- Page 1 HVG 93 .. Gas on Glass Cooktop Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY : 01949 862 012 : 01949 862 003 : service@cda.eu : www.cda.eu...
- Page 2 The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or instal- lation of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance.
-
Page 3: Before Using For The First Time
Important Safeguards and Recommendations – Do not carry out any cleaning or maintenance without first disconnecting the appliance from the electrical supply. – During and after use of the hob, certain parts will become very hot. Do not touch hot parts. –... -
Page 4: Features And Technical Data
Features and Technical Data Fig. 1 Cooking Points Auxiliary burner (A) 1,00 kW This appliance is class 3 Semi-rapid burner (SR) 1,75 kW Rapid burner (R) 3,00 kW Triple ring burner (TR) 3,50 kW Control Panel Triple ring burner control knob (4) Auxiliary burner control knob (1) Semi-rapid burner control knob (2) Rapid burner control knob (3) - Page 5 How to Use the Hob Gas Burners Gas flow to the burners is adjusted by turning the knobs (illustrated in fig. 2) which control the valves. Turning the knob so that the indicator line points to the symbols printed on the panel achieves the following functions: –...
- Page 6 Choice of Burner The symbols printed on the panel by the side of the knob indicate which burner you are controlling. Choose a suitable burner depending on the cookware dia- meter and capacity. The pan diameter should be suitable for the burner power to make the most of the burner’s high efficiency and not waste fuel.
- Page 7 Fig. 6a Fig. 6b...
-
Page 8: Cleaning And Maintenance
Cleaning and Maintenance CAUTION: Do not use harsh General Tips abrasive cleaners – Before cleaning the hob switch it off and wait for it to cool down. or sharp metal scra- – Clean with a cloth, hot water and soap or liquid detergent. pers to clean the –... - Page 9 Burners and Grids – These parts can be removed and cleaned with appropriate products. – After cleaning, the burners and their flame spreaders must be well dried and correctly replaced. – It is very important to check that the burner flame spreader and the cap have been correctly positio- ned.
- Page 10 Correct Positioning of the Auxiliary, Semi-rapid and Rapid Burners – It is very important to check that the burner flame spreader “F” and the cap “C” have been correctly positioned (see figs. 8 and 9). They shall be level and must not rotate. Failure to do so can cause serious problems.
- Page 11 Correct Positioning of the Triple Ring Burner – The triple ring burner must be correctly positio- ned (see fig. 11); the burner ribs must be fitted in their housing as shown by the arrow. The burner correctly positioned must not rotate (fig. 12). –...
-
Page 12: Provision For Ventilation
TIPS FOR INSTALLATION Location – The appliance may be installed in a kitchen, Kitchen/diner or a bed sitting room, but not in a room or space containing a bath or a shower. – The appliance must not be installed in a bed-sitting room of less than 20m –... -
Page 13: Installation
Installation Technical Information For The Installer In order to install the cooktop into the kitchen fixture, a hole with the dimensions shown in fig. 16 has to be made, bearing in mind the following: – Within the unit, between the bottom of the cooktop and the upper surface of a shelf there must be a clearance of at least 30mm. - Page 14 Fig.16 (1) 55mm from top of countertop (2) at least 135mm between the back side of the cut-out and the back of the countertop. Installing the Separator Below the Base of the Cooktop It is recommended that a 30mm clearance be left between to base of the cooktop and the separator.
- Page 15 Fastening the Cooktop Each cooktop is provided with an installation kit including brackets and screws for fastening the co- oktop to benches from 30 to 40mm thick.The kit includes two “F” type brackets (for the front of the cooktop), two “R” type brackets (for the rear of the cooktop) and four self-threading screws “S” (figs. 19a and 19b).
-
Page 16: Gas Supply Requirements
Gas Supply Requirements Important Note This appliance is supplied for use on NATURAL GAS or LPG (check the gas regulation label attached on the appliance). – Appliances supplied for use on NATURAL GAS: they are adjusted for this gas only and cannot be used on any other gas (LPG) without modification. -
Page 17: Gas Connection
The installation must conform to the relevant British Standards. CDA are not legally able to provide any assistance in the installation of gas appliances except to suitably qualified and registered installers. Any suitably qualified and registered fitter requiring help must provi- de name, address and registration number. - Page 18 1/2" G cylindrical 1/2" G cylindrical Gas Connection Cat: II 2H3+ (ISO 22 8-1) male (ISO 22 8 -1) female The fitting (fig. 20) is made up of: – 1 nut “A” – 1 elbow fitting “C” – gasket “F” Connection to the Gas Supply •...
-
Page 19: Conversion To Natural Gas Or To Lpg
Conversion to Natural Gas or to LPG Replacing the Burner Injectors If the NATURAL GAS/LPG conversion kit is not supplied with the appliance this kit can be purchased by contacting the After-Sales Service. Choose the injectors to be replaced according to the “Table for the Choice of the Injectors”. The injector diameter, expressed in hundredths of a millimetre, is marked on the injector body. -
Page 20: Lubrication Of The Gas Taps
Table for the Choice of the Injectors Cat: II 2H3+ G30 - 28-30 mbar G20 - 20 mbar Nominal Reduced G31 - 37 mbar Burners Power Power Ø Injector Ø Injector 1/100 mm 1/100 mm Auxiliary (A) 1,00 0,30 72 (X) Semi-Rapid (SR) 1,75 0,45... -
Page 21: Mains Electricity Connection
Mains Electricity Connection Incorrect installation may be dangerous and the manufacturer can not be held responsible. Warning! This appliance must be earthed The manufacturer declines all responsibility for any problem caused by failure to observe this rule. THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY BY A COMPETENT PERSON, USING FIXED WIRING VIA A DOUBLE POLE SWITCHED FUSE SPUR OUTLET AND PROTECTED BY A 3A FUSE. -
Page 22: Appliance Servicing
Appliance Servicing CDA provide a quality and effective after-sales service to cover all your servicing needs. Please attach your receipt to this page for safekeeping. Please help us to help you by having the following information available when booking a service-call: Model type, make and model –... - Page 24 To contact our Customer Care Department, or for Service, please contact us on the details below. Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY : 01949 862 012 : 01949 862 003 : service@cda.eu : www.cda.eu...
