Instruction Manual
AV Receiver
DRX-3.4
En

Advertisement

loading

Related Manuals for Integra DRX-3.4

Summary of Contents for Integra DRX-3.4

  • Page 1 Instruction Manual AV Receiver DRX-3.4...

  • Page 2: Table Of Contents

    Table of contents Firmware Update Speaker Layout Troubleshooting Main Room Main Room Room Supplementary Information Zone 2 Zone 2 Zone 2 Zone 2 Speaker Connections Reducing the Power Consumption in Standby State When the following functions are enabled, the power consumption in standby state increases.
  • Page 3 Connections Before starting the procedure Firmware Update Notes regarding connections with HDMI cables Update Information of the firmware Connections Firmware Update Procedure Connecting the TV Part Names To ARC/eARC TV Front Panel To Non-ARC TV Display Connecting the SUB Monitor Rear Panel SUB Monitor Remote Controller...
  • Page 4 Playback Amazon Music Registering This Unit with Amazon Music Playing audio from an externally connected device Playing Amazon Music using the Integra Basic Operations Control Pro BLUETOOTH Playback ® Playing Amazon Music using the remote controller Playing audio from BLUETOOTH wireless technology...
  • Page 5 1. Speaker Setup Play Queue 2. Multi Zone Sound Check Adding Play Queue Information 3. ARC Setup Sort and Delete 4. Room EQ Integra Control Pro Playing Back Connecting a transmitter for playback Main features Connections Initial Setup Setting Up...
  • Page 6 Before starting the procedure „ What's in the box „ Note • Connect speakers with an impedance of 4 Ω to 16 Ω. • The power cord must be connected only after all other connections are completed. • We will not accept any responsibility for damage arising from the connection with equipment manufactured by other companies.
  • Page 7 Firmware Update Updating the Firmware via Network This unit is equipped with a function to update the firmware via network or USB port when the firmware update is announced after purchase. This enables • While updating the firmware, do not do the following: various functions to be added and operations to be improved.
  • Page 8 Updating via USB represents an alphanumeric character.) Refer to the following descriptions and check. • While updating the firmware, do not do the following: Error Code – Disconnecting and reconnecting cables, USB storage device, speaker • -01, -10: setup microphone or headphones, or performing operations on the unit Ethernet cable not found.
  • Page 9 4. Connect the USB storage device to the USB port of this unit. • Others: • If an AC adapter is supplied with the USB storage device, connect the AC After removing the power plug once, insert it to the outlet, and then start the adapter, and use it with a household outlet.
  • Page 10 Part Names Front Panel 4. Remote control sensor: Receives signals from the remote controller. • The reception range of the remote controller is within a distance of approx. 16´/5 m, and an angle of 20° in vertical direction and 30° to right and left.
  • Page 11 Front Panel 15 16 15. Zone 2 button: Controls the multi-zone function. 19. Input selector buttons: Switches the input to be ( →p90) played. Off button: Switches the multi-zone function off. 20. AUX Input Video/Audio jacks: Input the video 16. Zone 3 button: Controls the multi-zone function. and audio signals from an external player with an ( →p92) analog audio/video cable.
  • Page 12 Display B: Audio is output only to ZONE B. AB: Audio is output to both ZONE A and ZONE 3. Lights according to the type of input digital audio signal and the listening mode. 4. Lights in the following conditions. RDS (Australian models): Receiving RDS broadcasting.
  • Page 13 Rear Panel 5. HDMI OUT jacks: Transmit video signals and audio signals with an HDMI cable connected to a monitor such as a TV or projector. 6. RS232 port: Connect a home control system equipped with an RS-232C port. For installing a home control system, contact the specialized stores.
  • Page 14 Rear Panel (ZONE 3). HEIGHT 2 PRE OUT jacks: Connect to a power amplifier. ( →p45) SURR BACK PRE OUT jacks: Connect to a power amplifier. ( →p45) 18. ZONE 2 PRE/LINE OUT jacks: Output audio signals with an analog audio cable connected to an integrated amplifier in a separate room (ZONE 2).
  • Page 15 Remote Controller On/Standby button selected, pressing and holding this button for 5 2. Input selector buttons: Switches the input to be seconds or more will switch to the pairing mode. played. button: Returns the display to the previous 3. Play buttons: Used for playback operations state while setting.
  • Page 16 Remote Controller 12. Tone buttons: Adjusts the sound quality. Press tuning and manual tuning for AM/FM stations "Treble", "Bass", or "Vocal" to select what you ( →p67). Also, when an HDMI CEC function- want to adjust, then adjust with + and -. enabled AV component is connected to this unit, Treble/Bass button: You can adjust the sound you can switch "3.
  • Page 17 Inputting Characters You can input characters or symbols on the keyboard displayed on the TV • Select "A/a" to switch between upper and lower cases. (Can also be switched screen such as when inputting a password for Wi-Fi Setup ( →p126) or naming with the Mode button on the remote controller.) a preset radio station ( →p121).
  • Page 18 Speaker Layout This unit can be used in different ways, depending on the layout of the speakers you are installing. Select the speaker layout that suits the installation environment, then confirm the methods for installation and connection. Speaker Layout 5.1ch 7.1ch 5.1.2ch ‰...

