Summary of Contents for Lenovo THinkVision T75
- Page 1 T75 Smart Large Format Display User Guide...
- Page 2 All rights reserved. LENOVO products, data, computer software, and services have been developed exclusively at private expense and are sold to governmental entities as commercial items as defined by 47 C.F.R. 2.101 with limited and restricted rights to use, reproduction and disclosure.
- Page 3 Notation ............................. 2-3 All Files ............................2-4 All Application ..........................2-4 System Settings ........................2-6 External Signal Source ......................2-10 Screen Off ..........................2-11 Chapter 3 Reference Information ................3-1 Resolution Specification ......................3-1 Common Faults and Solutions ....................3-2 © Copyright Lenovo 2022...
- Page 4 Reminder regarding the “Regulation on the Administration of the Recovery and Disposal of Waste Electrical and Electronic Products” .................D-1 Power line ..........................D-1 Recycling Information ........................D-1 Collecting And Recycling A Disused Lenovo Computer Or Monitor ..........D-2 Disposing Of Lenovo Computer Components ................D-2 Trademarks ..........................D-3 HDMI Trademarks ........................D-3 Signage Display ........................D-3...
- Page 5 Chapter 1 Get Started with Your Smart Large Format Display (LFD) This User’s Guide contains detailed information on the ThinkVision® T75 Smart Large Format Display (LFD). In The Box The product package should include the following items: z Smart Large Format Display z Wall hanger -2 vertical beams z Wall hanger -1 beam z Installation Guide QSG...
- Page 6 Wall Mounting 1. Installation notes z When installing wall hanging, at least two or more professionals are required to carry out all the installation work of the machine at the same time. Users should not install themselves without authorization, so as to avoid harm caused by improper operation.
- Page 7 Appearance 75 inch Infrared touch screen The microphone Full physical toughened protective USB-A external camera port glass Power button WIFI module Remote receiving device/light Built-in port on computer sensing device The front interface Rear I/O panel Speaker Power outlet Infrared body sensor Power switch Get Started with Your Smart Large Format Display (LFD) 1-3...
- Page 8 The I/O panel Front I/O panel Name Touch USB When the touch USB port is combined with the front HDMI port, the PC can be operated in touch mode. When the HDMI input port is combined with the front Touch USB port to connect to the LFD, the PC can be HDMI operated in touch mode.
- Page 9 Name Functional description TF Card TF card slot port for externally expanded storage MIC In Microphone input port Optical fiber output interface. Connect audio equipment with fiber optic input, such as power amplifier, SPDIF Out stereo, speaker box Line Out It connects audio devices such as headphones and speakers.
- Page 10 The Front Button Power button Power ON Step 1: After inserting the power cord, turn on the ship AC power switch (at the back of the screen, next to the power socket) to enter the standby state, and the power indicator is red. Step 2: Press "...
- Page 11 Features and Specifications Screen Size 75″ Backlight Type Aspect Ratio 16:9 Viewing Angle 178° Resolution 3840 x 2160 Pixel Working Voltage 100 - 240 V, 50/60 Hz Stand-by Power Consumption < 0.5 W Standard Power Consumption ≤293 W Rated Current Max 4.0 A Speaker 15 W x 2...
- Page 12 The Remote Control Remote control buttons Function Power button ( ) Power on/off Signal source button ( ) Turn on/off the source list Cursor key ( Up/down/Left/right select key Confirm button (OK) Confirm the current operation Menu button ( ) The main menu is displayed or hidden Home button ( Return to the Android launcher...
- Page 13 Chapter 2 Explore Your Smart Large Format Display (LFD) This section describes the basic operation functions of the display. Home Screen Follow the boot-up wizard to enter the system interface, as shown below. Quick Access Controls On the home screen, click the icon to expand all the ICONS in the floating bar.
- Page 14 Supports preset 6 colors + universal color palette, and adjustable brightness supports whiteboard pen +Mark pen to choose two pen types: fine, medium and thick. Support small, medium and thick eraser options for partial erasing Support one- The eraser click screen clearing to clear all content gesture: support for erasing the back of the hand.
- Page 15 Hold the finger on the screen for more than 2 seconds and release it to call out the floating toolbar, which is convenient for users to use the whiteboard quickly. Hover toolbar Common tools: If no operation is performed for more than 2 seconds, the floating toolbar will be automatically hidden.
- Page 16 All Files The file management page displays local files in the current system. If an external storage device (such as a USB storage device or a removable hard disk) is connected, the file content of the storage device is also displayed.
- Page 17 Screenshots You can access the screen capture screen in any of the following ways: z Click the "Screenshot" icon of the " All Application" interface; z Click the "Screenshot" icon in the task Management sidebar; After entering the screenshot mode, the capture box can change the capture position by dragging the gesture, and the capture box will follow the gesture to the position where the screenshot is needed.
