KRUPS GN492851 - 10 Speed Digital Hand Mixer Manual

DESCRIPTION

Eject button
Swivel cord
Helps keep the cord out of your way
Storage case
Clip-in storage box keeps all attachments and cord organized and tangle-free.
Digital display
D1. Speed level
D2. TURBO
D3. Count-up timer - displays how long you've been mixing
D4. PAUSE
Pause button
Holds your settings while you prepare or add ingredients.
ON | OFF
speeds plus turbo boost
Electronically controlled to spin at a precise speed no matter what the load. Press boost for momentary burst of power.
Beaters with Silicone Coating
Mix to the edges without clanging to maxmize contact with the bowl, leaving lumps nowhere to hide.
Dough hooks
Combine, mix and knead heavier batter and dough.
Balloon whisk
Maximum aeration for light ingredients and egg whites.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed including the following:

Read all instructions.
To protect against risk of electrical shock do not put motor unit in water or other liquid.
Close supervision is necessary when any appliance is used by or near children.
Unplug from outlet when not in use, before putting on or taking off parts, and before cleaning.
Avoid contacting moving parts. Keep hands, hair, clothing, as well as spatulas and other utensils away from beaters during operation to reduce the risk of injury to persons, or damage to the mixer.
Remove beaters from mixer before washing.
Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or is dropped or damaged in any manner. Return appliance to the nearest authorized service facility for examination, repair or electrical or mechanical adjustment.
The use of attachments not recommended or sold by the manufacturer may cause fire, electric shock or injury.
Do not use outdoors.
Do not let cord hang over edge of table or counter.
Do not let cord contact hot surface, including the stove.
A food mixer shall be marked with the following specific markings in addition to any other markings required by the standard:
1. Portable – Unplug before inserting or removing parts.
2. Hand supported – The marking required by (a) and (c) shall be located adjacent to the beater drives.
3. Hand supported – Do not put in water.

This appliance has been designed for household use only. In case of any commercial use, inappropriate use or failure to comply with the instructions, the manufacturer accepts no responsibility and the warranty will not apply.

Keep hands and utensils out of container to reduce the risk of injury to persons or damage to the mixer.
Never add to container while appliance is operating.
Container must be properly in place before operating appliance.

FOR HOUSEHOLD USE ONLY

SAVE THESE INSTRUCTIONS

Environment protection first!
information Your appliance contains valuable materials which can be recovered.
Leave it at a local civic waste collection point.

POLARIZATION INSTRUCTIONS
shock hazard This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.

USE

Clean the attachments before use. Rinse and dry them.
Insert your desired attachment, you will feel the beater lock into place and should not be able to pull it out without pushing the Eject button. Make sure they are fully locked in place before operating.
Note: The attachments are equipped with a color-coded collar. Those with a gray collar should be inserted into the hole with a gray ring. Note that the Whisk attachment also has a red collar and should only be inserted into the hole without the gray ring.
Plug in the hand-mixer.
Add ingredients to a properly sized mixing bowl.
Press the ON/OFF button to turn on the mixer.
Adjust speed using the speed control. Push forward to increase speed, push back to decrease speed.
You can hold in the forward or backwards position to adjust speed more quickly.

Note: The hand mixer is equipped with a slow-start to prevent splashing.
Note: To avoid overheating, the hand mixer can operate for up to 15 minutes.
1. Turbo (G) - press down on the speed control for an extra burst of power
2. Pause (E) allows you to momentarily stop. Press the button and the mixing and count-up will be paused. If desired, you can adjust speed with the speed control prior to resuming. Press the button again to start back up.
When you have finished, return the speed to position "0" or simply press either the PAUSE button or the ON/OFF button.
Unplug the hand-mixer.
Remove the attachments by pressing the ejection control (A).

RECIPES

Frosted Cinnamon Rolls

Prep Time: 45 minutes
Total Time: 2 hours 15 minutes
Serves: 15

Rolls
3 1/2 cups all-purpose flour, 1/4 cup granulated sugar, 1 teaspoon salt, 1 pkg (1/4 oz) quick rise yeast, 1/4 cup water, 3/4 cup milk, 1/4 cup butter, 1 egg

Filling
3 tablespoons butter, softened, 1/4 cup granulated sugar, 2 teaspoons cinnamon

Frosting
1 1/2 cups powdered sugar, 2 tablespoons butter, softened, 1/2 teaspoon vanilla, 2 tablespoons milk

In large mixing bowl, combine flour, 1/4 cup sugar, salt and yeast. Beat with dough hooks on Speed #2 for 1 minute or until mixed. In small microwavable bowl, combine water, milk and butter. Microwave on High 1 minute or until warm (110°F to 115°F). Add to dry ingredients along with eggs. Beat on Speed #1 with dough hooks until mixed, then increase to Speed #4 for 5 minutes or until smooth. Turn dough out onto floured work surface. Knead 5 or 6 times until smooth. Let rest 5 minutes.