  • Page 19: Speaker Layout

    Speaker Layout The listening room and the speaker layout 1. ZONE A Speakers The speaker system set up in the main room (where this unit is located). 2. ZONE 2 Speakers The 2 ch speaker system set up in a separate room (Zone 2). This enables you to play the same source in the main room and the separate at the same time, or to play separate sources.
  • Page 20 Speaker Layout 5.1 Channel System This is a basic 5.1 Channel System. Basic system ( →p27) 5.1 ch + ZONE 2 ( →p27) 5.1 ch + ZONE 2/ZONE 3 ( →p27) Main Room Main Room Zone 2 Zone 2 Zone 2 Zone 2 Zone 3 Zone 3...
  • Page 21 Speaker Layout 7.1 Channel System This is a 7.1 Channel System that consists of the basic 5.1 Channel System and added surround back speakers. Basic system ( →p27) 7.1 ch + ZONE 2 ( →p27) 7.1 ch (Bi-Amping (Front)) ( →p27) Main Room Zone 2 Zone 2...
  • Page 22 Speaker Layout 5.1.2 Channel System A Speaker System that is a 5.1 Channel System with one set of height speakers added. 5.1.2 ch (Front High or Rear High) ( →p28) 5.1.2 ch (Top Front or Top Middle or Top Rear) 5.1.2 ch (Dolby Enabled Speakers (Front or ( →p28) Surround)) ( →p28)
  • Page 23 Speaker Layout 7.1.2 Channel System A Speaker System that is a 7.1 Channel System with one set of height speakers added. 7.1.2 ch (Front High or Rear High) ( →p29) 7.1.2 ch (Top Front or Top Middle or Top Rear) 7.1.2 ch (Dolby Enabled Speakers (Front or ( →p29) Surround or Surround Back)) ( →p29)
  • Page 24 Speaker Layout 5.1.4 Channel System A Speaker System that is a 5.1 Channel System with two sets of height speakers added. 5.1.4 ch (Front High and Rear High) ( →p30) 5.1.4 ch (Front High and Top Middle) ( →p30) 5.1.4 ch (Front High and Top Rear) ( →p30) 5.1.4 ch (Front High and Dolby Enabled 5.1.4 ch (Top Front and Top Rear) ( →p30) 5.1.4 ch (Top Front and Rear High) ( →p30)
  • Page 25 Speaker Layout 5.1.4 Channel System 5.1.4 ch (Top Front and Dolby Enabled 5.1.4 ch (Top Middle and Rear High) 5.1.4 ch (Dolby Enabled Speakers (Front and Speakers (Surround)) ( →p30) ( →p30) Surround)) ( →p30) 5.1.4 ch (Dolby Enabled Speakers (Front) 5.1.4 ch (Dolby Enabled Speakers (Front) and and Rear High) ( →p30) Top Rear) ( →p30)
  • Page 26 Speaker Installation How the speakers are set up depends on the size and shape of the room, so here we introduce just a basic layout example. The alphabetic symbols used in this chapter represent the following speakers: Front speaker Left Front speaker Right Center speaker powered SubWoofer...
  • Page 27 Speaker Installation „ 5.1 Channel System „ 7.1 Channel System a: 22° to 30°, b: 120° a: 22° to 30°, b: 90° to 110°, c: 135° to 150° FL, FR Place the Left and Right Front Speakers to match ear height. FL, FR Place the Left and Right Front Speakers to match ear height.
  • Page 28 Speaker Installation „ 5.1.2 Channel System Top Speakers High Speakers a: 22° to 30° b: 120° 3´ (0.9 m) a: 30° to 55° b: 65° to 100° or more c: 125° to 150° 3´ (0.9 m) or more TFL, TFR Fit top front speakers on the ceiling in front of the listening position. TML, TMR Fit top middle speakers on the ceiling directly above the listening position.
  • Page 29 Speaker Installation „ 7.1.2 Channel System Top Speakers High Speakers a: 22° to 30° b: 90° to 110° c: 135° to 150° 3´ (0.9 m) a: 30° to 55° b: 65° to 100° or more c: 125° to 150° 3´ (0.9 m) or more TFL, TFR Fit top front speakers on the ceiling in front of the listening position.
  • Page 30 Speaker Installation „ 5.1.4 Channel System Top Speakers High Speakers a: 22° to 30° b: 120° 3´ (0.9 m) a: 30° to 55° b: 65° to 100° or more c: 125° to 150° 3´ (0.9 m) or more TFL, TFR Fit top front speakers on the ceiling in front of the listening position. TML, TMR Fit top middle speakers on the ceiling directly above the listening position.
  • Page 31 Speaker Connections (Before starting the procedure) Speakers you can use with this unit and cable connections 4-16 5.1 Channel System 34, 35, 36 Speaker Connections 7.1 Channel System 37, 38, 39 5.1.2 Channel System 40, 41, 42 7.1.2 Channel System 5.1.4 Channel System Connecting a Power Amplifier 5.1ch...
  • Page 32 Speaker Connections Speakers you can use with this unit and cable connections „ Speakers you can use with this unit This unit supports speakers with 4 Ω to 16 Ω impedance. For speaker impedance, check the speaker instruction manual. „ (Note) Speaker Impedance If any of the speakers to be connected has an impedance of 4 Ω...
  • Page 33 Speaker Connections „ Connect the Subwoofer a Subwoofer cable Connect a powered subwoofer with this unit using a subwoofer cable. Up to two powered subwoofers can be connected. The same signal is output from each SUBWOOFER PRE OUT jack. 5.1ch 7.1ch 5.1.2ch 7.1.2ch...
  • Page 34 Speaker Connections „ 5.1 Channel System 5.1ch 7.1ch 5.1.2ch 7.1.2ch 5.1.4ch...
  • Page 35 Speaker Connections „ 5.1 Channel System + ZONE SPEAKER Main Room Zone 2 Zone 3 FL(Z2) FR(Z2) FL(Z3) FR(Z3) 5.1ch FR(Z2) FL(Z2) FR(Z3) FL(Z3) 7.1ch To output audio from an externally connected AV component to ZONE 3, use an analog audio cable for connection. Note that ZONE 3 output is not possible with the connection using a HDMI cable, digital coaxial cable, or digital optical cable.
  • Page 36 Speaker Connections „ 5.1 Channel System (Bi-Amping the Speakers) For high- frequency 5.1ch For low- frequency 7.1ch Be sure to remove the jumper bar connecting between the woofer jacks and tweeter jacks of the Bi-Amping supported speakers. Refer to the instruction manual of your speakers as well.
  • Page 37 Speaker Connections „ 7.1 Channel System 5.1ch 7.1ch 5.1.2ch 7.1.2ch 5.1.4ch...
  • Page 38 Speaker Connections „ 7.1 Channel System + ZONE SPEAKER Main Room Zone 2 FL(Z2) FR(Z2) 5.1ch FR(Z2) FL(Z2) 7.1ch 5.1.2ch 7.1.2ch 5.1.4ch...
  • Page 39 Speaker Connections „ 7.1 Channel System (Bi-Amping the Speakers) For high- frequency 5.1ch For low- frequency 7.1ch Be sure to remove the jumper bar connecting between the woofer jacks and tweeter jacks of the Bi-Amping supported speakers. Refer to the instruction manual of your speakers as well.
  • Page 40 Speaker Connections „ 5.1.2 Channel System 5.1ch 7.1ch 5.1.2ch 7.1.2ch *1 Connect the Height Speakers you have actually installed (HL/HR: Height Speakers, Top Speakers, Dolby Enabled Speakers). 5.1.4ch...
  • Page 41 Speaker Connections „ 5.1.2 Channel System + ZONE SPEAKER Main Room Zone 2 FL(Z2) FR(Z2) 5.1ch FR(Z2) FL(Z2) 7.1ch 5.1.2ch 7.1.2ch *1 Connect the Height Speakers you have actually installed (HL/HR: Height Speakers, Top Speakers, Dolby Enabled Speakers). 5.1.4ch...
  • Page 42 Speaker Connections „ 5.1.2 Channel System (Bi-Amping the Speakers) For high- frequency 5.1ch For low- frequency 7.1ch 5.1.2ch 7.1.2ch Be sure to remove the jumper bar connecting between the woofer jacks and tweeter jacks of the Bi-Amping supported speakers. Refer to the instruction manual of your speakers as well.
  • Page 43 Speaker Connections „ 7.1.2 Channel System 5.1ch 7.1ch 5.1.2ch 7.1.2ch *1 Connect the Height Speakers you have actually installed (HL/HR: Height Speakers, Top Speakers, Dolby Enabled Speakers). 5.1.4ch...
  • Page 44 Speaker Connections „ 5.1.4 Channel System 5.1ch 7.1ch 5.1.2ch 7.1.2ch *1 Connect the Height Speakers you have actually installed (HL1/HR1: Front Height Speakers, Top (front side) Speakers, Dolby Enabled Speakers (Front)). *2 Connect the Height Speakers you have actually installed (HL2/HR2: Rear Height Speakers, Top (rear side) Speakers, Dolby Enabled Speakers (Surround)). 5.1.4ch...
  • Page 45 Speaker Connections Connecting a Power Amplifier Power amplifier You can connect a power amplifier to the unit and use the unit as a pre-amplifier in order to produce a large volume that cannot be output with the unit only. Connect the speakers to the power amplifier. For details, refer to the power amplifier's instruction manual.
  • Page 46 Connections Notes regarding connections with HDMI cables Connecting the TV Connecting the SUB Monitor Connecting Playback Devices Connecting a TV or Integrated Amplifier in a separate room (Multi-zone) Connecting Antennas Connections Network Connection Connecting External Control Devices Connecting the Power Cord...
  • Page 47 Connections Notes regarding connections with HDMI cables „ (Note) Placement of cables HDMI (High-Definition Multimedia Interface) is a digital interface standard for connecting TVs, projectors, Blu-ray Disc players, game consoles, and other Putting a load on HDMI cables can lead to poor operational performance. Place video components.
