PORTFOLIO
HOUSING
3"
HA3MR
HOUSING
HA3MR=Low Voltage MR16 Directional, 120/277V
HA3MRCP=Low Voltage MR16 Directional, 120/277V
Chicago Plenum
TRIM
Open Downlight
MR16 75W Max
Angle Cut
MR16 75W Max
Pinhole
MR16 75W Max
Lens Wall Wash
MR16 75W Max
Ordering Example
Housing, Trim, Accessories and Lamps ordered as separate line items.
838
COOPER LIGHTING
™
3" Low Voltage Directional
MR16
Low Voltage MR16 adjustable fixture for flat or slope ceilings.
Use open downlight for general and task lighting. Pinhole
hides lamp and provides clean ceiling. Lens wall wash for
even illumination along vertical surfaces. Lockable 361°
rotation and 45° tilt with center beam optics provides full
output with no flash back. Top lamp accessible. Integral
magnetic transformer.
TRIM
3451=Self Flanged
3450=Metal Trim Ring,
White
TRIM
3471=Self Flanged
3470=Metal Trim Ring,
White
TRIM
3470PIN=Pin Hole, Black
Shielding Cone and Oculus,
White Metal Trim Ring
TRIM
3481=Self Flanged
3480=Metal Trim Ring,
White
OPTIONS
DR37=DeRated Wattage Label
for 37W Maximum
DR50=DeRated Wattage Label
for 50W Maximum
FINISH
LI=Low Iridescent Clear
BB=Black Baffle
H=Haze
(3450 only)
WMH=Warm Haze
WB=White Baffle
G=Gold
(3450 only)
WH=Wheat
B=Black
W=Gloss White
GP=Graphite
GPH=Graphite Haze
K=Cognac
KH=Cognac Haze
FINISH
LI=Low Iridescent Clear
BB=Black Baffle
H=Haze
(3470 only)
WMH=Warm Haze
WB=White Baffle
G=Gold
(3470 only)
WH=Wheat
B=Black
W=Gloss White
GP=Graphite
GPH=Graphite Haze
K=Cognac
KH=Cognac Haze
FINISH
LI=Low Iridescent Clear
H=Haze
WMH=Warm Haze
G=Gold
WH=Wheat
B=Black
W=Gloss White
GP=Graphite
GPH=Graphite Haze
K=Cognac
KH=Cognac Haze
Housing
Trim
HA3MRDR50
3450LI
Dimensions
Length
Width
Standard Housing
12-1/8"
12"
Chicago Plenum
12-1/8"
12"
ACCESSORIES
HB26=C Channel Bar Hanger, 26" Long, Pair
HB50=C Channel Bar Hanger, 50" Long, Pair
RMB22=Wood Joist Bar Hanger, 22" Long, Pair
L100 Series=Color Filters and Lens
FK5=Field Installed Fuse Kit, 5 Amp
OPTIONS
WF=White
Painted Flange
(Self Flanged
only)
OPTIONS
WF=White
Painted Flange
(Self Flanged
only)
1-1/2"
OPTIONS
WF=White
Painted Flange
(Self Flanged
only)
Accessories
HB26
Height
Cutout
5-9/16"
4-9/16"
5-9/16"
3-1/2"
5-1/8"
3-1/2"
5-1/8"
5-1/8"
3-1/2"
5-1/8"