Grease 13x9-inch baking pan. Roll dough into 15x12-inch rectangle. Spread with 3 tablespoons butter. Sprinkle with 1/4 cup sugar and cinnamon. Roll up starting at long edge; seal edges. Cut in 15 (1-inch) slices. Place in greased pan. Press tops until edges touch. Cover; let rise in warm place 1 to 1 1/2 hours or until doubled.

Heat oven to 375°F. Bake 23 to 25 minutes or until deep golden brown and no longer doughy. Cool 15 minutes. Meanwhile, in medium bowl, mix powdered sugar, 2 tablespoons butter, vanilla and 2 tablespoons milk with beaters on Speed #1 until mixed. Then beat on Speed #4 for 1 minute or until smooth and creamy. Frost cinnamon rolls.

Chocolate Fig Bundt Cake with Chocolate Ganache

Prep Time: 35 minutes
Total Time: 3 hours
Serves: 16

1 cup chopped dried figs, 1 1/4 cups strong hot coffee, 1/2 cup butter, softened, 1 1/2 cups sugar, 2 eggs, 1 teaspoon vanilla, 1/2 cup vegetable oil, 2 oz unsweetened chocolate, melted, 2 cups all-purpose flour, 1/4 cup unsweetened cocoa powder, 1 1/2 teaspoons baking soda, 1/2 cup whipping cream, 1 bar (4-oz) semisweet chocolate (chopped)

Heat oven to 350°F (325°F for dark or nonstick pan). Generously grease and flour 12-cup fluted tube pan. In small bowl, mix figs and coffee. Set aside. In large mixing bowl, beat butter, sugar, eggs and vanilla with beaters on Speed #1 until mixed, then increase to Speed #4 until smooth and creamy. Add oil and melted chocolate. Beat on Speed #1 until mixed, then increase to Speed #4 until creamy. Add flour, cocoa powder and baking soda. Beat on Speed #1 until mixed. Drain figs, adding coffee to batter. Beat on Speed #1 until mixed, then increase to Speed #4 for 2 minutes. By hand, stir in figs. Pour into pan. Bake 40 to 45 minutes or until toothpick inserted in center comes out clean. Cool in pan 10 minutes. Turn onto cooling rack. Cool 1 hour.

In small saucepan, heat whipping cream until hot but not boiling. Remove from heat. Stir in chopped semisweet chocolate until melted and smooth. Cool 5 minutes or until mixture is cool enough to begin to mound. Spoon on top of cake and allow to drip down sides of cake. Let stand 30 minutes or until slightly set before cutting.

Mixed Berry Meringue Dessert

Prep Time: 30 minutes
Total Time: 5 hours
Serves: 6

Meringue, 3 egg whites, 1/4 teaspoon cream of tartar, 3/4 cup sugar, 1/2 teaspoon vanilla

Filling
3/4 cup whipping cream, 6 oz cream cheese, softened, 1 cup marshmallow creme

Topping
2 cups mixed fresh berries (sliced strawberries, blueberries, raspberries), 2 tablespoons sugar

Heat oven to 250°F. Line large cookie sheet with parchment paper. In large metal or glass bowl (free of all grease) beat egg whites and cream of tartar with whisk on Speed #10 until foamy. Gradually add sugar, while beating on Speed #10. Continue beating on Speed #10 for 10 to 12 minutes or until stiff peaks form and sugar is completely dissolved. Spread meringue on parchment paper in 9-inch circle. Push some of center meringue to edges, forming a raised edge. Bake 1 1/2 hours or until completely dry. Turn oven off. Leave meringue in oven 2 hours with door closed. Remove from oven. Cool completely, about 1 hour.

In medium bowl, beat whipping cream with whisk on Speed #8 until stiff peaks form. In medium bowl, beat cream cheese and marshmallow cream with beaters on Speed #4 until smooth and creamy. Fold whipped cream into cream cheese mixture. Spread over cooled meringue. Cut in wedges to serve.

In small bowl, mix berries and 2 tablespoons sugar; let stand 5 minutes. Spoon over individual servings of dessert.