  • Page 48 Connections Connecting the TV By connecting a TV to this unit, you can show the video from AV devices connected to this unit on the TV and also play the sound from the TV through this unit. To ARC/eARC TV IN(ARC) If the TV supports the ARC (Audio Return Channel) function(*), use only the HDMI cable to connect with the TV.
  • Page 49 Connections Connecting the SUB Monitor SUB Monitor This unit has multiple HDMI OUT jacks, and another TV or projector can be connected to the HDMI OUT SUB jack. • Switch between MAIN and SUB using the HDMI Main/Sub button on the remote controller ( →p15) or "Quick Menu"...
  • Page 50 Connections Connecting Playback Devices Connections to BD/DVD and GAME with HDMI jacks This is a connection example of an AV component equipped with an HDMI jack. When connecting with an AV component that conforms to the CEC (Consumer Electronics Control) standard, you can use the HDMI CEC function (*) that enables linking with input selectors, etc.
  • Page 51 Connections Connecting a BD/DVD without HDMI Jack Mounted This is a connection example of an AV component unequipped with an HDMI jack. Select cables that match the jacks of the AV component for connection. For example, when video input is connected to the BD/DVD jack, connect the audio input to BD/DVD jack, too.
  • Page 52 Connections Connecting an Audio Component This is a connection example of an audio component. Connect a CD player using an analog audio cable. You can also connect a turntable that has an MM- type cartridge to the PHONO jack. • If the turntable has a built-in phono equalizer, connect it to any of the AUDIO IN jacks other than the PHONO jack.
  • Page 53 Connections Connecting a Video Camera, etc. Connect a video camera, etc. to the AUX Input HDMI jack on the front panel using an HDMI cable. Be sure to insert the HDMI cable all the way in. Video camera a HDMI cable...
  • Page 54 Connections Connecting a TV or Integrated Amplifier in a separate room (Multi-zone) Connecting a TV (ZONE 2) While a disc is played on a Blu-ray Disc player in the main room (where this unit is located), you can play the video and audio of the same Blu-ray Disc player or another AV component on the TV equipped with an HDMI IN jack in a separate room (Zone 2).
  • Page 55 Connections Connecting an Integrated Amplifier (ZONE 2) You can enjoy 2 ch audio in the separate room (Zone 2) while performing playback in the main room (where this unit is located). Use an analog audio cable to connect the ZONE 2 PRE/LINE OUT jacks on this unit to the input jack on an integrated amplifier in the separate room.
  • Page 56 Connections Connecting an Integrated Amplifier (ZONE 3) You can enjoy 2 ch audio in the separate room (Zone 3) while performing playback in the main room (where this unit is located). Use an analog audio cable to connect the ZONE 3 PRE/LINE OUT jacks on this unit to the input jack on an integrated amplifier in the separate room.
  • Page 57 Connections Connecting Antennas Connect the antenna to this unit, and set up the antenna at the best position for listening while receiving radio signals. Attach the indoor FM antenna to the wall using push pins or adhesive tape. (North American (Australian models) models) a AM loop antenna, b Indoor FM antenna...
  • Page 58 Connections Network Connection This unit can be connected to the network using a wired LAN or Wi-Fi (wireless LAN). You can enjoy network functions such as Internet radio by network connection. If connection is made by the wired LAN, connect the router and the ETHERNET jack with the Ethernet cable as shown in the illustration.
  • Page 59 Connections Connecting External Control Devices IR IN/OUT port When connecting a remote control receiver unit consisting of an IR Receiver, etc. to this unit, operation using the remote controller is possible even if the remote control signal is difficult to reach (due to installation in the cabinet, etc.).
  • Page 60 Connections 12V TRIGGER OUT jack When connecting a device equipped with a TRIGGER IN jack such as a BD/ DVD player to this unit, the device can be turned on or set to standby by interlocking the operation on this unit. When the desired input is selected on the unit, power link operation will be activated with a control signal of maximum 12 V/100 mA from the 12V TRIGGER OUT A jack or maximum 12 V/25 mA when using the 12V TRIGGER OUT B or C jack.
  • Page 61 Connections Connecting the Power Cord Connect the power cord after all the connections are completed. • This model includes a removable power cord. Be sure to connect the power cord to the AC INLET of the unit first, and then connect it to the outlet. Always disconnect the outlet side first when disconnecting the power cord.
  • Page 62 Playback Basic Operations Playing audio from an externally connected device BLUETOOTH Playback ® Listening To the Radio Listening Mode Quick Menu Network Services Playback Spotify AirPlay ® DTS Play-Fi ® Amazon Alexa Amazon Music TIDAL Connecting the Sonos System for Playback Internet Radio Convenience functions Multi-zone...
  • Page 63 Playback Playing audio from an externally connected device You can play the audio from AV components, such as Blu-ray disc players through this unit. • When a TV is connected to the HDMI OUT SUB jack, use the HDMI Main/Sub button or "Quick Menu" ( →p73) to switch between MAIN and SUB. Basic Operations Perform the following procedure when this unit is on.
  • Page 64 If a password is requested, enter "0000". • This unit is displayed as "Integra DRX-3.4 XXXXXX". This display can be The illustration shows an image. changed using the Friendly Name function ( →p127) or Integra Control Pro ( →p148) (available on iOS or Android™).
  • Page 65 Playback Transmitting audio from this unit to BLUETOOTH wireless technology enabled devices Pairing 1. Press the input selector you want to play. • Select a source other than "BLUETOOTH". This function does not work if you select "BLUETOOTH". 2. Press the button on the remote controller, select "6.
  • Page 66 Playback Playing Back 1. Do the play operations on the AV component connected to this unit. Do the play operations on this unit when the input is TUNER or NET. • If "Variable" has been selected for the "Output Level", the volume can be adjusted on this unit.
  • Page 67 Playback Listening To the Radio You can receive AM/FM radio stations on this unit with the built-in tuner. Listening To the AM/FM Radio Tuning into a Radio Station Perform the following procedure when this unit is on. „ Tuning Automatically 1.
  • Page 68 Playback Using RDS (Australian models) „ Tuning Manually Note that if you tune manually, the reception for FM broadcasts will be monaural RDS stands for Radio Data System, and is a method of transmitting data in FM rather than stereo, irrespective of the sensitivity of the reception. radio signals.
  • Page 69 Playback • Unusual characters may be displayed when the unit receives unsupported characters. This is not a malfunction. Also, if the signal from a station is weak, information may not be displayed. ‰ Presetting a Radio Station ( →p70)
  • Page 70 Playback Presetting a Radio Station „ Registration Procedure „ Selecting a Preset Radio Station You can preset up to 40 of your favorite radio stations. 1. Press Tuner. After tuning in to the radio station you want to register, perform the following 2.
  • Page 71 Playback Listening Mode This unit is equipped with a variety of listening modes, and you can select the optimum listening mode for movies, TV, music, and games by pressing Movie/TV, Music, and Game. ( →p170) • For details of the effects of each listening mode, refer to "Listening Mode Effects" ( →p176). •...
  • Page 72 Playback Checking the input format and listening mode Repeatedly pressing the button on the remote controller switches the display of the main unit in the following order. • The content displayed depends on the source, BLUETOOTH, etc., being played. • Not all the information is necessarily displayed. Input source and volume Listening mode Input format...
  • Page 73 Playback Quick Menu Menu operations You can quickly adjust the settings you frequently use, such as tone adjustments, etc. You can make the settings on the TV screen during playback. Press Q on the remote controller to display the Quick Menu. Quick Menu BD/DVD HDMI...
  • Page 74 Playback „ HDMI Stereo Assign: This function enables you to select a pair of speakers to output stereo sound. Apart from the front speakers (Front), you can select the Surround HDMI Out: Select the HDMI OUT jack to output video signals from "MAIN", speakers (Surround), Surround Back speakers (Surround Back), Height 1 "SUB", and "MAIN+SUB".
