- Page 1 HPE FlexNetwork 5140 EI Switch Series Installation Guide Part number: 5200-7780a Document version: 6W101-20210706...
- Page 2 © Copyright 2021 Hewlett Packard Enterprise Development LP The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.
-
Page 3: Table Of Contents
Contents Preparing for installation ················································································ 1 Safety recommendations ··································································································································· 2 Examining the installation site ···························································································································· 2 Temperature/humidity ································································································································ 2 Cleanliness ················································································································································· 3 Corrosive gas limit ······································································································································ 3 EMI ····························································································································································· 4 Laser safety ················································································································································ 4 Installation tools ················································································································································· 5 Installation accessories ······································································································································ 5 Installing the switch ························································································... - Page 4 Fan tray failure ················································································································································· 35 Symptom ·················································································································································· 35 Solution ···················································································································································· 35 Configuration terminal issues ··························································································································· 35 No display on the configuration terminal ·································································································· 35 Garbled display on the configuration terminal ·························································································· 36 Technical specifications ··············································································· 37 Non-PoE switch models ··································································································································· 37 PoE switch models ···········································································································································...
-
Page 5: Preparing For Installation
Preparing for installation Table 1 describes the HPE FlexNetwork 5140 EI switches, power supplies,and interface cards available for the switches. Table 1 HPE 5140 EI switch models and power supplies Product code HPE description Alias HPE 5140 EI switches JL828A HPE FlexNetwork 5140 24G 4SFP+ EI Switch HPE 5140 24G 4SFP+ EI JL826A... -
Page 6: Safety Recommendations
NOTE: The available chassis models and accessories vary by country and region. This document describes only the preceding models. For the chassis models and accessories available in your country or region, contact the local HPE marketing personnel. Safety recommendations To avoid equipment damage or bodily injury, read the following safety recommendations before installation. -
Page 7: Cleanliness
Cleanliness Dust buildup on the chassis might cause electrostatic adsorption and dust corrosion, resulting in poor contact of metal connectors and contact points. This might shorten the device's lifetime and even cause device failure in the worst case. Table 2 describes the dust concentration limits in the equipment room. -
Page 8: Emi
CAUTION: As a best practice, control the corrosive gas concentrations in the equipment room at their average values. Make sure the corrosive gas concentrations do not exceed 30 minutes per day at their maximum values. To control corrosive gases, use the following guidelines: •... -
Page 9: Installation Tools
Installation tools No installation tools are provided with the switch. Prepare the following tools yourself as required. • Flat-blade screwdriver • Phillips screwdriver • ESD wrist strap • Needle-nose pliers • Diagonal pliers • Crimping tool • Marker • Heat gun Installation accessories All the installation accessories except the following installation accessories are provided with the switch:... - Page 10 Product code Description Quantity Applicable models Grounding cable (tin-plated at one end and with a ring terminal at the other end) 5185-9292 All HPE 5140 EI switches DC power cord (supplied with the PSR150-D1 (JD366B) DC power supply) 5185-9443 PSR150-D1 (JD366B) DC 5080-0120 power supply The power cord color code scheme is for...
