13. TECHNICAL INFORMATION ..........21 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind.
ENGLISH 1. SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes in- juries and damages. Always keep the instructions with the appliance for future reference. 1.1 Children and vulnerable people safety WARNING! Risk of suffocation, injury or permanent disability.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. • The operating water pressure (minimum and maximum) must be between 0,5 bar (0,05 MPa) and 8 bar (0,8 MPa) •...
Page 5
ENGLISH • Do not put a container to collect possi- Water connection ble water leakage under the appliance. • Make sure not to cause damage to the Contact the Service to ensure which water hoses. accessories can be used. • The appliance is to be connected to the water mains using the new supplied 2.3 Care and Cleaning hose-sets.
3. PRODUCT DESCRIPTION Worktop Detergent dispenser Control panel Door handle Rating plate Feet for the appliance level 3.1 Child safety device When you activate this device, you cannot close the door. This prevents children or pets to be closed in the drum. To activate the device, turn it clockwise, until the groove is horizontal.
ENGLISH Programme knob Delay start touchpad Spin reduction touchpad Extra rinse touchpad Temperature touchpad Easy iron touchpad Display Start pause touchpad Prewash touchpad Time Manager touchpads – Programme time. 4.1 Display – The alarm codes. Refer to the chap- ter “Troubleshooting” for their de- scription.
Page 8
Programme Type of load and soil Temperature range Maximum load, Maximum spin Special programme for one synthetic blanket, du- Täcken vet, bedspread and so on. 60° C - 30° C 2 kg, 800 rpm To rinse and spin the laundry. All fabrics.
10 www.electrolux.com Pro- Load Energy Water con- Approxi- Remain- grammes (Kg) consump- sumption mate pro- ing mois- tion (kWh) (litre) gramme ture (%) duration (minutes) Ylle\Handtvätt 0.30 30 °C Standard cotton programmes Standard 60 1.07 °C cotton Standard 60 0.79 °C cotton...
ENGLISH 7.4 Delay Start With this option you can delay the start of a programme from 30 minutes to 20 hours. The display shows the related indicator. ■ ■ ■ ■ ■ ■ 7.5 Extra Rinse 1) Shortest: to freshen the laundry. With this option you can add some rinses 2) Default level.
12 www.electrolux.com Set and start a programme for cotton laundry. This removes all possible dirt at the highest temperature without from the drum and the tub. 9. DAILY USE • Open the water tap. • Connect the mains plug to the mains socket.
Page 13
ENGLISH Liquid or powder detergent • Position A for powder detergent (factory setting). • Position B for liquid detergent. When you use the liquid detergent: – Do not use gelatinous or thick liquid detergents. – Do not put more liquid then the maximum level. –...
Page 14
14 www.electrolux.com After approximately 15 minutes 9.8 Opening the door from the start of the programme: While a programme or the delay start op- • The appliance adjusts automati- erates, the appliance door is locked and cally the programme duration the display shows the indicator agree with the laundry load.
ENGLISH – You must drain the water to open the 9.10 Stand-by door. Some minutes after the end of the wash- To drain the water: ing programme, if you do not deactivate If necessary, decrease the spin the appliance, the energy saving status speed.
16 www.electrolux.com • If your appliance has not the detergent 10.5 Water hardness dispenser with the flap device, add the If the water hardness in your area is high liquid detergents with a dosing ball. or moderate, we recommend that you use a water softener for washing machines.
Page 17
ENGLISH 11.5 Cleaning the detergent dispenser 11.6 Cleaning the drain filter WARNING! Do not clean the drain filter if the water in the appliance is hot.
Page 18
18 www.electrolux.com 11.7 Cleaning the inlet hose and the valve filter...
ENGLISH 45° 20° 11.8 Frost precautions Put the ends of the drain and inlet hose in a container. Let the water If the appliance is installed in an area flow out of the hoses. where the temperature can be less than 0 When no more water flows, install the °C, remove the remaining water from the inlet hose and the drain hose again.
Page 20
20 www.electrolux.com Problem Possible solution The programme does Make sure that the mains plug is connected to the mains not start. socket. Make sure that the appliance door is closed. Make sure that there is not a damaged fuse in the fuse box.
ENGLISH Problem Possible solution Make sure that the drain hose have no damages. Make sure you use the correct detergent and the correct quantity of it. You cannot open the Make sure that the washing programme is finished. appliance door. Set the drain or the spin programme if there is water in the drum.
Page 22
22 www.electrolux.com Electrical connection: Voltage 230 V Overall power 2100 W Fuse 10 A Frequency 50 Hz Level of protection against ingress of solid particles IPX4 and moisture ensured by the protective cover, except where the low voltage equipment has no protection...