  • Page 75 Playback „ Room EQ „ Level Dirac Live (*1): You can select the equalizers measured with Dirac Live Front: Adjust the speaker level of the front speakers while listening to the sound. →p145, p149) from "Slot1" to "Slot3". When disabling the equalizer, select Center: Adjust the speaker level of the center speaker while listening to the "Off".
  • Page 76 Playback Spotify Use your phone, tablet or computer as a remote control for Spotify. Go to spotify.com/connect to learn how.
  • Page 77 Playback AirPlay ® By connecting this unit to the same network as that of iOS devices such as iPhone , iPod touch and iPad , you can enjoy music files on iOS devices wirelessly. ® ® ® • Update the OS version on your iOS device to the latest version. •...
  • Page 78 AirPlay-enabled iPhone device. Integra DRX- XXXXXX You can also play the music files on a PC with iTunes (Ver. 12.8 or later) Integra XXXXXXXX equipped. Confirm that this unit and the PC are connected to the same network Integra XXXXXXXX beforehand.
  • Page 79 "Group playback" that plays the same music in https://integrahometheater.jp/playfi/info_i.html separate rooms at home. To enjoy this function, download Integra Music Control • To use a music streaming distribution service, user registration may be App (available on iOS or Android™).
  • Page 80 Refer to "Integra Control Pro" ( →p148) for information about the app. 2. Start Integra Control Pro and tap the unit when displayed. 3. Tap "NET" or "NETWORK" at the top of the Integra Control Pro screen, and after switching to the network menu, tap the "amazon alexa" icon.
  • Page 81 Operating this unit (*1) Log in using the same account as other terminals with Amazon Alexa. 7. When registration is finished, the screen returns to the one for Integra Control Pro. Follow the on screen instructions and talk to the terminal with You can use voice commands to adjust the volume on this unit, start and stop Amazon Alexa (an Amazon Echo, etc.), and confirm that you can use voice...
  • Page 82 Playback Amazon Music Registering This Unit with Amazon Music 1. Register with the Amazon account on Integra Control Pro. This cannot be set with operations on this unit. Refer to "Integra Control Pro" ( →p148) for information about the app.
  • Page 83 Playing Amazon Music using the Integra Control Pro 1. Start up Integra Control Pro. This unit is automatically displayed after startup. Then, tap and select this unit displayed. 2. Tap "NET" or "NETWORK" on the upper part of the screen to switch to the network screen.
  • Page 84 Registering this unit with TIDAL allows you to enjoy the music distribution service provided by TIDAL. You can register this unit on the screen of Integra Control Pro by downloading Integra Control Pro (available on iOS or Android™) to mobile devices such as a smartphone and tablet.
  • Page 85 Playback Connecting the Sonos System for Playback How to Connect This Unit and Sonos Connect 1. Connect the Sonos Connect to the AUDIO IN jack of this unit with the RCA audio cable supplied with the Sonos Connect. Any input jacks other than the PHONO jack can be used.
  • Page 86 Playback • Up to 32 devices can be displayed on the Sonos product list screen. If you cannot find the Sonos Connect to be interlocked, return to the previous screen, turn off the product you do not want to interlock, and try again. Output Zone: With the cursors / , select the ZONE where you want to listen to the...
  • Page 87 Playback Internet Radio By connecting this unit to an Internet-connected network, you can enjoy Internet radio services such as TuneIn Radio. • To play Internet radio services, the network needs to be connected to the Internet. • Depending on the Internet radio service, a user registration may be required on your PC beforehand. For details of each service, visit the website of each service. Playing Back Perform the following procedure when this unit is on.
  • Page 88 Playback Internet Radio Service Menu You can bookmark specific stations, or delete stations that have been bookmarked. The displayed menu varies according to the service being selected. The menu icon is displayed while a station is being played. When only this icon is displayed, pressing Enter will display the menu on the screen.
  • Page 89 "BLUETOOTH". You cannot select different stations of AM/FM broadcasts for the main room and separate room. Using Integra Control Pro ( →p148) is convenient for operations of multi-zone playback. You can use it on mobile devices, such as a smartphone and tablet to which Integra Control Pro (available on iOS or Android™) has been downloaded.
  • Page 90 Playback Playing Back (ZONE 2) In remote controller operation, while pressing and holding the Zone 2 Shift button, press other buttons for operation. 1. While pressing and holding the Zone 2 Shift button on the remote controller, point the remote controller at this unit and press . •...
  • Page 91 Playback • The audio from externally connected AV components can be output to ZONE 2 only when the audio is analog or 2 ch PCM signal. When the AV component is connected to this unit with an HDMI cable, digital coaxial cable or digital optical cable, change the audio output of the AV component to the PCM output.
  • Page 92 Playback Playing Back (ZONE 3) In remote controller operation, while pressing and holding the Zone 3 Shift button, press other buttons for operation. Settings are required to playback a source in ZONE 3. When outputting from the speakers: Set "2. Speaker" - "Configuration" - "Zone Speaker"...
  • Page 93 Playback • For ZONE 3 output, audio from externally connected AV components can be output only when it is an analog audio signal. • DSD audio signals cannot be output to ZONE 3 with the "NET" input selector. • If ZONE 3 is on, power consumption during standby will increase. •...
  • Page 94 Playback Playing different audio and video Displaying Your Favorite Video on TV While Playing Music While listening to the music from a CD or BLUETOOTH enabled device, you can display video on TV from an AV component such as a Blu-ray Disc player. •...
  • Page 95 Playback Playing music files saved on a USB storage device You can play music files stored on a USB storage device. Perform the following procedure when this unit is on. 1. Switch the input on the TV to the input connected to the unit. 2.
  • Page 96 Playback USB Storage Device Requirements • When playing files recorded with VBR (Variable bit-rate), the playback time may not be displayed correctly. • This unit supports the gapless playback of the USB storage device in the • This unit can use USB storage devices that comply with the USB mass following conditions.
  • Page 97 Playback Music Server Streaming play of music files stored on PCs or NAS devices connected to the same network as this unit is supported. • The network servers this unit is compatible with are those PCs with players installed that have the server functionality of Windows Media Player 12, or NAS that ®...
  • Page 98 Playback Playing Back Perform the following procedure when this unit is on. 1. Switch the input on the TV to the input connected to the unit. TV’s REMOTE 2. Start the server (Windows Media Player 12 or NAS device) containing the ®...
  • Page 99 Playback Controlling Remote Playback from a PC 6. Select the target server with the cursors, and press Enter to display the items list screen. You can use this unit to play music files stored on your PC by operating the PC •...
  • Page 100 The Play Queue information is effective until the power cord of this unit is removed from the outlet. Refer to "Integra Control Pro" ( →p148) for information about the app.
  • Page 101 Playback 2. Tap the " " icon of the track to sort, and drag the icon to the destination. 3. To delete a track, slide the track to the left until the trash icon changes to " ". If the device is on iOS, slide the " "...
  • Page 102 Playback Connecting a transmitter for playback When you connect wireless headphones or a wireless speaker transmitter to the ZONE B LINE OUT jacks of this unit, you can play back the same source through the wireless headphones or wireless speakers as in the main room. Connections Setting Up 1.
  • Page 103 Setup Setup Menu Web Setup Initial Setup with Auto Start-up Wizard Integra Control Pro Dirac Live Setup...
  • Page 104 Setup Setup Menu Use the on-screen displays (OSD) that appear on the TV to make the settings. Setup Press on the remote controller to display the Setup menu. Select the item with the cursors of the remote controller, and press the Enter button to confirm your selection. 1.
  • Page 105 Setup 4. Source 1. My Input Volume Set a volume value for each input selector. p121 2. Name Edit Set an easy name for each input. p121 Audio Select Select the prioritized input terminal when multiple audio sources are connected to one input p121 selector.