Cheese Soufflé

Prep Time: 20 minutes
Total Time: 45 minutes
Serves: 6

1/4 cup butter plus 1 tablespoon for dish, 1/4 cup all-purpose flour, 1 teaspoon Dijon mustard, Dash of cayenne pepper, 1 cup milk, 1 1/2 cups shredded sharp Cheddar cheese (6 oz), 4 eggs, separated, 1/4 teaspoon cream of tartar

Heat oven to 375°F. Butter 1 1/2-quart casserole or soufflé dish. Melt 1/4 cup butter in medium saucepan. Stir in flour, mustard and cayenne. Cook until bubbly. Stir in milk. Cook and stir until mixture boils. Cook and stir 1 minute. Stir in cheese until melted; set aside.

In large bowl, beat egg whites and cream of tartar with whisk on speed #10 until stiff peaks form; set aside. In medium bowl, beat egg yolks with whisk on Speed #8 for 3 minutes or until thick and light lemon-color. Switch to beaters and beat on Speed #3, adding cheese sauce, until mixed. Fold mixture into egg whites. Pour into casserole. Bake 25 to 30 minutes or until deep golden brown and set. Serve immediately.

Prep Time: 25 minutes
Total Time: 1 hour
Serves: 4 to 4 1/2 dozen

3/4 cup butter, softened, 1/2 cup shortening, 1 1/2 cups firmly packed brown sugar, 1/2 cup granulated sugar, 2 eggs, 2 teaspoons vanilla, 3 1/2 cups all-purpose flour, 1 1/2 teaspoons baking soda, 1 cup shelled roasted salted pistachios, coarsely chopped, 1 cup white chocolate baking chips, 1 cup dried tart cherries, coarsely chopped

Heat oven to 350°F. Line large cookie sheets with parchment paper. In large mixing bowl, beat butter, shortening, brown sugar, granulated sugar, eggs and vanilla with beaters on Speed #5 until smooth and creamy. Add flour and baking soda. Beat on Speed #1 for 30 seconds or until mixed, then increase to Speed #5 until smooth. By hand, stir in pistachios, baking chips and cherries.

Drop by rounded tablespoonfuls 2 inches apart on cookie sheets. Bake 11 to 13 minutes or until edges start to brown. Cool on cookie sheets 2 minutes. Remove to cooling rack. Repeat until all cookies are baked. If baking 2 sheets at a time, rotate sheets half-way through baking time.

Herbed Cheese Shortbread Crisps

Prep Time: 20 minutes
Total Time: 35 minutes
Serves: 24 crisps

1/2 cup butter, softened, 1/2 cup crumbled blue cheese, 1/2 cup grated Parmesan cheese
1 cup all-purpose flour, 1 tablespoon chopped fresh thyme leaves, 1/2 teaspoon coarse ground black pepper

Heat oven to 375°F. In medium bowl, beat butter and blue cheese with beaters on Speed #5 until creamy, about 2 minutes. Add remaining ingredients then decrease to Speed #1 until crumbly and dough starts to form. Roll dough into 1-inch balls. Place 3 inches apart on large cookie sheets (shiny aluminum works best). Dip flat bottom of drinking glass in flour and flatten balls to 2 1/2-inch diameter. Bake 11 to 13 minutes or until golden brown. Cool on cookie sheets 2 minutes. Remove to cooling racks.

CLEANING

Unplug the appliance.
We recommend that you clean the attachments immediately after use.
The attachments and storage case can be washed in warm soapy water. The attachments can also be washed in the dishwasher.
Use a damp sponge to clean the body of the appliance and dry it carefully.
Do not clean the appliance or the storage case in a dishwasher.
Do not use abrasive sponges or objects with metal parts.
Do not immerse the motor unit in water. Wipe it clean with a dry or slightly damp cloth.

TROUBLESHOOTING

PROBLEM	CAUSE	SOLUTION
The appliance has stopped working	Your appliance is installed with a microprocessor which controls the power of the appliance. For safety reasons, if the functioning time is too long and/or if there is too much food in the bowl, the appliance will stop working.	To restart your appliance, turn the speed control button (G) to position '0'. Allow your appliance to cool down for a few minutes. Then you can continue to prepare your recipe.
The appliance has stopped working and the display shows	The motor has stalled.	To resume operation, turn off the appliance, and then turn on the appliance again using the ON/OFF button.
Appliance stopped working Display shows nothing Display shows	The motor has overheated.	Unplug the mixer and let it cool down. To resume operation, plug in the appliance and turn it on again using the ON/OFF button.
My appliance does not turn on	Your appliance is not plugged in.	Check the plug, power cord and power supply.
The turbo does not work	You have already reached the maximum speed with the speed setting (G) Note: Turbo speed is equivalent to max speed 10.	The turbo allows you to directly reach the maximum speed without using the speed setting. (G)
I am unable to plug the attachments	Incorrectly attached.	Ensure the attachments are correctly plugged
