3–6 (TOM1–4), 12–15 (AUX1–4)
Trig Type
(*1)
Sensitivity
RimShot Adjust
Setting when connecting with trigger input 2(SNARE)
The PDX-8 does not support the TD-12's and TD-20's
positional sensing. Set the TD-12/TD-20 so that strike
position sensing is not activated. Set Snare CC to
"OFF."
(press [SETUP], then [F1 (MIDI)], then [F3 (CTRL)])
(*1)
PD80R or PD85
7
1.8 (*1)
1PS