  • Page 106: Firmware Update

    Setup 7. Multi Zone 1. Zone 2 Change the settings for Zone 2. p137 2. Zone 3 p137 Change the settings for Zone 3. 3. Remote Play Zone Change the settings for remote play. p138 8. Miscellaneous 1. Tuner Change the settings for Tuner. p139 2.
  • Page 107 Setup Setup 1. Input/Output Assign 1. Input/Output Assign „ 1. TV Out / OSD ‰ Upscaling (Default Value: Off) When a TV supporting 4K/8K is used, video signals input with 1080p can be Make settings for TV output and On-Screen Displays (OSD) that appear on the automatically output with 4K/8K.
  • Page 108 Setup Setup 1. Input/Output Assign ‰ HDMI 4K/8K Signal Format ‰ Zone 2 HDMI (Default Value: Not Use) Set the 4K/8K signal format input and output by this unit. Set to suit the TV or Make the setting when you output to the ZONE 2 TV connected to the HDMI player connected.
  • Page 109 Setup Setup 1. Input/Output Assign „ 2. HDMI Input ‰ Mini Player OSD (Default Value: Always On) You can display on the TV the images from another input selected last while You can change input assignment between the input selectors and HDMI IN playing the audio from NET or BLUETOOTH input.
  • Page 110 Setup Setup 1. Input/Output Assign „ 3. Video Input „ 4. Digital Audio Input Change input assignment between the input selectors and COMPONENT Change input assignment between the input selectors and DIGITAL IN VIDEO IN jacks and the VIDEO IN jacks. If you do not assign a jack, select "---". COAXIAL/OPTICAL jacks.
  • Page 111 Setup Setup 1. Input/Output Assign „ 5. Analog Audio Input Change input assignment between the input selectors and AUDIO IN jacks. If you do not assign a jack, select "---". ‰ BD/DVD (Default Value: AUDIO 1) GAME (Default Value: AUDIO 2) CBL/SAT (Default Value: AUDIO 3) STRM BOX (Default Value: AUDIO 4)
  • Page 112 Setup Setup 2. Speaker 2. Speaker „ 1. Configuration ‰ Height 1 Speaker (Default Value: Top Middle) Change the settings of connection environment of the speakers. Set the speaker type if height speakers are connected to the HEIGHT 1 • If the settings for "Speaker Channels", "Subwoofer", "Height 1 Speaker", or terminals.
  • Page 113 Setup Setup 2. Speaker ‰ Height 2 Speaker (Default Value: Rear High) ‰ Zone 2 Preout (Default Value: Zone 2) Set an output destination of the audio output from ZONE 2 PRE/LINE OUT/ Set the speaker type if height speakers are connected to the HEIGHT 2 ZONE B LINE OUT jack.
  • Page 114 Setup Setup 2. Speaker „ 2. Crossover Surround Back: Select the crossover frequency from "40 Hz" to "200 Hz" to start outputting Change the settings of crossover frequencies. frequencies for each channel. • As for the THX-certified speakers, the following settings are recommended. "Full Band": Full band will be output.
  • Page 115 Setup Setup 2. Speaker „ 3. Distance „ 4. Level Calibration Set the distance from each speaker to the listening position. Adjust the volume level of each speaker. ‰ Front Left (Default Value: 12.0 ft/3.60 m) ‰ Front Left (Default Value: 0.0 dB) Center (Default Value: 12.0 ft/3.60 m) Center...
  • Page 116 Setup Setup 2. Speaker „ 5. Dolby Enabled Speaker „ 6. Equalizer Settings Change the settings of Dolby Enabled Speakers. You can adjust the output volume of the range for each connected speaker. • This setting can be selected when "Configuration" - "Height 1 Speaker" / Adjust the volume of different sound ranges for each speaker.
  • Page 117 Setup Setup 2. Speaker „ 7. Speaker Virtualizer The Speaker Virtualizer function can be switched between On and Off. ‰ Speaker Virtualizer (Default Value: On) Listening modes such as T-D that have virtual speaker effects can be selected. Listening modes such as T-D that have virtual speaker effects cannot be selected.
  • Page 118 Setup Setup 3. Audio Adjust 3. Audio Adjust „ 1. Multiplex/Mono „ 2. Dolby Change the settings of multiplex audio playback. Change the setting of when Dolby signals are input. ‰ Multiplex Input Channel (Default Value: Main) ‰ Loudness Management (Default Value: On) Set the audio channel or language to be output when playing multiplex audio or When playing Dolby TrueHD, enable the dialog normalization function which multilingual broadcasts, etc.
  • Page 119 Setup Setup 3. Audio Adjust „ 3. DTS/IMAX ‰ IMAX User Setting (Default Value: Auto) When playing IMAX content with the IMAX sound mode, select whether to Change the setting of when DTS signals are input. automatically apply the speaker setting recommended by IMAX or to set it ‰...
  • Page 120 Setup Setup 3. Audio Adjust „ 4. LFE Level Set the low-frequency effect (LFE) level for Dolby Digital series, DTS series, Multichannel PCM, and DSD signals. ‰ LFE Level (Default Value: 0 dB) Select the low-frequency effect (LFE) level of each signal from "0 dB" to "-∞ dB".
  • Page 121 Setup Setup 4. Source 4. Source „ 1. My Input Volume „ Audio Select Set a volume value for each input selector. Select the priority for input selection when multiple audio sources are connected to one input selector, such as connections to both the "BD/DVD" HDMI IN jack ‰...
  • Page 122 Setup Setup 4. Source „ Video Select Analog When giving priority to the input signal from AUDIO IN jacks • This item can be selected only when the input to be set When "TUNER", "NET", or "BLUETOOTH" input is selected, you can set the is assigned to the AUDIO IN jack in the "1.
  • Page 123 Setup 5. Listening Mode Preset You can preset your favorite listening mode to each input. (For example, you can always apply straight decode to the Dolby TrueHD source of Blu-ray Disc to play it in unchanged sound field.) When the list of input sources is displayed, set the signal type and listening mode.
  • Page 124 Setup 6. Hardware „ 1. HDMI ‰ HDMI Standby Through (Default Value: Auto (Eco)) When this is set to anything other than "Off", you can play the video and audio of Change the settings of the HDMI function. an HDMI-connected player on the TV even if the unit is in standby mode. Also, ‰...
  • Page 125 Setup Setup 6. Hardware ‰ Audio TV Out (Default Value: Auto) ‰ Audio Return Channel (eARC supported) (Default Value: On) You can enjoy audio through the speakers of the TV while this unit is on. You can enjoy the sound of an HDMI-connected ARC-compatible TV or eARC- •...
  • Page 126 Setup Setup 6. Hardware „ 2. Network ‰ DHCP (Default Value: Enable) Change the settings of the Network function. Enable Auto configuration by DHCP • When LAN is configured with a DHCP, set "DHCP" to "Enable" to configure Disable Manual configuration without DHCP the setting automatically.
  • Page 127 6. Hardware ‰ Friendly Name (Default Value: Integra DRX-3.4 XXXXXX) ‰ AirPlay Device Name (Default Value: Integra DRX-3.4 XXXXXX) Change the model name of this unit which is displayed on the device Change the model name of this unit which is displayed on the AirPlay- connected to the network to an easily recognized name.
  • Page 128 Setup Setup 6. Hardware ‰ AirPlay Password (Default Value: -) ‰ Privacy Statement (Default Value: Not Accepted) You can set a password of up to 31 characters so that only users that have When using a network service that requires a login name, email address, input can use AirPlay.
  • Page 129 Setup Setup 6. Hardware „ 3. Bluetooth ‰ Pairing Information (Default Value: -) You can initialize the pairing information stored on this unit. If you are no longer Change the settings for the BLUETOOTH function. able to connect with a device you have paired, try doing this. ( →p160) •...