-
Page 11: Installing The Switch
Installing the switch CAUTION: Keep the tamper-proof seal on a mounting screw on the chassis cover intact, and if you want to open the chassis, contact HPE for permission. Otherwise, HPE shall not be liable for any consequence. Figure 1 Hardware installation flow Start Install the switch Ground the switch... -
Page 12: Installing The Switch In A 19-Inch Rack
Installing the switch in a 19-inch rack Mounting brackets Table 5 describes the mounting brackets applicable to the switch. Table 5 Mounting brackets applicable to the switch Switch model Mounting brackets Views HPE 5140 24G 4SFP+ EI HPE 5140 48G 4SFP+ EI Mounting brackets A See A in Figure... -
Page 13: Attaching The Mounting Brackets To The Switch
Attaching the mounting brackets to the switch Determine the installation position for the mounting brackets. The HPE 5140 24G SFP w/8G Combo 4SFP+ EI, HPE 5140 24G PoE+ 2SFP+ 2XGT EI, and HPE 5140 48G PoE+ 2SFP+ 2XGT EI switches provide two installation positions for the mounting brackets: port side mounting position and power supply side mounting position. -
Page 14: Rack-Mounting The Switch
Figure 5 Attaching mounting bracket B to the power supply side mounting position (HPE 5140 24G SFP w/8G Combo 4SFP+ EI) Figure 6 Attaching mounting bracket C (HPE 5140 8G 2SFP 2GT Combo EI) Rack-mounting the switch This task requires two people. To mount the switch in the rack: Wear an ESD wrist strap and make sure it makes good skin contact and is reliably grounded. - Page 15 Figure 7 Mounting an HPE 5140 24G SFP w/8G Combo 4SFP+ EI switch in the rack (port side mounting position for the mounting brackets) Figure 8 Mounting an HPE 5140 24G SFP w/8G Combo 4SFP+ EI switch in the rack (power supply side mounting position for the mounting brackets)
-
Page 16: Mounting The Switch On A Workbench
Figure 9 Mounting an HPE 5140 8G 2SFP 2GT Combo EI switch in the rack Mounting the switch on a workbench IMPORTANT: • Ensure 10 cm (3.9 in) of clearance around the chassis for heat dissipation. • Do not place heavy objects on the switch. If a standard 19-inch rack is not available, you can place you switch on a workbench. - Page 17 Figure 10 Screw anchor and screw To mount the switch on a wall: Mark two installation holes on the wall. Make sure the two holes are on the same horizontal line. Table 6 for the distance requirement between the two holes. Figure 11 Installing the switch on a wall (1) Drill two holes with a diameter of 6 mm (0.24 in) and a depth of 25 mm (0.98 in) at the marked locations.
-
Page 18: Grounding The Switch
Figure 13 Installing the switch on a wall (3) Grounding the switch WARNING! Correctly connecting the switch grounding cable is crucial to lightning protection and EMI protection. The power input end of the switch has a noise filter, whose central ground is directly connected to the chassis to form the chassis ground (commonly known as PGND). -
Page 19: Grounding The Switch With A Grounding Conductor Buried In The Earth Ground
Figure 14 Attaching the grounding cable to the grounding hole of the switch (HPE 5140 24G PoE+ 4SFP+ EI) (1) Grounding screw (2) Ring terminal (3) Grounding sign (4) Grounding hole (5) Grounding cable Connect the other end of the grounding cable to the grounding strip. a. -
Page 20: Installing And Removing Power Supplies
Weld the yellow-green grounding cable to the angel iron or steel tube and treat the joint for corrosion protection. Figure 16 Grounding the switch by burying the grounding conductor into the earth ground (1) Grounding screw (2) Grounding cable (3) Earth (4) Joint (5) Grounding conductor (6) Chassis rear panel... -
Page 21: Installing A Power Supply
Installing a power supply Wear an ESD wrist strap and make sure it makes good skin contact and is reliably grounded. Unpack the power supply and verify that the power supply model is as required. Remove the filler panel (if any) from the target slot. If you require only one power supply, install it in power supply slot 1 and make sure a filler panel is installed in power supply slot 2. -