- Page 18 Lenovo Projection Click the "Lenovo Projection" icon to enter the screen projector pairing display interface. Users can use the screen projector to display according to the instructions, as shown below: System Settings Click the " " icon in the " All Application " interface to enter the setting interface, including common functions, network Settings, time and language, advanced Settings, about devices and other information.
- Page 19 Network The Network sub-menu is displayed, allowing you to set the wireless network, wired network, hotspot information, and Bluetooth functions. z Wireless network: View the MAC address of the device and enable or disable Wi-Fi. z On wired networks: View the MAC address, IP address, gateway, subnet mask, and DNS information. It can automatically obtain LAN IP or LAN IP as required.
- Page 20 Advanced Settings Enter the "Advanced Settings" sub-menu, you can choose "Hover menu Settings", "Auto On/off", "Auto Sleep and Wake up Settings", "Standby", "Low Blue light mode", "Startup channel", "OPS startup". Low Blue Light Mode Enter the low Blue light mode: Click the "Settings" button in the sidebar and select "Advanced Settings" to enter the page.
- Page 21 The product's "Low Blue light mode" is certified by TUV RHINeland for low blue light. The incidence of blue light problems affecting eye health has increased in recent years. Low blue light technology can reduce blue light levels. It is recommended to use low blue light mode to protect your eyes. No Stroboscopic: The device has no visible or invisible flicker in the range of 0-3000Hz.
- Page 22 External Signal Source Click the signal source icon " " in the floating bar of the home page, and the system pops up the external signal port tool window (display Built-in computer, Front HDMI, Front Type-C. Type-C HDMI 1, HDMI 2 , HDMI 3 , DP ,VGA ,AV ).
- Page 23 Screen Off In response to the policy of energy conservation and environmental protection, the screen function is specially added in the design of intelligent large screen. You can set the screen rest state when you only answer the voice without viewing the screen. In this case, audio or video plays normally, the screen is off, and the power indicator is steady green.
- Page 24 Chapter 3 Reference Information Resolution Specification VGA Display Mode Resolution Refresh Rate (Hz) 800×600 60 Hz 1280×720 60 Hz 1360×768 60 Hz 1600×900 60 Hz 1920×1080 60 Hz HDMI Display Mode Resolution Refresh Rate (Hz) 1280×720 60 Hz 1920×1080 30 Hz 1920×1080 60 Hz 3840×2160...
- Page 25 Common Faults and Solutions Before contacting technical support, please perform troubleshooting according to the following table. If the issue still cannot be solved, please contact your local distributor. For your safety, do not repair the product by yourself. Troubleshooting Symptom Possible Factor Solution There's nothing on...
- Page 26 General Safety Guidelines For tips to help you use your computer safety, go to: http://www.lenovo.com/safety Before installing this product, read the Safety Information. This equipment is not suitable for use in locations where children are likely to be present, avoid hurting your child when machine falling down.
- Page 27 Maintenance Important Safety Information The power cable is dedicated to the smart screen. If you want to use a different power cable, only use the power cable that matches the smart screen. To prevent the machine from being damaged, do not use any cables other than the one provided with the machine.
- Page 28 Appendix B Usage Precautions z Please do not disassemble or assemble this product by yourself in any way. Opening or removing the cover without authorization may expose you to dangerous voltage or other hazards. If you have any main- tenance matters, please contact professional maintenance personnel for handling. z If the unit is dirty, please unplug the unit and wipe it with a soft semi-dry cloth dipped in a small amount of water, do not repeatedly wipe the display to avoid scratches.
- Page 29 Appendix C. Service and Support The following information describes the technical support that is available for your product, during the warrantyperiod or throughout the life of the product. Refer to your Lenovo Statement of Limited Warranty for a fullyLenovo warranty terms explanation of...
- Page 30 If you still can't solve your problem, please contact the Customer Support Centre. For more information on contacting the Customer Support Centre, please see Appendix C, "Service and support" on page C-1. Service parts Refer to Lenovo service eSupport. Service and Support C-2...
- Page 31 Lenovo encourage owners of information technology (IT) equipment to responsibly recycle their equipment when it is no longer needed. Lenovo offers a variety of programs and services to assist equipment owne in recycling their IT products. For information on recycling Lenovo products, go to:...
- Page 32 Collecting And Recycling A Disused Lenovo Computer Or Monitor If you are a company employee and need to dispose of a Lenovo computer or monitor that is the property of the company, you must do so in accordance with the Law for Promotion of Effective Utilization of Resources.
- Page 33 All information contained in this document was obtained from specific environments and presented as an illustration. The result obtained in other operating environments may vary. Lenovo may use or distribute any of the information you supply in any way it believe appropriate without incurring any obligation to you.