  • Page 130 Setup Setup 6. Hardware ‰ Search Devices (Default Value: -) ‰ Pairing Information (Default Value: -) You can initialize the pairing information stored on this unit. If you are no longer Search for a BLUETOOTH wireless technology enabled device that is able to able to connect with a device you have paired, try doing this.
  • Page 131 Standby" or "Network Standby" is enabled, the unit enters the Hybrid Standby application such as Integra Control Pro that can control this unit. mode which minimizes the increase in power consumption.) •...
  • Page 132 Setup Setup 6. Hardware „ 5. 12V Trigger A ‰ Bluetooth Wakeup (Default Value: Off) This function wakes up the unit on standby by connecting a BLUETOOTH Set when outputting the control signal (maximum 12V/100 mA) through the 12V enabled device. This is effective when "Bluetooth" - "Bluetooth Receiver" is set TRIGGER OUT A jack.
  • Page 133 Setup Setup 6. Hardware „ 6. 12V Trigger B Zone 3 When controlling the power of external devices linked to the input selection in ZONE 3 Set when outputting the control signal (maximum 12V/25 mA) through the 12V Main/Zone 3 When controlling the power of external devices linked to the TRIGGER OUT B jack.
  • Page 134 Setup Setup 6. Hardware „ 7. 12V Trigger C Zone 3 When controlling the power of external devices linked to the input selection in ZONE 3 Set when outputting the control signal (maximum 12V/25 mA) through the 12V Main/Zone 3 When controlling the power of external devices linked to the TRIGGER OUT C jack.
  • Page 135 Setup Setup 6. Hardware „ 8. Works with SONOS Zone 3 When controlling the power of external devices linked to the input selection in ZONE 3 Change the settings to connect with the Sonos Connect. Main/Zone 3 When controlling the power of external devices linked to the (SONOS-1/SONOS-2/SONOS-3) input selection in the main room or in ZONE 3 ‰...
  • Page 136 Setup Setup 6. Hardware ‰ Output Zone (Default Value: Main) Select the zone where you want to listen to the music. • To use this function, set "Input Selector" beforehand. Main Outputs audio only to the main room (where this unit is located).
  • Page 137 Setup Setup 7. Multi Zone 7. Multi Zone „ 1. Zone 2 „ 2. Zone 3 Change the settings for Zone 2. Change the settings for Zone 3. ‰ Output Level (Default Value: Fixed) ‰ Output Level (Default Value: Fixed) Select whether to adjust the volume on the integrated amplifier in the separate Select whether to adjust the volume on the integrated amplifier in the separate room or on this unit when outputting to the separate room (Zone 2).
  • Page 138 Setup Setup 7. Multi Zone „ 3. Remote Play Zone Change the settings for remote play. ‰ Remote Play Zone (Default Value: Auto) When playing with AirPlay or Spotify Connect, or when using the Music Server function to play remotely from your PC, you can set whether to play in the main room (where this unit is located) or in a separate room (Zone 2/Zone 3).
  • Page 139 ‰ Remote ID (Default Value: 1) Press Enter to select when updating the firmware via USB. If multiple Integra/ONKYO products are installed in the same room, select the • This setting cannot be selected if a USB storage device is not connected or ID for the remote control used with this unit from "1", "2"...
  • Page 140 Setup Setup 8. Miscellaneous „ 4. Initial Setup Make the initial setup from the setup menu. • Wait for a while if "Initial Setup" cannot be selected. It can be selected when the network function is activated. „ 5. Lock Lock the Setup menu so that the settings cannot be changed.
  • Page 141 Setup Web Setup Menu operations Device Information You can make the settings for the network function of this unit using an Internet browser on a PC, smartphone, etc. You can change the Friendly Name or AirPlay Device Name, set an AirPlay Password, etc.
  • Page 142 Setup Initial Setup with Auto Start-up Wizard Operations When you turn the unit on for the first time after purchase, the Initial Setup screen is automatically displayed on the TV to allow you to make settings TV’s REMOTE required for startup using simple operations following on-screen guidance. Inputs 1.
  • Page 143 Setup Network Connection Keyboard Input 1. A confirmation screen asking you whether to agree to the privacy statement To switch between upper and lower cases, select "A/a" on the screen, and press is displayed during network setting. If you agree, select "Accept" and press Enter on the remote controller.
  • Page 144 Initial Setup. „ When measuring with Dirac Live Download the Integra Control Pro to your mobile device and use the app to operate the measurements. For details on how to measure with Dirac Live, refer to "Measuring with Dirac Live" ( →p145).
  • Page 145 4. Tap "Next", confirm that the displayed speaker configuration is correct, then tap "Next". Use the Integra Control Pro to use Dirac Live to take measurements. Use the • If the number of speaker channels set in "1.Speaker Setup" in Initial Setup most recent version.
  • Page 146 Setup 6. The guidance about outputting the test tone is displayed. Refer to the illustration to set up the speaker setup microphone in the listening position. Follow the on-screen instructions to measure. • Measurement may not be possible if the test tone is too loud or too soft. Tap "Level Adjust"...
  • Page 147 Setup „ Measuring with AccuEQ Room Calibration • When it cannot be resolved by performing the re-measurement, confirm if the speakers are connected correctly. If there is any problem with the Place the supplied speaker setup microphone at the listening position. The unit speaker connection, perform the connection after disconnecting the power automatically measures the test tones output from each speaker, and sets the cord.
  • Page 148 (internet radio or play of a music file) without looking at the TV. • To use Integra Control Pro, this unit needs to be connected to the same network as the mobile device.
  • Page 149 "Quick" which measures 3 locations; at the listening position Use the Integra Control Pro to use Dirac Live to take measurements. Use the and to the left and right of the listening position; and "Full" which measures 9 most recent version.
  • Page 150 1. Start the Integra Control Pro and tap the unit when displayed. 2. Tap " " in the top left of the Integra Control Pro screen to display a list of menus, then tap "Manual Adjust". 3. Select the slot to modify from "Slot1" to "Slot3", then tap "Next".
  • Page 151 Setup 1 The speaker currently being adjusted. To adjust another speaker, tap the " " next to it and select another speaker. 2 Displays the Menu screen. From the menu, you perform actions such as reset the speaker adjustments and cancel and exit the adjustments. You can also copy data from other slots.
  • Page 152 Troubleshooting Before starting the procedure When the unit is operating erratically Try restarting the unit Resetting the unit (this resets the unit settings to the default) Troubleshooting „ Power Troubleshooting „ Audio „ Listening Modes „ Video „ Linked operation „...
  • Page 153 Troubleshooting Before starting the procedure Problems may be solved by simply turning the power on/off or disconnecting/ connecting the power cord, which is easier than working on the connection, setting and operating procedure. Try the simple measures on both the unit and the connected device.
  • Page 154 Troubleshooting When the unit is operating erratically ‰ Try restarting the unit ‰ Resetting the unit (this resets the unit settings to the default) Restarting this unit may solve the problem. Set the main unit to standby, then after waiting for 5 seconds or more, press and hold the On/Standby button of If the restart of the unit does not solve the problem, reset the unit, and restore the main unit for at least 5 seconds, and then restart the unit.