Page 22: Connecting The Power Cord
Figure 20 Removing a power supply Connecting the power cord CAUTION: • Provide a circuit breaker for each power cord. • Before connecting the power cord, make sure the circuit breaker on the power cord is turned off. Table 7 Power cord connection procedures at a glance Switch model Available power source Connection procedure reference... -
Page 23: Connecting The Dc Power Cord For The Fixed Dc Power Supply
Figure 21 Connecting the AC power cord for the fixed AC power supply Figure 22 Securing the AC power cord for the fixed AC power supply through a cable tie Connecting the DC power cord for the fixed DC power supply CAUTION: •... -
Page 24: Connecting The Power Cord For A Psr150-A1 Power Supply
Figure 23 Connecting the DC power cord for the fixed DC power supply Connecting the power cord for a PSR150-A1 power supply Pull the bail latch leftward, as shown in Figure Connect the plug of the power cord to the power receptacle on the switch. See Figure Pull the bail latch rightward to secure the plug to the power receptacle. -
Page 25: Connecting The Power Cord For A Psr150-D1 Power Supply
Figure 25 Connecting the power cord for a PSR150-A1 power supply (2) Connecting the power cord for a PSR150-D1 power supply CAUTION: • Connect the other ends of the wires for a PSR150-D1 power supply to a –48 VDC power source, with the negative wire (–... -
Page 26: Verifying The Installation
Figure 26 Connecting the DC power cord for a PSR150-D1 power supply (HPE 5140 24G SFP w/8G Combo 4SFP+ EI) Verifying the installation After you complete the installation, verify that: • There is enough space for heat dissipation around the switch, and the rack or workbench is stable. -
Page 27: Accessing The Switch For The First Time
Accessing the switch for the first time Setting up the configuration environment You can access and configure the switch through the serial console port or the micro USB console port. Only the micro USB console port is available if you connect both the serial console port and micro USB console port. -
Page 28: Connecting The Micro Usb Console Cable
RJ-45 Signal DB-9 Signal To connect to a configuration terminal (for example, a PC) through the serial console cable: Plug the DB-9 female connector of the serial console cable to the serial port of the PC. Connect the RJ-45 connector to the serial console port of the switch. NOTE: •... - Page 29 Figure 29 Device Driver Installation Wizard Click Continue Anyway if the following dialog box appears. Figure 30 Software Installation Click Finish.
-
Page 30: Setting Terminal Parameters
Figure 31 Completing the device driver installation wizard Setting terminal parameters To configure and manage the switch through the console port, you must run a terminal emulator program, TeraTermPro or PuTTY, on your PC. You can use the emulator program to connect a network device, a Telnet site, or an SSH site. - Page 31 with software versions. For more information about Boot ROM menu options, see the software-matching release notes for the device. After the startup completes, you can access the CLI to configure the switch. For more information about the configuration commands and CLI, see HPE 5140 EI Switch Series Configuration Guides and HPE 5140 EI Switch Series Command References.
-
Page 32: Setting Up An Irf Fabric
Setting up an IRF fabric You can use HPE IRF technology to connect and virtualize the switches into a large virtual switch called an "IRF fabric" for flattened network topology, and high availability, scalability, and manageability. IRF fabric setup flowchart Figure 32 IRF fabric setup flowchart Start Plan IRF fabric setup... -
Page 33: Planning Irf Fabric Setup
Step Description on a workbench." Connect grounding cables and "Grounding the switch" and "Connecting the power cord." power cords. Power on the switches. See the IRF configuration guide or virtual technologies Configure basic IRF settings. configuration guide for the switch series, depending on the software version. -
