PAR36 12V
Closed Back Machined Fixture w/ Integral Transformer
PM615cbi | PM415cbi | PM215cbi | PM115cbi
A machined aluminum track fixture for low voltage
PAR36 lamps for 35 or 50 watts. For use with RSA
Profile Series 60 Amp Busway, 20 Amp 1 or 2 Circuit
Track or 20 Amp 2 Circuit / 2 Neutral Track.
Integral low voltage electronic transformer in
aluminum housing.
Front loading lamp with bayonet action lens /
accessory bezel. Optical accessories are captured
in the bezel with a threaded retainer ring preventing
accessory spill-out during relamping. Can accom-
modate up to three optical accessories.
Auto extending / retracting lamp holder. Lamps
extend for easy access and automatically retract
to optimum position. This is extremely helpful when
dealing with varying accessory combinations or dif-
fering manufacturer lamp dimensions.
Optical accessories include color filters, UV fil-
ters, screens, spread lenses, louvers, hex louvers,
snoots. Consult RSA for details.
Locking on both the horizontal and vertical
planes. 370º vertical rotation possible due to over-
center locking mechanism (60 amp busway only).
270º horizontal locking adjustment.
UL and CUL listed
Available in White, Black, Natural Aluminum or
custom finishes.
Closed Back Machined Fixture w/ Integral Transformer
❑ PM615cbi - PAR36 for 60 Amp Busway
❑ PM115cbi - PAR36 for 20 Amp 1 Circuit Track
❑ PM215cbi - PAR36 for 20 Amp 2 Circuit Track
❑ PM415cbi - PAR36 for 20 Amp 2 Circuit / 2 Neutral Track
Ordering Example:
PM615cbi-50-AL-120
www.rsalighting.com
PM60
Lamp Wattage
❑ 35
❑ 50
RSA Lighting 9660-9700 Topanga Canyon Blvd. Chatsworth, CA 91311
Toll Free: 800-356-3030 • 818-349-3030 • Fax: 818-349-3031
®
©2004 RSA Lighting • All Rights Reserved • Specifications are subject to change without notice
Catalog #
Type
Project
Finish
35 Watt 12V PAR36
❑ WH White
50 Watt 12V PAR36
❑ BK
❑ AL
❑ PT
60 Amp Busway
Voltage
❑ 120 120 Volts primary
Black
❑ 277 277 Volts primary
Natural Alum.
Custom Finish
www.cooperlighting.com
PM615cbi
PM415cbi
20 Amp Track
2 Cct. 2 Ntl.
PM115cbi
PM215cbi
20 Amp Track
1 or 2 Cct.
