Whirlpool ADP 6941 Quick Reference Manual

ADP 6941
Programme selection button
On / Off button
Start button
Switches "on" when the dishwasher is operating.
Flashes when a fault occurs. Switches off at the end
of the programme.
Indicators
Add regeneration salt
Only add regeneration salt immediately before
starting a wash programme.
Add rinse aid
Wash cycle
Pre-Rinse Washing
Programmes
Sensor max
Pre-Rinse
Glass
Quickwash
1) Reference programme for energy label EN 50242
(Liter = 13.0, kWh = 1.05, Min. = 120);
2) Refer to "User instructions";
3) Program data obtained in conformity with European
standard EN 50242. Values may vary in relation to usage,
e.g.: different loads, water temperatures - above or below
15°C - as well as water hardness and power supply
voltage, etc.
Important information for Test Laboratories:
For detailed information on the EN comparison test and other tests, contact the following address:
"nk_customer@whirlpool.com".
Whirlpool is a registered trademark of Whirlpool USA
Before using the dishwasher, read the user instructions!
Quick Reference Guide
Drying
Programme chart
Loading instructions
Lightly, normally or heavily soiled, also
1) 5)
40-70°C
suitable for pans and saucepans.
cold
Crockery to be washed later.
Light soiling, for example glasses and
40°C
cups.
Lightly soiled crockery with no
40°C
dried-on food.
Options
"Half load - Multizone" button
Load the upper or lower rack only.
This function can be used with any programme.
Press once = upper rack (the symbol comes on)
Press twice = lower rack (the symbol comes on)
Press 3 times = Off (half load function deactivated).
When washing without the top rack, press the
"Half Load" button twice, or "Lower rack wash"
(relative symbol lights up).
Time and failure display
Indicates in hours the time remaining until the start
of the wash cycle. Switches off when the
programme starts and indicates the time remaining
in hours and minutes.
"F ...." Identification of faults for service technician
"Delayed start" button
The wash cycle can be programmed to start after
1 - 24 hours. With each successive touch of the button,
the delayed start indicator increases by 1 hour, and
after 24 returns to 00. Then press the Start button.
The dishwasher will start at the set time.
Antibacterial rinse
This function adds an antibacterial rinse at the end of
the wash cycle, thereby guaranteeing a perfectly clean
and sanitized load. The lamp will light up when the
function is activated. If the temperature is not
maintained during the antibacterial cycle (e.g. if the
door is opened and remains open for a long time), the
lamp will start blinking to indicate that sanitation is
not guaranteed.
Detergent
A
X
-
X
X
4) The bacteria removal efficiency has been tested by the
Institut Pasteur de Lille (France), based on the NF
EN 13697 standard of November 2001.
5) These programmes can be used with the Antibacterial
rinse option.
(We reserve the right to make technical modifications)
GB
3)
4)
2) 3)
Consumption
B
Litres kWh Minutes
X 7.0-17.0 0.99-1.58 60-146
- 4.0 0.03 14
- 10.0 0.80 55
- 10.0 0.65 30
5019 396 91514
WH/I/B/GB