Page 34: Identifying Irf Physical Ports On The Member Switches
The switch can form an IRF fabric only with switches from the same switch series. For the physical ports that can be used for IRF connections and the restrictions for using the ports, see Table 9. The IRF physical ports can set up IRF connections only when operating at their highest speeds. For example, a 10-GE port must operate at 10 Gbps. -
Page 35: Planning The Cabling Scheme
Table 9 IRF physical ports and use restrictions Candidate IRF physical Restrictions for using the ports for Device model ports IRF connections All physical ports to be bound to an IRF port must have the same data rate. The port must operate at its highest speed. HPE 5140 24G 4SFP+ EI •... -
Page 36: Configuring Basic Irf Settings
As a best practice, use ring topology to connect the switches. The following describes cabling schemes in ring topology. Connecting the IRF member switches in one rack Use SFP cables to connect the IRF member switches in a rack as shown in Figure 35. -
Page 37: Connecting The Irf Physical Ports
• Assign the master switch higher member priority than any other switch. • Bind physical ports to IRF port 1 on one switch and to IRF port 2 on the other switch. You perform IRF port binding before or after connecting IRF physical ports depending on the software release. -
Page 38: Maintenance And Troubleshooting
Maintenance and troubleshooting Fixed power supply failure To identify a power failure on a switch with fixed power supplies, examine the system status LED (SYS) and the RPS status LED (RPS) on the switch. NOTE: Only the following switches provide an RPS status LED: •... -
Page 39: Symptom
PWR2 on the switch front panel. For descriptions about the PWR1 and PWR2 LEDs, see LEDs in Hardware Information and Specifications. Symptom A power supply LED on the front panel of the switch is not steady green. Solution To resolve the issue: Verify that the AC or DC power cord is correctly connected to the switch. -
Page 40: Garbled Display On The Configuration Terminal
Verify that the console cable is not faulty. If the issue persists, contact HPE Support. Garbled display on the configuration terminal Symptom The configuration terminal displays garbled text. Solution To resolve the issue: Verify that the following settings are configured for the terminal: Baud rate—9600. -
Page 41: Technical Specifications
Technical specifications Non-PoE switch models Table 12 Technical specifications for non-PoE switch models (1) HPE 5140 8G HPE 5140 24G HPE 5140 48G HPE 5140 24G Item 2SFP 2GT 4SFP+ EI 4SFP+ EI 2SFP+ 2XGT EI Combo EI 43.6 × 440 × 160 mm 43.6 ×... - Page 42 HPE 5140 8G HPE 5140 24G HPE 5140 48G HPE 5140 24G Item 2SFP 2GT 4SFP+ EI 4SFP+ EI 2SFP+ 2XGT EI Combo EI current compliance Melting current of 2 A/250 V 3.15 A/250 V 2 A/250 V 2 A/250 V power supply fuse Using fixed fan trays...
-
Page 43: Poe Switch Models
Item HPE 5140 24G SFP w/8G Combo 4SFP+ EI • 2 × PSR150-A1: 23 W • 2 × PSR150-D1: 22 W • 1 × PSR150-A1: 48 W • 1 × PSR150-D1: 51 W Maximum power • consumption 2 × PSR150-A1: 55 W •... - Page 44 HPE 5140 24G PoE+ 2SFP+ HPE 5140 48G PoE+ 2SFP+ 2XGT Item 2XGT EI Chassis leakage UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC current compliance 60950-1/GB4943.1 Melting current of 2 A/250 V power supply fuse Using fixed fan trays to draw ambient air in from the chassis left side and exhaust Cooling system heated air from the chassis right side.
- Page 45 Item HPE 5140 48G PoE+ 4SFP+ EI HPE 5140 24G PoE+ 4SFP+ EI consumption) Chassis leakage UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC current compliance 60950-1/GB4943.1 Melting current of 15 A/250 V 15 A/250 V power supply fuse Using fixed fan trays to draw ambient air Using fixed fan trays to draw ambient air Cooling system in from the left side and exhaust heated...