  • Page 155: Troubleshooting

    Troubleshooting Troubleshooting „ Power ‰ When the power is turned on, "AMP Diag Mode" appears on the display of the main unit • The protection circuit function may have operated. If the unit suddenly enters the standby state and "AMP Diag Mode" appears on the display of the main unit when the power is turned on again, this function is diagnosing whether or not the main unit is malfunctioning or there is an abnormality with the speaker cable connection.
  • Page 156 Troubleshooting ‰ No sound from the TV • Change the input selector on this unit to the position of the terminal to which the TV is connected. • If the TV doesn't support the ARC function, along with connection by HDMI, connect the TV and this unit using a digital optical cable or analog ( →p48) audio cable.
  • Page 157 Troubleshooting ‰ Noise can be heard • Using cable ties to bundle analog audio cables, power cords, speaker cables, etc. may degrade the audio performance. Do not bundle the cords. • An audio cable may be picking up interference. Change the position of the cables. ‰...
  • Page 158 Troubleshooting ‰ About Dolby signals • When surround back speakers are included in the speaker layout, and software that is recorded with the 5.1-channel Dolby audio format is played, the surround channel audio may be output from the surround back speakers. •...
  • Page 159 Troubleshooting ‰ No image from a device connected to HDMI IN jack • To display video from the connected player on the TV while the unit is in standby, you need to enable "6. Hardware" - "HDMI" - "HDMI Standby ( →p124) Through"...
  • Page 160 Troubleshooting „ Tuner ‰ Poor reception or much noise • Recheck the antenna connection. ( →p57) • Move the antenna away from the speaker cord or power cord. • Move the unit away from your TV or PC. • Passing cars or airplanes in the vicinity can cause interference. •...
  • Page 161 Troubleshooting ‰ Cannot transmit from this unit to a BLUETOOTH wireless technology enabled device (wireless headphones, etc.) • Check that the "Bluetooth Transmitter" setting on this unit is set to either "On(Tx)" or "On(Main + Tx)". ( →p129) ‰ Cannot connect this unit to a BLUETOOTH wireless technology enabled device (wireless headphones, etc.) •...
  • Page 162 Troubleshooting „ Network function • If you cannot select a network service, start up the network function to select it. It may take approx. one minute to start it up. • When the NET indicator is blinking, this unit is not properly connected to the home network. •...
  • Page 163 Troubleshooting „ USB storage device ‰ USB storage device is not displayed • Check if the USB storage device or USB cable is securely inserted to the USB port of the unit. ( →p95) • Disconnect the USB storage device once from the unit, and then reconnect it. •...
  • Page 164 Troubleshooting „ ZONE B function ‰ Cannot output audio to ZONE B • To output audio to ZONE B, set the audio output destination for "Audio" - "Zone B" on Quick menu to "On (A+B)" or "On (B)" and also set ( →p102) "2.
  • Page 165 Troubleshooting „ Others ‰ Strange noise can be heard from the unit • If you have connected another device to the same outlet as this unit, strange noise may occur under the influence of the device. If the symptom is remedied by removing the power plug of the other device from the outlet, use different outlets for this unit and the device. ‰...
  • Page 166 Appendix Speaker Layouts and Selectable Listening Modes Listening Mode buttons and Selectable Listening Modes Input Formats and Selectable Listening Modes Listening Mode Effects Speaker Combinations General Specifications Appendix...
  • Page 167 Appendix Speaker Layouts and Selectable Listening Modes See the following table for selectable listening modes for each speaker layout. Speaker layout (ch) Listening mode 2.1.2 3.1.2 4.1.2 5.1.2 6.1.2 7.1.2 4.1.4 5.1.4 (*2) (*2) DD (Dolby Audio - DD) (*1) (*1) (*1) (*2)
  • Page 168 Appendix Speaker layout (ch) Listening mode 2.1.2 3.1.2 4.1.2 5.1.2 6.1.2 7.1.2 4.1.4 5.1.4 (*3) (*3) (*3) (*3) (*3) (*3) (*3) ES Discrete (DTS-ES Discrete) ES Matrix (DTS-ES Matrix) DTS 96/24 (*3) (*3) (*3) (*3) (*3) (*3) (*3) DTS-HD HR (DTS-HD High Resolution) DTS-HD Master (DTS-HD Master Audio) DTS Express DTS:X...
  • Page 169 Appendix Speaker layout (ch) Listening mode 2.1.2 3.1.2 4.1.2 5.1.2 6.1.2 7.1.2 4.1.4 5.1.4 Multich (Multichannel) (*1) (*1) (*1) (*1) (*1) (*3) (*3) (*3) (*3) (*3) (*3) (*3) (*3) (*3) (*1) (*1) (*1) (*5) (*5) (*3) (*3) (*3) (*3) (*3) (*5) (*5) (*1)
  • Page 170 Appendix Listening Mode buttons and Selectable Listening Modes Refer to the following table for the listening modes that can be selected with each listening mode button. Listening Mode buttons Listening Mode buttons Listening mode Movie/TV Music Game Listening mode Movie/TV Music Game DD (Dolby Audio - DD)
  • Page 171 Appendix Listening Mode buttons Listening mode Movie/TV Music Game Unplugged Game-RPG Game-Action Game-Rock Game-Sports AllCh Stereo Mono Music T-D (Theater-Dimensional)
  • Page 172 Appendix Input Formats and Selectable Listening Modes You can select a variety of listening modes Listening mode DTHD according to the audio format of the signal to be DSur Direct (Dolby Audio (Dolby Atmos input. (Dolby Audio (Dolby Audio Stereo - DD+) Audio - (*12)
  • Page 173 Appendix Listening mode DTS-HD HR DTS-HD ES Discrete ES Matrix IMAX DTS 96/24 (DTS-HD High Master (DTS- (DTS-ES IMAX DTS IMAX DTS (*2) Express (DTS-ES DTS:X Neural:X Neural:X (*2) Resolution) HD Master Discrete) (*10) DTS:X (*10) (*2) Matrix) (*5) (*6) (*10) Input format (*2)