-
Page 46: Chassis Views
Chassis views HPE 5140 8G 2SFP 2GT Combo EI Figure 38 Front panel (1) 10/100/1000BASE-T autosensing Ethernet port (2) 10/100/1000BASE-T autosensing Ethernet port LED (3) SFP port LED (4) System status LED (SYS) (5) Console port (CONSOLE) (6) SFP port Figure 39 Rear panel (1) Grounding screw (2) AC-input power receptacle... -
Page 47: Hpe 5140 48G 4Sfp+ Ei
Figure 41 Rear panel (1) Grounding screw (2) AC-input power receptacle HPE 5140 48G 4SFP+ EI Figure 42 Front panel (1) 10/100/1000BASE-T autosensing Ethernet port (2) 10/100/1000BASE-T autosensing Ethernet port LED (3) Console port (CONSOLE) (4) Micro USB console port (5) SFP+ port LED (6) System status LED (SYS) (7) SFP+ port... -
Page 48: Hpe 5140 24G Sfp W/8G Combo 4Sfp+ Ei
HPE 5140 24G SFP w/8G Combo 4SFP+ EI Figure 44 Front panel (1) SFP port (2) SFP port LED (3) 10/100/1000BASE-T autosensing Ethernet port (4) 10/100/1000BASE-T autosensing Ethernet port LED (5) Management Ethernet port (6) Console port (CONSOLE) (7) Micro USB console port (8) System status LED (SYS) (9) Power supply 2 status LED (PWR2) (10) Power supply 1 status LED (PWR1) -
Page 49: Hpe 5140 24G 2Sfp+ 2Xgt Ei
HPE 5140 24G 2SFP+ 2XGT EI Figure 46 Front panel (1) 10/100/1000BASE-T autosensing Ethernet port (2) SFP+ port (3) 10/5/2.5/1GBASE-T autosensing Ethernet port (4) Console port (CONSOLE) (5) 10/100/1000BASE-T autosensing Ethernet port LED (6) SFP+ port LED (7) 10/5/2.5/1GBASE-T autosensing Ethernet port LED (8) System status LED (SYS) Figure 47 Rear panel (1) Grounding screw... -
Page 50: Hpe 5140 48G Poe+ 4Sfp+ Ei
Figure 49 Rear panel (1) Grounding screw (2) AC-input power receptacle (3) DC-input power receptacle HPE 5140 48G PoE+ 4SFP+ EI Figure 50 Front panel 10 9 (1) 10/100/1000BASE-T autosensing Ethernet port (2) 10/100/1000BASE-T autosensing Ethernet port LED (3) Console port (CONSOLE) (4) Port LED mode switching button (5) System status LED (SYS) (6) RPS status LED (RPS) -
Page 51: Hpe 5140 24G Poe+ 2Sfp+ 2Xgt Ei
HPE 5140 24G PoE+ 2SFP+ 2XGT EI Figure 52 Front panel (1) 10/100/1000BASE-T autosensing Ethernet port (2) SFP+ port (3) 10/5/2.5/1GBASE-T autosensing Ethernet port (4) Console port (CONSOLE) (5) Port LED mode switching button (6) 10/100/1000BASE-T autosensing Ethernet port LED (7) SFP+ port LED (8) System status LED (SYS) (9) Mode LED (MODE) - Page 52 (1) 10/100/1000BASE-T autosensing Ethernet port (3) SFP+ port (4) Console port (CONSOLE) (5) Port LED mode switching button (6) Mode LED (MODE) (7) System status LED (SYS) (8) 10/5/2.5/1GBASE-T autosensing Ethernet port (9) 10/5/2.5/1GBASE-T autosensing Ethernet port LED (10) SFP+ port LED Figure 55 Rear panel (1) AC-input power receptacle (2) Grounding screw...
-
Page 53: Removable Components
Removable components WARNING! You can replace one of the two power supplies operating in 1+1 redundancy on the HPE 5140 24G SFP w/8G Combo 4SFP+ EI switches. To avoid device damage and bodily injury, make sure the power supply is powered off before removing it. The HPE 5140 24G SFP w/8G Combo 4SFP+ EI switches provide two power supply slots. -
Page 54: Management Ethernet Port
Item Serial console port Micro USB console port • Provides connection to • Provides connection to an ASCII terminal. an ASCII terminal. • • Provides connection to the serial port of a Provides connection to Services local PC running terminal emulation the USB port of a local program. -
Page 55: 10/5/2.5/1Gbase-T Autosensing Ethernet Port
10/5/2.5/1GBASE-T autosensing Ethernet port The HPE 5140 24G PoE+ 2SFP+ 2XGT EI, HPE 5140 24G 2SFP+ 2XGT EI and HPE 5140 48G PoE+ 2SFP+ 2XGT EI switches provide 10/5/2.5/1GBASE-T autosensing Ethernet ports. Table 20 10/5/2.5/1GBASE-T autosensing Ethernet port specifications Item Specification Connector type RJ-45... - Page 56 Connect bandwidt waveleng diameter transmission code description h (MHz × th (nm) (µm) distance HP X120 1G Category-5 JD089B SFP RJ45 T RJ45 100 m (328.08 ft) twisted pair Transceiver 550 m (1804.46 ft) 50/125 HP X120 1G 500 m (1640.42 ft)
- Page 57 Product Connect bandwidt waveleng diameter transmission code description h (MHz × th (nm) (µm) distance HP X125 1G 40 km (24.86 SFP LC LH40 JD061A 1310 9/125 miles) 1310nm Transceiver HP X120 1G SFP LC LH40 40 km (24.86 JD062A...