  • Page 174 Appendix Listening mode Orchestra/ Unplugged/ AllCh T-D (Theater- Studio-Mix/ TV Logic/ Game- Stereo / (Multich Mono Dimensional) (*2)(*11) Action/ Game-Rock/Game- Mono Music PCM) (*2) (*9) Input format RPG/ Game-Sports (*7) (*8) 2-channel signal input Analog / PCM Music file / DSD (*1) DD / DD+ / DTHD DTS / DTS 96/24 / DTS Express / DTS-HD HR /...
  • Page 175 Appendix (*1) You cannot select any mode other than Stereo, AllCh Stereo and Mono Music if the sampling rate is 5.6/11.2 MHz. (*2) A center speaker or surround speakers need to be installed. (*3) If the input source is Blu-ray Disc and the speaker layout is 5.1 ch or less, DD+ cannot be selected. Instead, the listening mode for DD can be selected. (*4) This can only be selected when no surround back speaker is connected.
  • Page 176 Appendix Listening Mode Effects In alphabetical order "4.1.4 ch" or "5.1.4 ch" setting with surround speakers and height speakers installed. „ AllCh Stereo • To enable transfer of this audio format, connect via an HDMI cable and set This mode is ideal for background music. Stereo sound is played through the the audio output on the player to Bitstream output.
  • Page 177 Appendix „ Direct DTHD (Dolby Audio - TrueHD) „ This listening mode can be selected for all input signals. Processing that affects This mode faithfully reproduces the sound design recorded in the Dolby TrueHD sound quality is shut down, and sound closer to the original is reproduced. The audio format.
  • Page 178 Appendix „ DTS 96/24 • To enable transfer of this audio format, connect via an HDMI cable and set the audio output on the player to Bitstream output. This mode faithfully reproduces the sound design recorded in the DTS 96/24 „...
  • Page 179 Appendix „ ES Discrete (DTS-ES Discrete) „ IMAX This mode faithfully reproduces the sound design recorded in the DTS-ES IMAX is an innovator in entertainment technology, combining proprietary Discrete audio format. software, architecture and equipment to create experiences that take you DTS-ES Discrete is an optional audio format based on 5.1 ch for DVD-Video beyond the edge of your seat to a world you've never imagined.
  • Page 180 Appendix „ T-D (Theater-Dimensional) • IMAX Mode is set to "Auto" at the time of purchase ( →p119). The listening mode automatically switches when IMAX Enhanced content is recognized, In this mode, you can enjoy a virtual playback of multichannel surround sound but when playing IMAX Enhanced content received through streaming even with only two or three speakers.
  • Page 181 Appendix Speaker Combinations • Up to two powered subwoofers can be connected in either combination. ZONE 2 (*1) ZONE 3 (*1) Speaker SURROUND FRONT CENTER SURROUND HEIGHT 1 HEIGHT 2 Bi-AMP (*1) (ZONE (ZONE Channels BACK SPEAKER) SPEAKER) 2.1 ch 3.1 ch 4.1 ch 5.1 ch...
  • Page 182 Appendix General Specifications Amplifier Section North American models Australian models With 8 ohm loads, both channels driven, from 20- 20,000 Hz; rated 100 watts per channel minimum 9 ch × 175 W at 6 ohms, 1 kHz, 1 ch driven of 1% THD Rated Output Power RMS power, with no more than 0.08% total harmonic (IEC)
  • Page 183 Appendix Video Section North American models Australian models 1 Vp-p/75 Ω (Composite Video) Signal level 1 Vp-p/75 Ω (Component Video Y) 0.7 Vp-p/75 Ω (Component Video Pb/Pr) Correspoinding maximum resolution 480i/576i Tuner Section North American models Australian models FM Tuning Frequency Range 87.5 MHz - 107.9 MHz 87.5 MHz - 108.0 MHz, RDS 50 dB quieting sensitivity (FM MONO)
  • Page 184 Appendix HDMI North American models Australian models Input 7 (Including 1× Front) Output 2 (MAIN, SUB/ZONE2) Input *1 Output HDMI SUB/Zone2 HDMI 1 HDMI 2 HDMI 3 HDMI 4 HDMI 5 HDMI 6 MAIN Zone2 (Front) HDMI Ver bandwidth 40Gbps 40Gbps 40Gbps 24Gbps...
  • Page 185 Appendix Corresponding Frame rate Color space Color depth HDMI IN 1 - 3 HDMI IN 4 - 6 AUX Input HDMI (Front) input resolutions 24/25/30 Hz YCbCr4:2:2 12 bit (3840x2160p) YCbCr4:4:4/RGB 8 bit 10/12 bit 4K SMPTE 48/50/60 Hz YCbCr4:2:0 8 bit (4096x2160p) 10/12 bit...
  • Page 186 Operation has been confirmed on the following devices: (As of April 2020) Toshiba brand televisions; Sharp brand televisions; Onkyo and Integra brand RIHD-compatible players; Toshiba brand players and recorders; Sharp brand players and recorders (when used with a Sharp brand television)
  • Page 187 Appendix USB Section North American models Australian models 1 (Rear : Ver.2.0, 5V/1 A) MP3 (.mp3) • MPEG-1/MPEG-2 Audio Layer-3/44.1 kHz, 48 kHz/Between 8 kbps and 320 kbps, and VBR WMA (.wma) • 44.1 kHz, 48 kHz/Between 5 kbps and 320 kbps, and VBR •...

  • Page 188: Hdmi Cec ( →P124)

    Appendix General North American models Australian models Power Supply AC 120 V, 60 Hz AC 220 - 240 V, 50/60 Hz Power Consumption 750 W 760 W Full Standby mode 0.1 W 0.15 W Network Standby (wired) 1.6 W 1.7 W Network Standby (wireless) 1.7 W 1.7 W...
  • Page 189 Appendix Audio Inputs North American models Australian models Analog 8 (Including 1×PHONO, 1×AUX(Front)) Digital 2 (COAXIAL×1, OPTICAL×1) Audio Outputs North American models Australian models LINE OUT (ZONE 2)(*) × 1 PRE OUT (FRONT L/R, CENTER, SURROUND L/R, HEIGHT 1 L/R, SURROUND BACK L/R or HEIGHT 2 L/R Analog or ZONE 3) ×...
  • Page 190 SN 29403985_EN ©2021 Onkyo Home Entertainment Corporation. All rights reserved. ©2021 Onkyo Home Entertainment Corporation, Tous droits de reproduction et de traduction réservés. https://www.onkyo.com/privacy/ F2106-0...