-
Page 58: Sfp+ Port
(MHz × h (nm) (µm) distance 2000 300 m (984.25 ft) Multi-mode, 82 m (269.03 ft) 50/125 HP X130 10G JD092B SFP+ LC SR 66 m (216.54 ft) Transceiver 33 m (108.27 ft) Multi-mode, 62.5/125 26 m (85.30 ft) -
Page 59: Combo Interface
Table 25 10-GE SFP+ cables available for the SFP+ ports Product code HPE description Max transmission distance JD095C HP X240 10G SFP+ SFP+ 0.65m DA Cable 0.65 m (2.13 ft) JD096C HP X240 10G SFP+ SFP+ 1.2m DA Cable 1.2 m (3.94 ft) -
Page 60: Management Ethernet Port Led
Table 26 System status LED description LED mark Status Description Steady yellow Boot ROM booting stage. Linux kernel booting stage, or the switch has started up Steady green correctly. Software image loading and decompressing stage, or Flashing green (1 Hz) software booting stage. -
Page 61: Mode Led (Mode)
Mode LED (MODE) Each PoE switch provides a mode LED (MODE). The mode LED works in conjunction with the Ethernet port LEDs to indicate the operating state of the Ethernet ports and the switch. You can use the LED mode switching button to change the indication of the mode LED. Table 30 Description for the mode LED LED mark Status... - Page 62 Mode LED Ethernet port LED Description status status power supply requirement of the port. The port is not connected to a PD or PoE is not enabled on the port. The Ethernet port LEDs on the switch work in conjunction to Flashing indicate the IRF member ID of the switch.
-
Page 63: Support And Other Resources
Hewlett Packard Enterprise Support Center More Information on Access to Support Materials page: www.hpe.com/support/AccessToSupportMaterials IMPORTANT: Access to some updates might require product entitlement when accessed through the Hewlett Packard Enterprise Support Center. You must have an HP Passport set up with relevant entitlements. Websites Website Link... -
Page 64: Customer Self Repair
Hewlett Packard Enterprise Information Library for www.hpe.com/networking/resourcefinder Networking Hewlett Packard Enterprise Networking website www.hpe.com/info/networking Hewlett Packard Enterprise My Networking website www.hpe.com/networking/support Hewlett Packard Enterprise My Networking Portal www.hpe.com/networking/mynetworking Hewlett Packard Enterprise Networking Warranty www.hpe.com/networking/warranty General websites Hewlett Packard Enterprise Information Library www.hpe.com/info/enterprise/docs Hewlett Packard Enterprise Support Center www.hpe.com/support/hpesc... -
Page 65: Index
Index A C E F G H I L M N P R S T V Attaching the mounting brackets to the switch,9 Identifying IRF physical ports on the member switches,30 Identifying the master switch and planning IRF Cleanliness,3 member IDs,29 Combo interface,55... - Page 66 port,51 Symptom,35 SFP/SFP+ port LED,57 System status LED,55 SFP+ port,54 Solution,34 Temperature/humidity,2 Solution,35 Solution,35 Symptom,34 Verifying the installation,22 Symptom,35 Verifying the IRF fabric setup,33...
